VOLVO EC160C EC160D EC160E EC170D EC180C EC180D EC180E EXCAVATOR VOE14538587 VOE14538545 SWING MOTOR ROTARY GROUP AND SPARE PARTS

VOLVO EC160C EC160D EC160E EC170D EC180C EC180D EC180E EXCAVATOR VOE14538587 VOE14538545 SWING MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
VOE14538587 VOE14538545 EC160C EC160D EC160E EC170D EC180C EC180D EC180E
Pos. Part No Qty Parts name Comments
1   VOE14538587   [1]   Drive unit
2   VOE14538545   [1]   Swing motor
3   VOE14540719   [1]   Swing gearbox
Pos. Part No Qty Parts name Comments
  VOE14538545   [1]   Swing motor
1   SA8230-04420   [1]   Inner race
2   SA8220-15630   [1]   Seal
3   SA8230-00790   [1]   Roller bearing
4   SA8230-04320   [1]   Spring
5   SA8230-04360   [1]   Plate
6   SA8230-04410   [1]   Plate
7   VOE14519350   [9]   Piston
8   SA8230-22900   [3]   Plate
9   SA8230-22910   [3]   Friction plate
10   SA8230-25140   [1]   O-ring
11   SA8230-02411   [2]   O-ring
12   SA8230-04230   [10]   Spring
13   SA8230-31150   [2]   Pin
14   VOE993320   [3]   O-ring
15   VOE14552099   [3]   Cap
16   SA8230-04240   [4]   Spring
17   SA8230-00891   [4]   Sealing ring
18   SA8230-04330   [4]   Bushing
19   SA8230-03990   [1]   Plate
20   SA8230-00820   [1]   Needle Bearing
21   VOE14519351   [1]   Piston
22   SA8230-01030   [1]   Ring
23   VOE14508587   [1]   Cylinder
24   VOE14508589   [1]   Housing
25   SA8230-23350   [1]   Plug
26   VOE14508590   [2]   Valve
27   VOE14625246   [1]   Ring
28   VOE990557   [1]   O-ring
29   VOE983503   [1]   O-ring
30   VOE14534867   [1]   Cover
31   VOE14534868   [1]   Valve
32   SA8230-00610   [3]   Bolt
33   SA8230-11610   [2]   Cap
34   VOE14880821   [2]   Back-up ring
35   VOE983525   [4]   O-ring
36   VOE14596241   [2]   Spring
37   SA8230-11110   [2]   Non-return valve
38   VOE14508592   [2]   Relief valve
39   VOE984135   [4]   Hex. socket screw
100   VOE14534869   [1]   Seal
