Toshiba SG20 hydraulic swing motor rotary group and spare parts used for Volvo EC360 excavator

Name: Toshiba SG20 hydraulic swing motor rotary group and spare parts used for Volvo EC360 excavator
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

Toshiba SG20 hydraulic swing motor rotary group and spare parts used for Volvo EC360 excavator

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

SG20 MFC250 R450LC-7 EC360 31NB-11130 XJDB-00356

Pos.	Part No	Qty	Parts name	Comments
N*.	31NB-11130	[1]	SWING MOTOR ASSY
N*-1.	XJDB-00356	[1]	SWING MOTOR
1	XJDB-00002	[1]	RACE-INNER
2	XJDB-00003	[1]	SEAL-OIL
3	XJDB-00004	[1]	BEARING-ROLLER
4	XJDB-00225	[1]	GAUGE ASSY-LEVEL
5	XJDB-00005	[1]	SPRING-BACKING
6	XJDB-00006	[1]	PLATE-CAM
7	XJDB-00007	[1]	PLATE-RETURN
8	XJDB-00226	[9]	PISTON ASSY
9	XJDB-00009	[3]	PLATE-LINING
10	XJDB-00010	[3]	PLATE
11	XJDB-00011	[1]	O-RING
12	XJDB-00012	[1]	PISTON
13	XJDB-00013	[2]	O-RING
14	XJDB-00014	[11]	SPRING
15	XJDB-00015	[2]	PIN-PARALLEL
16	XJDB-00016	[2]	PISTON
17	XJDB-00018	[3]	O-RING
18	XJDB-00017	[3]	CAP
19	XJDB-00019	[4]	SCROWWAVE
20	XJDB-00020	[4]	RING-TEFLON
21	XJDB-00021	[4]	BUSHING
22	XJDB-00022	[1]	PLATE-BALANCE
23	XJDB-00023	[1]	BEARING-NEEDLE
24	XJDB-00024	[1]	RING-SNAP
25	XJDB-00025	[1]	CYLINDER ASSY
26	XJDB-00227	[1]	HOUSING
27	XJDB-00027	[1]	COLLAR
28	XJDB-00071	[2]	PLUG
29	XJDB-00029	[1]	RING-SNAP
30	XJDB-00030	[2]	BYPASS VALVE ASSY
31	XJDB-00031	[2]	RING-BACK UP
32	XJDB-00032	[2]	O-RING
33	XJDB-00033	[2]	O-RING
N34.	XJDB-00034	[1]	COVER
35	XJDB-00038	[1]	VALVE-TIME DELAY
36	XJDB-00037	[3]	BOLT-SOCKET
37	XJDB-00039	[1]	O-RING
38	XJDB-00040	[2]	O-RING
39	XJDB-00035	[2]	RELIEF VALVE ASSY
40	XJDB-00036	[4]	O-RING
41	XJDB-00041	[4]	BOLT-SOCKET
42	XJDB-00042	[2]	VALVE-CHECK
43	XJDB-00043	[2]	SPRING
44	XJDB-00044	[2]	CAP
45	XJDB-00045	[2]	RING-BACK UP
N.	@	[1]	NOT INDIVIDUALLY SUPPLIED

MFC250-014 31NA-10120 XJDB-00223 R360LC-7 R370LC-7

Pos.	Part No	Qty	Parts name	Comments
*.	31NA-10120	[1]	SWING UNIT	-1,-2 OPT
N*-1.	XJDB-00223	[1]	SWING MOTOR UNIT
1	XJDB-00164	[1]	RING-SNAP
2	XJDB-00165	[1]	RING-INNER
3	XJDB-00167	[1]	SEAL-OIL
4	XJDB-00168	[1]	BEARING-T/ROLLER
N5.	XJDB-00169	[1]	HOUSING
6	XJDB-00170	[1]	PLATE-CAM
7	XJDB-00171	[1]	PLATE-RETURN
8	XJDB-00172	[1]	SPRING-BACKING
9	XJDB-00173	[1]	CYLINDER
10	XJDB-00174	[9]	PISTON ASSY
11	XJDB-00175	[4]	PLATE-LINING
12	XJDB-00176	[4]	PLATE-FREE
13	XJDB-00177	[1]	PISTON
14	XJDB-00178	[1]	O-RING
15	XJDB-00179	[2]	O-RING
16	XJDB-00014	[19]	SPRING
17	XJDB-00180	[4]	RING-TEFLON
18	XJDB-00181	[4]	PLATE-DISK
19	XJDB-00182	[4]	BUSHING
20	XJDB-00017	[2]	CAP
21	XJDB-00018	[2]	O-RING
22	XJDB-00183	[1]	BOLT-SOCKET
N23.	XJDB-00184	[2]	PISTON
24	XJDB-00222	[1]	COVER
25	XJDB-00015	[2]	PIN-PARALLEL
26	XJDB-00186	[1]	PIN-PARALLEL
27	XJDB-00187	[1]	PLATE-BALANCE
28	XJDB-00188	[1]	BEARING-NEEDLE
29	XJDB-00189	[1]	RING-SNAP
30	XJDB-00190	[1]	CAP
31	XJDB-00032	[3]	O-RING
32	XJDB-00096	[2]	O-RING
33	XJDB-00191	[2]	RELIEF VALVE ASSY
34	XJDB-00073	[7]	BOLT-SOCKET
35	XJDB-00044	[2]	CAP
36	XJDB-00043	[2]	SPRING
37	XJDB-00045	[2]	RING-BACK UP
38	XJDB-00036	[2]	O-RING
39	XJDB-00042	[2]	VALVE-CHECK
40	XJDB-00033	[2]	O-RING
41	XJDB-00031	[2]	RING-BACK UP
42	XJDB-00030	[2]	BYPASS VALVE ASSY
43	XJDB-00038	[1]	VALVE-TIME DELAY
44	XJDB-00037	[3]	BOLT-SOCKET
45	XJDB-00039	[1]	O-RING
46	XJDB-00040	[2]	O-RING
*-2.	@	[1]	SWING REDUCTION GEAR	SEE 4110
N.	@	[AR]
