VOLVO EC140B EXCAVATOR VOE14531858 HYDRAULIC PUMP ROTARY GROUP

Name: VOLVO EC140B EXCAVATOR VOE14531858 HYDRAULIC PUMP ROTARY GROUP
Brand: +8613035309093
Price: 5000.0 USD
Availability: InStock

VOLVO EC140B EXCAVATOR VOE14531858 HYDRAULIC PUMP ROTARY GROUP

$5,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

VOE14531858 EC140B

Pos.	Part No	Qty	Parts name	Comments
1	VOE14531858	[1]	Pump
2	VOE14535541	[1]	Regulator control
3	VOE14535543	[1]	Regulator control
4	VOE14534034	[1]	Gear pump
5	VOE984140	[4]	Hex. socket screw
6	VOE60110299	[4]	Washer
Parts on group Hydraulic pump:

Pos.	Part No	Qty	Parts name	Comments
	VOE14531858	[1]	Pump
1	VOE14567022	[2]	Piston
2	VOE14508516	[1]	Cylinder	RH
3	VOE14604488	[1]	Cylinder	LH
4	SA8230-32220	[2]	Plate
5	SA8230-09231	[1]	Shaft
6	SA8230-28260	[1]	Shaft
7	SA8230-28280	[1]	Snap-on coupling
8	SA8230-25430	[2]	Roller bearing
9	VOE14511629	[2]	Needle bearing
10	SA8230-14520	[4]	Spacer
11	SA8230-09220	[2]	Bushing
12	VOE14508524	[2]	Bushing
13	SA8230-09380	[18]	Spring
14	SA8230-09420	[2]	Bolt
15	SA8230-09620	[2]	Plate
16	SA8230-32180	[2]	Support
17	SA8230-09270	[1]	Cover
18	VOE14567020	[2]	Pump housing
19	SA8230-08920	[1]	Valve body
20	SA8230-09390	[8]	Bolt
21	SA8230-25840	[4]	Bolt
22	VOE14883837	[2]	Plug
23	SA8230-26050	[4]	Plug
24	VOE14560637	[15]	Plug
25	SA8230-09730	[2]	Pin
26	VOE14508528	[2]	Piston
27	VOE14511631	[2]	Stop ring
28	SA8230-09410	[2]	Plate
29	VOE14528251	[2]	O-ring
30	VOE14534033	[1]	O-ring
31	VOE14534032	[2]	O-ring
32	VOE14534031	[2]	O-ring
33	VOE14533604	[18]	O-ring
34	VOE14534029	[2]	O-ring
35	VOE14534028	[4]	O-ring
36	VOE14528250	[2]	O-ring
37	VOE14518818	[1]	Seal
38	VOE14880816	[2]	Back-up ring
39	VOE14880837	[2]	Back-up ring
40	SA8230-25620	[4]	Nut
41	VOE914465	[2]	Snap ring
42	SA8230-26400	[2]	Pin
43	SA7223-00660	[4]	Spring pin
44	VOE14623509	[2]	Eye bolt
45	SA8230-26780	[2]	Bolt
100	VOE14555218	[1]	Seal
Parts on group Regulator, hydraulic pump:

Pos.	Part No	Qty	Parts name	Comments
	VOE14535541	[1]	Regulator control
	VOE14535543		Regulator control
1	SA8230-25910	[2]	Hex. socket screw
2	SA8230-25920	[2]	Bolt
3	SA8230-25860	[2]	Bolt
4	SA8230-25850	[6]	Bolt
5	VOE14560637	[6]	Plug
6	SA8230-08970	[1]	Casing
7	VOE14501610	[1]	Lever
8	SA8230-09440	[1]	Lever
9	SA8230-09450	[1]	Lever
10	SA8230-09460	[1]	Plug
11	SA8230-09470	[1]	Plug
12	SA8230-09480	[1]	Piston
13	SA14535542	[1]	Sleeve
14	SA8230-09500	[1]	Rod
15	SA8230-09510	[1]	Seat
16	VOE14500010	[1]	Spring
17	SA8230-09520	[1]	Spring
18	SA8230-09530	[1]	Stem
19	SA8230-09540	[1]	Screw
20	SA8230-09240	[1]	Cover
21		[1]	Lock nut
22	VOE14501611	[1]	Sleeve
23	SA8230-09340	[1]	Cover
24	SA8230-09560	[1]	Piston
25	SA8230-09570	[1]	Seat
26	VOE14501612	[1]	Stem
27	VOE14500007	[1]	Spring
28	VOE14501613	[1]	Sleeve
29	SA8230-09590	[1]	Spool
30	SA8230-09600	[1]	Seat
31	SA8230-09630	[1]	Spring
32	SA8230-09610	[1]	Spring
33	SA8230-09820		Cover
34	VOE14534051	[1]	O-ring
35	VOE14533603	[1]	O-ring
36	VOE14533604	[9]	O-ring
37	VOE14534050	[1]	O-ring
38	VOE14534028	[1]	O-ring
39	VOE14534049	[1]	O-ring
40	VOE14528250	[2]	O-ring
41	VOE14534048	[1]	O-ring
42	VOE14534047	[1]	O-ring
43	VOE14601515	[1]	O-ring
44	VOE14534029	[3]	O-ring
45	VOE14534045	[1]	O-ring
46	VOE14534044	[1]	O-ring
47	SA9113-10800	[2]	Hexagon nut
48	SA8240-03680	[1]	Snap ring
49	SA8230-26960	[1]	Ring
50	VOE914503	[2]	Retaining ring
51	VOE14500006	[1]	Cover
52		[4]	Pin
53	SA8230-09750	[1]	Pin
54	VOE14500005	[1]	Pin
55	VOE14501614	[1]	Pin
56	SA8240-04510	[1]	Screw
57	SA8230-09720	[1]	Screw
58	VOE14534053	[2]	O-ring
59	VOE14883837	[1]	Plug
60	SA8230-25870	[4]	Bolt
61	VOE14501615	[1]	Casing
62	SA8230-32080	[1]	Valve
63	VOE990547	[1]	O-ring
64	VOE14535455	[1]	O-ring
65	VOE14535456	[1]	O-ring
100	VOE14555217	[1]	Seal
Parts on group Hydraulic gear pump:

Pos.	Part No	Qty	Parts name	Comments
	VOE14534034	[1]	Gear pump
