KMF160 KMV160 swing motor parts

KMF160 KMV160 swing motor parts

$3,000.00 USD
$3,000.00 USD
特價 售罄
結帳時計算運費。
KMF160=KMV160 PC300-6HM
706-77-01170 706-77-01271 706-77-03070 706-77-03130 PC300-6 PC300-6Z PC300LC-6 PC300LC-6Z PC300SC-6 PC340-6K PC340LC-6K PC340NLC-6K PC350-6 PC350-6Z PC350LC-6 PC350LC-6Z PC380LC-6K PC400-6 PC400-6Z PC400LC-6 PC400LC-6Z PC400ST-6 PC400ST-6LC PC450-6K-J PC450-6 PC450-6Z PC450LC-6 PC450LC-6K-J

706-77-01281 706-77-03130 PC300-6 PC300-6Z PC300LC-6 PC300LC-6LE/HD-6LE PC300LC-6Z PC300LL-6 PC340LC-6K-J PC340NLC-6 PC350-6 PC350-6Z PC350LC-6 PC350LC-6Z PC380LC-6K-J PC400-6 PC400-6Z PC400LC-6 PC400LC-6LK/HD-6LK PC400LC-6LM/HD-6LM PC400LC-6Z PC400ST-6 PC400ST-6LC PC450-6 PC450-6K PC450-6Z PC450-6K-J PC450-6K-KE PC450LC-6 PC450LC-6K PC450LC-6K-KE PC450LC-6K-J PC450LC-6Z
PC300LL-7L
Pos. Part No Qty Parts name Comments
     706-77-01281   [1]   MOTOR ASSEMBLY, SWING (COMPLETE) Komatsu China
  ["SN: A83001--UP"] analogs:["7067701280"] |$0.
        706-77-03130   [1]   MOTOR SUB ASSEMBLY Komatsu China
  ["SN: A83001--UP"] |$1.
1   706-77-43210   [1]   CASE, MOTOR Komatsu 21.001 kg.
  ["SN: A83001--UP"]
2   706-77-72610   [2]   HOUSING Komatsu 30 kg.
  ["SN: A83001--UP"]
3   706-75-42830   [1]   PIN Komatsu 0.02 kg.
  ["SN: A83001--UP"]
4   706-77-72170   [2]   PLUG Komatsu 0.115 kg.
  ["SN: A83001--UP"]
5   07002-12434   [2]   O-RING Komatsu China 0.01 kg.
  ["SN: A83001--UP"] analogs:["0700202434", "0700213434"]
6   706-73-71450   [1]   PIN Komatsu 0.035 kg.
  ["SN: A83001--UP"]
7   07002-11423   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: A83001--UP"] analogs:["0700201423"]
8   706-7G-40010   [1]   BEARING Komatsu 0.032 kg.
  ["SN: A83001--UP"]
9   706-7E-11440   [1]   O-RING Komatsu 0.008 kg.
  ["SN: A83001--UP"]
10   706-77-43180   [8]   BOLT Komatsu China
  ["SN: A83001--UP"]
11   706-77-43860   [1]   SHAFT Komatsu 6.581 kg.
  ["SN: A83001--UP"]
12   706-77-43880   [1]   BEARING Komatsu 5.5 kg.
  ["SN: A83001--UP"] analogs:["7067743890"]
13   706-77-42890   [1]   BEARING Komatsu 1.185 kg.
  ["SN: A83001--UP"]
14   706-77-42051   [2]   SPRING Komatsu 0.14 kg.
  ["SN: A83001--UP"]
15   706-77-42041   [1]   SEAT Komatsu 0.1 kg.
  ["SN: A83001--UP"]
16   706-77-05010   [1]   KIT, SPACER Komatsu 0.172 kg.
  ["SN: A83001--UP"]
     706-77-42440   [2]   SPACER, 2.30 mm Komatsu 0.172 kg.
  ["SN: A83001--UP"] analogs:["7067705010"] |$18.
     706-77-42450   [2]   SPACER, 2.50 mm Komatsu 0.172 kg.
