SG04 swing motor valve plate balance plate

SG04 swing motor valve plate balance plate

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Pos. Part No Qty Parts name Comments
*. @ [1]   SWING MOTOR ASSY
N*-1. 31N3-10220 [1]   SWING MOTOR UNIT
1 XJDB-00047 [1]   RING-INNER
2 XJDB-00048 [1]   SEAL-OIL
3 XJDB-00049 [1]   BEARING-T/ROLLER
4 XJDB-00050 [1]   SPRING-BACKING
5 XJDB-00051 [1]   PLATE-CAM
6 XJDB-00052 [1]   PLATE-RETURN
7 XJDB-00053 [9]   PISTON ASSY      1321-132
8 XJDB-00054 [2]   PLATE-LINING
9 XJDB-00055 [2]   PLATE
10 XJDB-00056 [1]   O-RING
11 XJDB-00058 [1]   PISTON
12 XJDB-00057 [2]   O-RING
13 XJDB-00059 [14]   SPRING      1390-162
14 XJDB-00060 [2]   RING-TEFLON
15 XJDB-00061 [2]   PISTON
16 XJDB-00017 [3]   CAP      0824-051
17 XJDB-00018 [3]   O-RING      8202-009
18 XJDB-00062 [4]   SCROWAVE
19 XJDB-00063 [4]   RING-TEFLON
20 XJDB-00064 [4]   BUSH
21 XJDB-00065 [1]   PLATE-BALANCE
22 XJDB-00066 [1]   BEARING-NEEDLE
23 XJDB-00067 [1]   RING-SNAP
N24. XJDB-00068 [1]   CYLINDER ASSY
N25. XJDB-00069 [1]   HOUSING
26 XJDB-00030 [2]   BYPASS VALVE ASSY      3537-252
27 XJDB-00031 [2]   RING-BACK UP      0859-320
28 XJDB-00032 [2]   O-RING      8202-014
29 XJDB-00033 [2]   O-RING      8202-010
30 XJDB-00070 [1]   COVER
31 XJDB-00071 [1]   PLUG      8320-003
32 XJDB-00072 [2]   PIN-PARALLEL      8022-101
33 XJDB-00036 [4]   O-RING      8202-021
34 XJDB-00035 [2]   RELIEF VALVE ASSY      3537-194
35 XJDB-00037 [3]   BOLT-SOCKET      0576-054
36 XJDB-00038 [1]   VALVE-TIME DELAY      1329-111
37 XJDB-00039 [1]   O-RING      0200-010
38 XJDB-00040 [2]   O-RING      0200-049
39 XJDB-00073 [4]   BOLT-SOCKET      0576-034
40 XJDB-00042 [2]   VALVE-CHECK      3513-154
41 XJDB-00043 [2]   SPRING      3590-288
42 XJDB-00044 [2]   CAP      3526-327
43 XJDB-00045 [2]   RING-BACK UP      0859-229
*-2. @ [1]   SWING REDUCTION GEAR      SEE 4110
N. @ [AR]
