NABTESCO GM35VL travel motor parts For Doosan Solar 220LC-7A excavator

NABTESCO GM35VL travel motor parts For Doosan Solar 220LC-7A excavator

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
401-00454-A 300506-00054 ROTARY GROUP 671B2205-00 SOLAR 220LC-V SOLAR 220LL SOLAR 225LC-7A SOLAR 225LC-V SOLAR 225LL
Pos. Part No Qty Parts name Comments
*. 2401-9287KT [1]   SEAL KIT
-. 401-00454-A [2]
-. 300506-00054 [1]
100 1.409-00173 [1]
102 1.405-00023 [1]
103 1.412-00142 [1]
104 1.451-00048 [1]
107 1.412-00092 [1]   PLATE;RETAINER
108 1.148-00015 [1]   BALL;THRUST
109 1.412-00168 [1]
110 1.114-00286 [2]   WASHER
111 1.114-00006 [1]
112 1.409-00196 [1]
113 1.131-00049 [12]   SPRING
114 1.131-00048 [1]   SPRING
115 1.412-00059 [2]
116 1.412-00070 [2]
132 1.180-00521 [1]   SEAL;OIL
135 1.180-00145 [1]
139 1.180-00146 [1]
145 S6510620 [1]   RING;SNAP
149 1.109-00029 [1]   BEARING;BALL
150 1.109-00026 [1]   BEARING;BALL
151 1.109-00134 [5]   ROLLER
160 1.409-00180 [1]   PISTON KIT;2 SPEED
167 1.540-00006 [2]   PIVOT
171 1.123-00053 [2]   PIN,PARALLEL
193 1.131-00042 [1]   SPRING
200 1.420-00119 [2]   RELIEF VALVE ASS'Y
201 1.420-00011 [1]
202 1.425-00004 [1]   SLEEVE
203 1.115-00010 [1]   RETAINER;SPRING
204 1.181-00063 [1]   PLUG
205 1.114-00016 [1]   SHIM
206 1.131-00050 [1]   SPRING
208 S8000161 [1]   O-RING
209 S8000221 [1]   O-RING
210 S8000181 [1]   O-RING
211 S8060161 [2]   RING;BACK-UP
217 S8060221 [2]   RING;BACK UP
219 S8000291 [1]   O-RING
220 1.180-00527 [1]   SEAL;PISTON
300 674B4101-00-B [1]   REAR FLANGE KIT
300A. *NA00915 [1]   REAR FLANGE
300B. 1.424-00024 [1]   SPOOL
300C. 2.409-00058 [1]   PISTON
324 1.181-00059 [2]   PLUG;FOR MAIN
325 1.416-00009 [2]   STOPPER
326 1.181-00067 [2]   PLUG;CHECK
327 1.420-00013 [2]   VALVE;CHECK
328 1.131-00058 [2]   SPRING;FOR MAIN
330 1.129-00006 [2]   SPRING;CHECK
336 S8000321 [2]   O-RING
337 S8002731 [2]   O-RING
341 S5700891 [1]   PIN;PARALLEL
343 S2221471 [12]   BOLT,SOCKET
346 2181-1116D2 [4]   PLUG
352 2181-1890D2 [2]   PLUG
354 2.181-00370 [8]   PLUG
355 S8000181 [2]   O-RING
357 2181-1890D4 [2]   PLUG
358 S8000111 [2]   O-RING
359 S8000141 [2]   O-RING
363 1.424-00041 [1]   SPOOL;2 SPEED
366 1.131-00001 [1]   SPRING
368 S6250182 [2]   BALL
379 1.471-00001 [1]   FILTER
380 2.181-00460 [2]   PLUG
382 1.181-00062 [2]   PLUG
383 S8000051 [2]   O-RING
384 S8000081 [2]   O-RING
385 1.148-00012 [2]   BALL;STEEL
397 1.415-00005 [1]   ORIFICE
398 2181-1116D1 [4]   PLUG
99 671B2205-00 [1]   CYLINDER & PISTON KIT
