PC200-6 LMF45
PC200-5C PC200-5Z PC200LC-5C PC220-5C PC220-5C PC220LC-5C
PC200-6 PC200-6H PC200-6J PC200-6S PC200-6Z PC200LC-6 PC200LC-6H PC200LC-6J PC200LC-6S PC200LC-6Z PC220-6Z
PC210-6 PC210-6G PC210LC-6 PC210LC-6G
PC220-6 PC220LC-6 PC220LC-6Z
PC230-6 PC230LC-6 706-75-01100 706-75-01101 706-75-03021 706-75-03022 |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
706-75-01101 |
[1] |
MOTOR ASS'Y Komatsu
|
50 kg. |
|
["SN: 80321-94998"] analogs:["7067501100"] |$2. |
| |
706-75-01100 |
[1] |
MOTOR ASS'Y Komatsu
|
50 kg. |
|
["SN: 80001-80320"] analogs:["7067501101"] |$3. |
| |
|
[-1] |
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1640-01A0 TO Y1640-03A0.
|
|
|
|$$3. |
| |
706-75-03022 |
[1] |
MOTOR SUB ASS'Y Komatsu China
|
|
|
["SN: 80321-@"] |$5. |
| |
706-75-03021 |
[1] |
MOTOR SUB ASS'Y Komatsu China
|
|
|
["SN: 80001-80320"] |$6. |
| 1 |
07000-05200 |
[1] |
O-RING Komatsu
|
0.023 kg. |
|
["SN: 80001-@"] analogs:["0700015200", "0700001520"] |
| 2 |
01252-61440 |
[8] |
BOLT Komatsu China
|
|
|
["SN: 80321-@"] analogs:["0125231440"] |
| 2 |
706-87-50360 |
[8] |
BOLT Komatsu China
|
|
|
["SN: 80001-80320"] |
| 3 |
706-75-42662 |
[1] |
SHAFT Komatsu
|
3.94 kg. |
|
["SN: 80321-@"] |
| 3 |
706-75-42661 |
[1] |
SHAFT Komatsu
|
3.94 kg. |
|
["SN: 80001-80320"] analogs:["7067542662"] |
| 4 |
706-75-42880 |
[1] |
BEARING Komatsu
|
2.42 kg. |
|
["SN: 80001-@"] |
| 5 |
706-76-40890 |
[1] |
BEARING Komatsu
|
0.524 kg. |
|
["SN: 80001-@"] |
| 6 |
706-7E-11260 |
[2] |
SPRING Komatsu
|
0.03 kg. |
|
["SN: 80001-@"] |
| 7 |
706-7E-11270 |
[1] |
SEAT Komatsu
|
0.05 kg. |
|
["SN: 80001-@"] |
| 8 |
706-75-05010 |
[1] |
SPACER KIT Komatsu
|
0.14 kg. |
|
["SN: 80001-@"] |
| 9 |
04064-04518 |
[1] |
RING,SNAP Komatsu China
|
0.007 kg. |
|
["SN: 80001-@"] analogs:["20Y3029190"] |
| 10 |
706-7E-11280 |
[1] |
SEAL Komatsu
|
0.15 kg. |
|
["SN: 80001-@"] |
| 11 |
706-75-42711 |
[1] |
COVER Komatsu
|
0.49 kg. |
|
["SN: 80001-@"] |
| 12 |
07000-02085 |
[1] |
O-RING Komatsu China
|
0.03 kg. |
|
["SN: 80001-@"] analogs:["0700012085", "YM24321000850"] |
| 13 |
04065-09030 |
[1] |
RING,SNAP Komatsu
|
0.03 kg. |
|
["SN: 80001-@"] analogs:["2324013250", "R0406509030"] |
| 14 |
706-75-41091 |
[1] |
BLOCK,CYLINDER Komatsu
|
2.85 kg. |
|
["SN: 80001-@"] |
| 15 |
706-75-42740 |
[1] |
PLATE,VALVE Komatsu
|
0.5 kg. |
|
