VOLVO EC135B EC140B EXCAVATOR VOE14533648 SA1143-01060 SA7117-30011 VOE14524182 VOE14528729 TRAVEL MOTOR PARTS

VOLVO EC135B EC140B EXCAVATOR VOE14533648 SA1143-01060 SA7117-30011 VOE14524182 VOE14528729 TRAVEL MOTOR PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
VOE14533648
SA1143-01060 SA7117-30011 VOE14524182 VOE14528729
EC135B EC140B
Pos. Part No Qty Parts name Comments
  VOE14524182   [1]   Drive unit
1   SA8230-33440   [1]   Plate
2   SA8230-34310   [1]   Plunger
3   VOE990557   [2]   O-ring
4   SA8230-34150   [2]   Seat
5   SA8230-34130   [2]   Spring
6   SA8230-34160   [2]   Seat
7   SA8230-34320   [2]   Cap
8       [1]   O-ring
9       [1]   O-ring
10   SA8230-34330   [2]   Valve
11   SA8230-32630   [1]   O-ring
12   VOE983510   [1]   O-ring
13   SA9566-30210   [2]   Back-up ring
14   VOE983506   [1]   O-ring
15   VOE14625243   [2]   Ring
16   SA8230-32300   [11]   Plug
17   SA8230-32380   [1]   Valve
18   VOE983493   [1]   O-ring
19   VOE990551   [1]   O-ring
20   SA9566-10060   [1]   Back-up ring
21   SA9566-10050   [1]   Back-up ring
22   SA8230-33400   [1]   Spring
23   SA8230-34050   [1]   Plug
24   VOE990557   [2]   O-ring
25   SA8230-33430   [1]   Guide
26   SA8230-33940   [1]   Plug
27   SA8230-34220   [2]   Orifice
28   SA8230-34230   [2]   Orifice
29   SA8230-32650   [2]   Orifice
30 SA8230-32360   [1]   Shaft
31   SA8230-32390   [1]   Block
32   SA8230-33410   [1]   Plate
33   SA8230-34020   [2]   Ball
34   SA8230-33980   [1]   Ball bearing
35   SA8230-33970   [1]   Ball bearing
36   SA8230-32410   [1]   Pin
37   SA8230-33230   [9]   Bolt
38   SA8230-32420   [1]   Seal
39   SA8230-34040   [1]   Plate
40   SA8230-34030   [1]   Piston
41   VOE960252   [1]   O-ring
42   SA9566-41800   [1]   Back-up ring
43   SA8230-33960   [1]   O-ring
44   SA8230-33950   [1]   Ring
45   SA8230-32330   [8]   Spring
46   SA8230-32320   [4]   Pin
47   SA8230-33930   [1]   Plate
48   SA8230-34210   [1]   Orifice
49   VOE983497   [4]   O-ring
50   SA8230-34070   [1]   O-ring
51   SA8230-34050   [2]   Plug
52   VOE990557   [2]   O-ring
53   SA8230-32700   [2]   Plug
54   SA8230-32690   [1]   Plug
55   SA8230-32350   [3]   Plug
56   VOE983502   [3]   O-ring
57   SA8230-33890   [2]   Spring
58   SA8230-33550   [1]   Holder
59   SA8230-32600   [1]   Holder
60   SA8230-33390   [2]   Plug
61   SA8230-34090   [2]   Piston
62   SA8230-33470   [1]   Travel gearbox
900   SA8230-33460   [1]   Plate   INCL.1,2,16,17
100   SA8230-32400   [1]   Sealing Kit
Parts on group Travel motor with mounting parts:
Pos. Part No Qty Parts name Comments
1   SA1143-01060   [2]   Drive unit
  VOE14524182   [2]   Drive unit
  SA7117-30011       Drive unit
  VOE14528729       Drive unit
2   VOE14533648       Travel motor
3   VOE14528733       Travel gearbox
4   VOE60110321   [32]   Hexagon screw
5   VOE60110299   [32]   Washer