  ["SN: A83001--UP"] analogs:["7067705010"] |$19.
     706-77-42460   [2]   SPACER, 2.70 mm Komatsu 0.172 kg.
  ["SN: A83001--UP"] analogs:["7067705010"] |$20.
17   04064-06525   [1]   RING Komatsu China 0.021 kg.
  ["SN: A83001--UP"]
18   706-77-43950   [1]   SEAL Komatsu China
  ["SN: A83001--UP"]
19   706-77-43060   [1]   COVER Komatsu 0.81 kg.
  ["SN: A83001--UP"]
20   07000-02125   [1]   O-RING Komatsu OEM 0.005 kg.
  ["SN: A83001--UP"] analogs:["0700002125E", "0700012125"]
21   04071-00130   [1]   RING Komatsu 0.12 kg.
  ["SN: A83001--UP"]
22   706-77-43191   [1]   BLOCK, CYLINDER Komatsu 5.64 kg.
  ["SN: A83001--UP"] analogs:["7068740091"]
23   706-77-43840   [1]   PLATE Komatsu 1 kg.
  ["SN: A83001--UP"] analogs:["7067743850"]
24   708-18-13230   [1]   PIN Komatsu 0.01 kg.
  ["SN: A83001--UP"]
25   706-77-43080   [1]   SHAFT, CENTER Komatsu 0.6 kg.
  ["SN: A83001--UP"]
26   706-77-42130   [1]   RING, CENTER Komatsu 0.1 kg.
  ["SN: A83001--UP"]
27   706-77-42110   [1]   SPRING Komatsu 0.23 kg.
  ["SN: A83001--UP"]
     706-77-05050   [1]   KIT, RETAINER Komatsu 0.281 kg.
  ["SN: A83001--UP"] |$32.
28   706-77-43260   [1]   RETAINER Komatsu 0.281 kg.
  ["SN: A83001--UP"] analogs:["7067705050"]
29   706-75-41271   [7]   SCREW Komatsu 0.004 kg.
  ["SN: A83001--UP"]
30   706-77-42160   [7]   PISTON Komatsu 0.46 kg.
  ["SN: A83001--UP"]
31   706-77-91540   [7]   PLATE Komatsu 0.26 kg.
  ["SN: A83001--UP"]
32   706-77-91550   [3]   DISC Komatsu 0.28 kg.
  ["SN: A83001--UP"]
33   706-77-91580   [1]   PISTON Komatsu 2.5 kg.
  ["SN: A83001--UP"]
34   07000-15180   [1]   O-RING Komatsu China 0.025 kg.
  ["SN: A83001--UP"] analogs:["0700005180"]
35   708-8H-15220   [1]   O-RING Komatsu 0.025 kg.
  ["SN: A83001--UP"]
36   706-77-91510   [6]   SPRING Komatsu China
  ["SN: A83001--UP"]
702-77-04102 2 RELIEF VALVE
Parts on group :
Pos. Part No Qty Parts name Comments
     706-77-01271   [1]   MOTOR ASS'Y Komatsu 101.401 kg.
  ["SN: 33001-UP"] analogs:["7067701270"] |1.
     706-77-01170   [1]   MOTOR ASS'Y Komatsu 98.751 kg.
  ["SN: 30001-32999"] |1.
        706-77-03130   [1]   MOTOR SUB ASS'Y Komatsu China
  ["SN: 33001-UP"] |1.
        706-77-03070   [1]   MOTOR SUB ASS'Y Komatsu China
  ["SN: 30001-32999"] |1.
1   706-77-43210   [1]   CASE,MOTOR Komatsu 21.001 kg.
  ["SN: 30001-UP"]
2   706-77-72610   [1]   HOUSING Komatsu 30 kg.
  ["SN: 33001-UP"]
     706-77-72510   [1]   HOUSING Komatsu 33 kg.
  ["SN: 30001-32999"] |2.
3   706-75-42830   [1]   PIN,DOWEL Komatsu 0.02 kg.
