VOLVO EC140B Travel gearbox

VOLVO EC140B Travel gearbox

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group Travel gearbox:EC140B Travel gearbox None 8277946-None NoneNone None Autodata Volvo online
Pos. Part No Qty Parts name Comments
  VOE14528733   [1]   Travel gearbox
1   SA7117-30100   [1]   Housing   S/N 10001-11739 S/N 20001-20082
  VOE14522475   [1]   Housing   S/N 11740- S/N 20083-
2   SA7117-30110   [2]   Ball bearing
3   SA7117-30120   [1]   Seal   S/N 10001-11739 S/N 20001-20082
  VOE14729840   [1]   Seal   S/N 11740- S/N 20083-
4   SA7117-30140   [1]   Shim   THICK=0.1
  SA7117-30150   [1]   Shim   THICK=0.9
  SA7117-30160   [1]   Shim   THICK=1.0
  SA7117-30170   [1]   Shim   THICK=1.2
5   SA7117-30130   [1]   Retainer
6   VOE997446   [12]   Hexagon screw
7   SA9324-21212   [2]   Pin
8   SA7117-30190   [1]   Ring gear
9   SA7117-30180   [1]   Flexible coupling
10   SA7117-30200   [1]   Carrier   S/N 10001-11739 S/N 20001-20082
  VOE14528723   [1]   Planet carrier   S/N 11740- S/N 20083-
11   SA7117-30210   [1]   Planet carrier
12   SA7117-30240   [4]   Planetary Gear
13   SA7117-30230   [8]   Needle bearing
14   SA7117-30220   [8]   Thrust washer
15   SA7117-30250   [4]   Pin   S/N 10001-11739 S/N 20001-20082
  VOE14528724   [4]   Pin   S/N 11740- S/N 20083-
16   SA9325-06012   [4]   Spring pin
17   SA7117-30260   [1]   Thrust ring
18   SA7117-30270   [1]   Carrier   S/N 10001-11739 S/N 20001-20082
  VOE14528727   [1]   Planet carrier   S/N 11740- S/N 20083-
19   VOE14528728   [1]   Planet carrier
20   SA7117-30290   [1]   Sun gear
21   SA7117-30300   [1]   Ring
22   SA7117-30340   [3]   Planetary gear
23   SA7117-30320   [3]   Needle bearing
24   SA7117-30310   [6]   Thrust washer