["SN: 80001-@"] |
| 16 |
04020-00820 |
[1] |
PIN Komatsu
|
0.056 kg. |
|
["SN: 80001-@"] analogs:["802540092"] |
| 17 |
706-75-42180 |
[1] |
SHAFT,CENTER Komatsu China
|
|
|
["SN: 80001-@"] |
| 18 |
706-75-41130 |
[1] |
RING,CENTER Komatsu China
|
|
|
["SN: 80001-@"] |
| 19 |
706-75-41220 |
[1] |
BALL,CENTER Komatsu China
|
|
|
["SN: 80001-@"] analogs:["7067540220"] |
| 20 |
706-75-41110 |
[1] |
SPRING Komatsu
|
0.05 kg. |
|
["SN: 80001-@"] |
| |
706-75-05020 |
[1] |
RETAINER KIT Komatsu
|
0.201 kg. |
|
["SN: 80001-@"] |$32. |
| 23 |
706-75-41163 |
[7] |
PISTON SUB ASS'Y Komatsu
|
0.27 kg. |
|
["SN: 80001-@"] |
| 24 |
706-75-92130 |
[1] |
PLATE Komatsu
|
0.38 kg. |
|
["SN: 80001-@"] |
| 25 |
706-75-92141 |
[5] |
PLATE Komatsu
|
0.1 kg. |
|
["SN: 80321-@"] analogs:["7067592140"] |
| 25 |
706-75-92140 |
[5] |
PLATE Komatsu
|
0.1 kg. |
|
["SN: 80001-80320"] analogs:["7067592141"] |
| 26 |
706-75-92150 |
[4] |
DISK Komatsu
|
0.08 kg. |
|
["SN: 80001-@"] |
| 27 |
706-75-92180 |
[1] |
PISTON,BRAKE Komatsu China
|
|
|
["SN: 80001-@"] |
| 28 |
07000-15155 |
[1] |
O-RING Komatsu China
|
0.017 kg. |
|
["SN: 80001-@"] analogs:["0700005155E", "0700005155"] |
| 29 |
07000-15175 |
[1] |
O-RING Komatsu China
|
0.03 kg. |
|
["SN: 80001-@"] analogs:["0700005175"] |
| 30 |
706-75-92170 |
[6] |
SPRING Komatsu China
|
|
|
["SN: 80321-@"] analogs:["7067592160"] |
| 30 |
706-75-92160 |
[6] |
SPRING Komatsu China
|
|
|
["SN: 80001-80320"] analogs:["7067592170"] |
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
706-75-01101 |
[1] |
MOTOR ASS'Y Komatsu
|
50 kg. |
|
["SN: 94999-96513"] analogs:["7067501100"] |$1. |
| |
|
[-1] |
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1640-01A0A T0 Y1640-03A0A .
|
|
|
|$$2. |
| |
702-75-01201 |
[2] |
VALVE ASS'Y,RELIEF Komatsu
|
0.68 kg. |
|
["SN: 80321-96513"] analogs:["7027501200"] |$3. |
| 10 |
07000-F2020 |
[1] |
O-RING Komatsu China
|
0.001 kg. |
|
["SN: 80321-@"] analogs:["0700022020"] |
| 11 |
07001-02020 |
[1] |
RING,BACK-UP Komatsu
|
0.001 kg. |
|
["SN: 80001-@"] |
| 12 |
07002-13034 |
[1] |
O-RING Komatsu China
|
0.005 kg. |
|
["SN: 80001-@"] analogs:["0700203034"] |
| 13. |
706-77-72170 |
[2] |
PLUG Komatsu
|
0.115 kg. |
|
["SN: 80001-96513"] |
| 14. |
07002-12434 |
[2] |
O-RING Komatsu China
|
0.01 kg. |
|
["SN: 80001-96513"] analogs:["0700202434", "0700213434"] |
