Rexroth A6VE160 travel motor friction plate

Rexroth A6VE160 travel motor friction plate

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
A6VE160
31NB-40030 34E7-03050  ROTARY GROUP ZGAR-00039 ZGAR-00051
R450LC-7 R500LC-7 R450LC-7A R500LC-7A R480LC-9 R480LC-9MH R520LC-9 R480LC-9A R520LC-9A R480LC-9S R520LC-9S
34E7-02490 34E7-03050 34E7-03051 ROTARY GROUP ZGAR-00039 ZGAR-00051
R450LC-3 R450LC-7 R450LC-7A R480LC-9MH R480LC-9 R480LC-9A R480LC-9S R500LC-7 R500LC-7A R520LC-9 R520LC-9AR520LC-9S
Pos. Part No Qty Parts name R450LC-7
N*. 34E7-03050 [1]   TRAVEL MOTOR ASSY      *-1,*-2
*-1. 34E7-02490 [1]   TRACK MOTOR UNIT
1 ZGAR-00039 [1]   ROTARY GROUP 09603784
1-1. ZGAR-00051 [1]   ROTARY-HYD SECTION      09603785
1-1-1. ZGAR-00070 [1]   CYLINDER 09430794
1-1-2. ZGAR-00071 [1]   LENS-CONTROL 09921790
1-1-3. ZGAR-00072 [1]   PIN-CENTER 09921576
1-1-4. ZGAR-00073 [7]   PISTON 09430790
1-1-5. ZGAR-00082 [14]   RING-STEEL SEALING 09831897
1-1-6. ZGAR-00074 [1]   SHIM-ADJUST 09921577
1-1-7. ZGAR-00080 [1]   SPRING-PRESSURE 09921583
1-1-11. ZGAR-00081 [1]   PLATE-RETAINING 09062969
1-1-12. ZGAR-00083 [14]   SCREW-PAN HEAD 09831108
1-2. ZGAR-00052 [1]   SHAFT-DRIVE 09921597
N1-3. ZGAR-00053 [1]   SHIM      09651499
1-6. ZGAR-00058 [1]   PLATE-BACK UP      09650815
1-7. ZGAR-00067 [1]   RING-RETAINING      09083369
1-10. ZGAR-00068 [1]   BEARING-ROLLER      09154687
1-11. ZGAR-00069 [1]   BEARING-ROLLER      09154688
5 ZGAR-00043 [1]   HOUSING
9 ZGAR-00044 [1]   RING-RETAINING      09083416
10 ZGAR-00045 [1]   RING-SHAFT SEAL      09831663
11 ZGAR-00046 [1]   PLATE-BACK UP      09832084
12 ZGAR-00047 [1]   O-RING      09087781
13 ZGAR-00048 [1]   SCREW-LOCKING      09156989
14 ZGAR-00049 [1]   O-RING
17 ZGAR-00041 [2]   PIN-THREADED      09446862
18 ZGAR-00050 [2]   NUT-SEAL LOCK      09152459
25 ZGAR-00042 [1]   O-RING
*-2. ZGAR-00040 [1]   CONTROL GROUP
Pos. Part No Qty Parts name Comments
*. @ [1]   TRAVEL MOTOR ASSY      SEE 4150
*. @ [1]   TRAVEL MOTOR UNIT      SEE 4150
*-2. ZGAR-00040 [1]   CONTROL GROUP
1 ZGAR-00089 [1]   PLATE-PORT
2 ZGAR-00090 [1]   PISTON-POSITIONING
3 ZGAR-00091 [1]   TRUNNING-POSITIONING
4 ZGAR-00092 [1]   BUSHING-CONTROL
5 ZGAR-00093 [1]   PISTON-CONTROL
6 ZGAR-00094 [1]   SPRING-PRESSURE
7 ZGAR-00095 [1]   SCREW-LOCKING
8 ZGAR-00096 [1]   SCREW-THROTTLE
9 ZGAR-00097 [1]   SCREW-THROTTLE
10 ZGAR-00084 [1]   VALVE-BRAKE
10-1. ZGAR-00113 [1]   PISTON-BRAKE
10-2. ZGAR-00114 [2]   SCREW-LOCKING
10-3. ZGAR-00115 [2]   SPRING-PRESSURE
10-4. ZGAR-00116 [2]   WASHER
10-5. ZGAR-00096 [2]   SCREW-THROTTLE
10-6. ZGAR-00097 [2]   SCREW-THROTTLE