  ["SN: 30001-UP"]
4   706-77-72170   [2]   PLUG Komatsu 0.115 kg.
  ["SN: 30001-UP"]
5   07002-12434   [2]   O-RING Komatsu China 0.01 kg.
  ["SN: 30001-UP"] analogs:["0700202434", "0700213434"]
5A.   706-73-71450   [1]   PLUG Komatsu 0.035 kg.
  ["SN: 33001-UP"]
5B.   07002-11423   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: 33001-UP"] analogs:["0700201423"]
6   706-7G-40010   [1]   BEARING Komatsu 0.032 kg.
  ["SN: 30001-UP"]
7   706-7E-11440   [1]   O-RING Komatsu 0.008 kg.
  ["SN: 30001-UP"]
8   706-77-43180   [8]   BOLT Komatsu China
  ["SN: 30001-UP"]
9   706-77-43860   [1]   SHAFT Komatsu 6.581 kg.
  ["SN: 30001-UP"]
10   706-77-43880   [1]   BEARING Komatsu 5.5 kg.
  ["SN: 30001-UP"] analogs:["7067743890"]
11   706-77-42890   [1]   BEARING Komatsu 1.185 kg.
  ["SN: 30001-UP"]
12   706-77-42051   [2]   SPRING Komatsu 0.14 kg.
  ["SN: 30001-UP"]
13   706-77-42041   [1]   SEAT Komatsu 0.1 kg.
  ["SN: 30001-UP"]
14   706-77-05010   [1]   SPACER KIT Komatsu 0.172 kg.
  ["SN: 30001-UP"]
15   04064-06525   [1]   RING,SNAP Komatsu China 0.021 kg.
  ["SN: 30001-UP"]
16   706-77-43950   [1]   SEAL,OIL Komatsu China
  ["SN: 30001-UP"]
17   706-77-43060   [1]   COVER Komatsu 0.81 kg.
  ["SN: 30001-UP"]
18   07000-02125   [1]   O-RING Komatsu OEM 0.005 kg.
  ["SN: 30001-UP"] analogs:["0700002125E", "0700012125"]
19   04071-00130   [1]   RING,SNAP Komatsu 0.12 kg.
  ["SN: 30001-UP"]
20   706-77-43191   [1]   BLOCK,CYLINDER Komatsu 5.64 kg.
  ["SN: 30001-UP"] analogs:["7068740091"]
21   706-77-43840   [1]   PLATE,VALVE Komatsu 1 kg.
  ["SN: 30001-UP"] analogs:["7067743850"]
22   708-18-13230   [1]   PIN Komatsu 0.01 kg.
  ["SN: 30001-UP"]
23   706-77-43080   [1]   SHAFT,CENTER Komatsu 0.6 kg.
  ["SN: 30001-UP"]
24   706-77-42130   [1]   RING,CENTER Komatsu 0.1 kg.
  ["SN: 30001-UP"]
25   706-77-42110   [1]   SPRING Komatsu 0.23 kg.
  ["SN: 30001-UP"]
     706-77-05050   [1]   RETAINER KIT Komatsu 0.281 kg.
  ["SN: 30001-UP"] |26.
28   706-77-42160   [7]   PISTON SUB ASS'Y Komatsu 0.46 kg.
  ["SN: 30001-UP"]
29   706-77-91540   [5]   PLATE Komatsu 0.26 kg.
  ["SN: 30001-UP"]
30   706-77-91550   [3]   DISC Komatsu 0.28 kg.
  ["SN: 30001-UP"]
31   706-77-91580   [1]   PISTON,BRAKE Komatsu 2.5 kg.
  ["SN: 30001-UP"]
32   07000-15180   [1]   O-RING Komatsu China 0.025 kg.
  ["SN: 30001-UP"] analogs:["0700005180"]
33   708-8H-15220   [1]   O-RING Komatsu 0.025 kg.
  ["SN: 30001-UP"]
34   706-77-91510   [6]   SPRING Komatsu China
  ["SN: 30001-UP"]
