Nabtesco GM40VD TM40VD hydraulic final drive motor parts used for Daewoo DH225-7 DH225-9，Kato HD1250，Hyundai R220 R265-7 excavator

Nabtesco GM40VD TM40VD hydraulic final drive motor parts used for Daewoo DH225-7 DH225-9，Kato HD1250，Hyundai R220 R265-7 excavator

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
GM40VD TM40VD DX215-9
DX200A DX210 DX220A DX220AF DX225LC DX225LC-3 DX225LC-5 DX225LCA DX225NLCA DX235NLC-5 DX255LC-3 DX255LC-5 DX260LCA
K9007407 400701-00004
Pos. Part No Qty Parts name Comments
*. K9008310 [1]   SEAL KIT;TRAVEL MOTOR
1 *NA00915 [1]   REAR FLANGE
200 K9007407 [1]   CYL BLOCK & PISTON KIT   400701-00004
200 400701-00004 [1]
202 K9007415A [1]
202 K9007415 [1]   SHAFT;DRIVE   K9007415A
203 K9007382 [1]   PLATE;SWASH
204 K9007397 [1]   BLOCK;CYLINDER
205 K9007406 [1]   PISTON ASS'Y
205 K9007406A [1]
207 K9004447 [1]   PLATE;RETAINER
208 K9004448 [1]   BALL;THRUST
209 K9007398A [1]
209 K9007398 [1]   PLATE;TIMING
212 K9004453 [1]   PISTON;PARKING
213 1.131-00049A [12]   SPRING
213 1.131-00049 [12]   SPRING
214 K9004449 [1]   SPRING
215 412-00013 [2]   PLATE,FRICTION
216 352-00014 [2]   PLATE,SEPARATION
23 K9007399 [1]   MAIN SPOOL
23 410207-00163 [1]
23 410207-00163A [1]
23 410207-00307 [1]   SPOOL,MAIN
232 K9007401 [1]   SEAL;OIL
235 S8001801 [1]   O-RING
239 S8002101 [1]   O-RING
24 1.181-00059 [2]   PLUG;FOR MAIN
242 1.123-00053 [4]   PIN,PARALLEL
247 S8061800 [1]   RING;BACK UP
248 S8062100 [1]   RING;BACK UP
249 K9007400 [1]   BEARING;BALL
25 110956-00071 [2]
250 1.109-00026 [1]   BEARING;BALL
26 1.181-00067 [2]   PLUG;CHECK
260 1.409-00180 [1]   PISTON KIT;2 SPEED
260 130602-00200 [1]
261 1.131-00042 [1]   SPRING
261 111601-00117 [1]
267 1.540-00006 [2]   PIVOT
27 1.420-00013 [2]   VALVE;CHECK
275 S8000081 [2]   O-RING
28 1.131-00058 [2]   SPRING;FOR MAIN
30 1.129-00006 [2]   SPRING;CHECK
36 S8000321 [2]   O-RING
37 S8002731 [2]   O-RING
400 K9007413 [2]   RELIEF VALVE ASS'Y
400 410127-00058 [2]
400 410127-00058A [2]   410127-00190
400 410127-00190 [2]   VALVE ASSY,RELIEF
401 *NA00890 [1]   . PLUNGER
402 1.180-00527 [1]   SEAL;PISTON
403 *NA00079 [1]   BODY
404 S8060161 [2]   RING;BACK-UP
405 S8000161 [3]   O-RING
406 S8010291 [1]   O-RING
407 *NA00926 [1]
408 *NA01182 [1]   . SPRING
409 *NA00796 [1]   PISTON
41 S5700891 [1]   PIN;PARALLEL
410 S8000221 [2]   O-RING
411 S8060221 [3]   RING;BACK UP
412 *NA00865 [1]   PLUG,ADJUST
413 *NA00628 [1]   NUT,LOCK
43 S2221471 [12]   BOLT,SOCKET
46 S8000181 [2]   O-RING
52 2181-1890D2 [2]   PLUG
52 2181-1890D2 [4]   PLUG
54 181-00318 [5]   BOLT;SOCKER
55 2181-1116D2 [2]   PLUG
63 2181-1890D4 [2]   PLUG
65 1.424-00041 [1]   SPOOL;2 SPEED
66 1.131-00001 [1]   SPRING   111601-00354
66 111601-00354 [1]   SPRING
68 S6250182 [2]   BALL
71 1.415-00005 [1]   ORIFICE
74 S8000111 [2]   O-RING
74 S8000111 [4]   O-RING
79 1.471-00001 [1]   FILTER
79 1.471-00001A [1]   FILTER
91 2181-1116D1 [2]   PLUG
C. K9007410 [1]   CONTROL PART ASS'Y   300609-00069
C. 300609-00069 [1]
C-1. K9007408 [1]   REAR FLANGE ASS'Y
C-1. K9007408A [1]   430215-00552
C-1. 430215-00552 [1]
C-2. K9007409 [1]   REAR FLANGE KIT
C-2. K9007409A [1]
C-3. 110956-00060 [2]   STOPPER