10-10. ZGAR-00085 [2]   PIN-THROTTLE
10-11. ZGAR-00117 [2]   O-RING
11 ZGAR-00085 [1]   PIN-THROTTLE
12 ZGAR-00086 [2]   VALVE
N12-1. ZGAR-00119 [1]   POPPET-VALVE
N12-2. ZGAR-00120 [1]   SPRING-PRESSURE
12-3. ZGAR-00121 [1]   SEAT-POPPET
N12-4. ZGAR-00122 [1]   POPPET-VALVE
N12-5. ZGAR-00123 [1]   SPRING-PRESSURE
N12-6. ZGAR-00124 [1]   SCREW-LOCKING
12-11. ZGAR-00125 [1]   O-RING
13 ZGAR-00098 [1]   SCREW-LOCKING
N14. ZGAR-00099 [1]   SCREW-VALVE
15 ZGAR-00100 [1]   BUSHING
20 ZGAR-00101 [4]   SCREW-SOCKET HEAD
22 ZGAR-00102 [4]   SCREW-SOCKET HEAD
23 ZGAR-00103 [2]   PIN-CYLINDER
24 ZGAR-00104 [4]   SCREW-LOCKING
25 ZGAR-00105 [2]   SCREW-LOCKING
26 ZGAR-00106 [1]   O-RING
27 ZGAR-00107 [1]   O-RING
28 ZGAR-00108 [5]   PIN-D/BREAK OFF
29 ZGAR-00109 [1]   BALL
30 ZGAR-00110 [1]   SCREW-LOCKING
31 ZGAR-00111 [2]   PIN-D/BREAK OFF
32 ZGAR-00112 [1]   SCREW-LOCKING
49 ZGAR-00087 [1]   VALVE-PRESS CONTROL
49-1. ZGAR-00126 [1]   SCREW-LOCKING
49-2. ZGAR-00127 [1]   PISTON-CONTROL
49-3. ZGAR-00128 [1]   BUSHING-CONTROL
49-4. ZGAR-00129 [1]   SPRING-PRESSURE
49-5. ZGAR-00130 [1]   O-RING
49-6. ZGAR-00131 [1]   SHIM
50 ZGAR-00136 [2]   VALVE-RELIEF PRESS
50-1. ZGAR-00132 [1]   SEAL KIT
50-2. ZGAR-00133 [2]   CAP
34E7-02490 34E7-03050 34E7-03051 ROTARY GROUP ZGAR-00039 ZGAR-00051
R450LC-3 R450LC-7 R450LC-7A R480LC-9MH R480LC-9 R480LC-9A R480LC-9S R500LC-7 R500LC-7A R520LC-9 R520LC-9AR520LC-9S
Pos. Part No Qty Parts name Comments
N*. 34E7-03050 [1]   TRAVEL MOTOR ASSY      *-1,*-2
N*. 34E7-03051 [1]   TRAVEL MOTOR ASSY      *-1,*-2
*-1. 34E7-02490 [1]   TRACK MOTOR UNIT      SB-S-2013-025
1 ZGAR-00039 [1]   ROTARY GROUP
1-1. ZGAR-00051 [1]   ROTARY-HYD SECTION
1-1-1. ZGAR-00070 [1]   CYLINDER
1-1-2. ZGAR-00071 [1]   LENS-CONTROL
1-1-3. ZGAR-00072 [1]   PIN-CENTER
1-1-4. ZGAR-00073 [7]   PISTON
1-1-5. ZGAR-00082 [14]   RING-STEEL SEALING
1-1-6. ZGAR-00074 [1]   SHIM-ADJUST
1-1-7. ZGAR-00080 [1]   SPRING-PRESSURE
1-1-11. ZGAR-00081 [1]   PLATE-RETAINING
1-1-12. ZGAR-00083 [14]   SCREW-PAN HEAD
1-2. ZGAR-00052 [1]   SHAFT-DRIVE
N1-3. ZGAR-00053 [1]   SHIM
1-6. ZGAR-00058 [1]   PLATE-BACK UP
1-7. ZGAR-00067 [1]   RING-RETAINING
1-10. ZGAR-00068 [1]   BEARING-ROLLER
1-11. ZGAR-00069 [1]   BEARING-ROLLER
5 ZGAR-00043 [1]   HOUSING
9 ZGAR-00044 [1]   RING-RETAINING
10 ZGAR-00045 [1]   RING-SHAFT SEAL
11 ZGAR-00046 [1]   PLATE-BACK UP
12 ZGAR-00047 [1]   O-RING
13 ZGAR-00048 [1]   SCREW-LOCKING
14 ZGAR-00049 [1]   O-RING
17 ZGAR-00041 [2]   PIN-THREADED
18 ZGAR-00050 [2]   NUT-SEAL LOCK
25 ZGAR-00042 [1]   O-RING
*-2. ZGAR-00040 [1]   CONTROL GROUP
N. @ [AR]   NOT SUPPLIED PARTS
