Toshiba SG20 hydraulic swing motor rotory group and spare parts used for Volvo EC360 excavator

Toshiba SG20 hydraulic swing motor rotory group and spare parts used for Volvo EC360 excavator

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
MFC250-014 31NA-10120 XJDB-00223 R360LC-7 R370LC-7
Pos. Part No Qty Parts name Comments
*. 31NA-10120 [1]   SWING UNIT      *-1,*-2 OPT
N*-1. XJDB-00223 [1]   SWING MOTOR UNIT
1 XJDB-00164 [1]   RING-SNAP
2 XJDB-00165 [1]   RING-INNER
3 XJDB-00167 [1]   SEAL-OIL
4 XJDB-00168 [1]   BEARING-T/ROLLER
N5. XJDB-00169 [1]   HOUSING
6 XJDB-00170 [1]   PLATE-CAM
7 XJDB-00171 [1]   PLATE-RETURN
8 XJDB-00172 [1]   SPRING-BACKING
9 XJDB-00173 [1]   CYLINDER
10 XJDB-00174 [9]   PISTON ASSY
11 XJDB-00175 [4]   PLATE-LINING
12 XJDB-00176 [4]   PLATE-FREE
13 XJDB-00177 [1]   PISTON
14 XJDB-00178 [1]   O-RING
15 XJDB-00179 [2]   O-RING
16 XJDB-00014 [19]   SPRING
17 XJDB-00180 [4]   RING-TEFLON
18 XJDB-00181 [4]   PLATE-DISK
19 XJDB-00182 [4]   BUSHING
20 XJDB-00017 [2]   CAP
21 XJDB-00018 [2]   O-RING
22 XJDB-00183 [1]   BOLT-SOCKET
N23. XJDB-00184 [2]   PISTON
24 XJDB-00222 [1]   COVER
25 XJDB-00015 [2]   PIN-PARALLEL
26 XJDB-00186 [1]   PIN-PARALLEL
27 XJDB-00187 [1]   PLATE-BALANCE
28 XJDB-00188 [1]   BEARING-NEEDLE
29 XJDB-00189 [1]   RING-SNAP
30 XJDB-00190 [1]   CAP
31 XJDB-00032 [3]   O-RING
32 XJDB-00096 [2]   O-RING
33 XJDB-00191 [2]   RELIEF VALVE ASSY
34 XJDB-00073 [7]   BOLT-SOCKET
35 XJDB-00044 [2]   CAP
36 XJDB-00043 [2]   SPRING
37 XJDB-00045 [2]   RING-BACK UP
38 XJDB-00036 [2]   O-RING
39 XJDB-00042 [2]   VALVE-CHECK
40 XJDB-00033 [2]   O-RING
41 XJDB-00031 [2]   RING-BACK UP
42 XJDB-00030 [2]   BYPASS VALVE ASSY
43 XJDB-00038 [1]   VALVE-TIME DELAY
44 XJDB-00037 [3]   BOLT-SOCKET
45 XJDB-00039 [1]   O-RING
46 XJDB-00040 [2]   O-RING
*-2. @ [1]   SWING REDUCTION GEAR      SEE 4110
N. @ [AR]
