Nabtesco GM35VL hydraulic final drive motor rotary group and spare parts

Nabtesco GM35VL hydraulic final drive motor rotary group and spare parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
GM35VL R210LC-7 (EM140 & ￠25.5)
31N6-40010 31N6-40011 31EM-40011 XKAH-00373 XKAH-00455 CYLINDER KIT&PISTON KIT XKAH-00321 R210LC-3 R210LC-3H R210LC-7 R210NLC-7
Komatsu PC200-6 PC200-7 PC200-8
Hyundai R210-5 R210-7,Volvo EC210 EC240B,Daewoo DH220-3 DH220-5 DH225-5,Kobelco SK200-6 excavator
Pos. Part No Qty Parts name Comments
*. @ [1]   TRAVEL MOTOR ASSY      SEE ILLUST
*-1. @ [1]   TRAVEL MOTOR UNIT      SEE 4150
*-6. XKAH-00321 [1]   C/BLOCK & PISTON KIT
K*61. XKAH-00068 [1]   PISTON ASSY
N105. XKAH-00069 [9]   PISTON
N106. XKAH-00070 [9]   SHOE
104 XKAH-00071 [1]   BLOCK-CYLINDER
107 XKAH-00072 [1]   PLATE-RETAINER
108 XKAH-00073 [1]   BALL-THRUST
110 XKAH-00074 [2]   WASHER
111 XKAH-00318 [1]   COLLAR
114 XKAH-00076 [1]   SPRING
145 XKAH-00091 [1]   RING-SNAP
151 XKAH-00077 [5]   ROLLER
102 XKAH-00081 [1]   SHAFT-MAIN
103 XKAH-00082 [1]   PLATE-SWASH
109 XKAH-00083 [1]   PLATE-TIMING
112 XKAH-00084 [1]   PISTON-PARKING
113 XKAH-00085 [12]   SPRING
115 XKAH-00086 [2]   PLATE-FRICTION
116 XKAH-00087 [2]   PLATE-MATING
K132. XKAH-00088 [1]   SEAL-OIL
K135. XKAH-00089 [1]   O-RING
K139. XKAH-00090 [1]   O-RING
149 XKAH-00092 [1]   BEARING-BALL
150 XKAH-00093 [1]   BEARING-BALL
167 XKAH-00095 [2]   PIVOT
171 XKAH-00034 [2]   PIN-PARALLEL
193 XKAH-00094 [1]   SPRING
*-7. XKAH-00078 [1]   PISTON KIT-2 SPEED
N161. XKAH-00079 [1]   PISTON-2 SPEED
N162. XKAH-00080 [1]   SHOE-2 SPEED
N. @ [AR]   NOT INDIVIDUALLY SUPPLIED
K. XKAH-00111 [1]   SEAL KIT      SEE ILLUST
Pos. Part No Qty Parts name Comments
*. 31N6-40010 [1]   TRAVEL MOTOR ASSY
*. 31N6-40011 [1]   TRAVEL MOTOR ASSY      SEE ILLUST
*. 31EM-40011 [1]   TRAVEL MOTOR ASSY      SEE 4300-4310
*. 31N6-40011 [1]   TRAVEL MOTOR ASSY      SEE ILLUST,4151
N*-1. XKAH-00373 [1]   TRAVEL MOTOR UNIT
N*-1. XKAH-00455 [1]   TRAVEL MOTOR UNIT      SEE 4300-4310
N*-1. XKAH-00373 [1]   TRAVEL MOTOR UNIT
*-8. XKAH-00096 [2]   RELIEF VALVE ASSY
*-81. XKAH-00097 [2]   RELIEF VALVE KIT
201 XKAH-00098 [2]   VALVE
202 XKAH-00099 [2]   SLEEVE
203 XKAH-00100 [2]   RETAINER-SPRING
204 XKAH-00101 [2]   PLUG
205 XKAH-00102 [2]   SHIM
206 XKAH-00103 [2]   SPRING
K208. XKAH-00104 [2]   O-RING
K209. XKAH-00105 [2]   O-RING
K210. XKAH-00035 [2]   O-RING
K211. XKAH-00106 [4]   RING-BACK UP
K217. XKAH-00107 [4]   RING-BACK UP
K219. XKAH-00108 [1]   O-RING
K220. XKAH-00109 [1]   SEAL-PISTON
*-5. XKAH-00036 [1]   REAR FLANGE ASSY
*-51. XKAH-00374 [1]   REAR FLANGE KIT
301 XKAH-00038 [1]   REAR FLANGE
323 XKAH-00039 [1]   SPOOL
324 XKAH-00041 [2]   PLUG
325 XKAH-00042 [2]   STOPPER
326 XKAH-00043 [2]   PLUG
327 XKAH-00044 [2]   VALVE-CHECK
328 XKAH-00045 [2]   SPRING
330 XKAH-00046 [2]   SPRING
K336. XKAH-00047 [2]   O-RING
K337. XKAH-00048 [2]   O-RING
341 XKAH-00065 [1]   PIN-PARALLEL
343 XKAH-00066 [12]   BOLT-SOCKET
346 XKAH-00049 [2]   PLUG-PT
352 XKAH-00050 [2]   PLUG-RO
354 XKAH-00051 [8]   PLUG-NPTF
K355. XKAH-00035 [2]   O-RING
357 XKAH-00032 [2]   PLUG-RO
K358. XKAH-00052 [2]   O-RING
K359. XKAH-00053 [2]   O-RING
363 XKAH-00054 [1]   SPOOL-2 SPEED
366 XKAH-00055 [1]   SPRING
368 XKAH-00056 [2]   BALL-STEEL
379 XKAH-00057 [1]   FILTER
380 XKAH-00058 [2]   PLUG
381 XKAH-00040 [1]   PISTON
382 XKAH-00059 [2]   PLUG
K383. XKAH-00060 [2]   O-RING
K384. XKAH-00027 [2]   O-RING
385 XKAH-00061 [2]   BALL-STEEL
397 XKAH-00062 [1]   ORIFICE
398 XKAH-00063 [4]   PLUG-PT
399 XKAH-00064 [1]   PLATE-NAME
N. @ [AR]   NOT SUPPLIED PARTS



401-00454-A 300506-00054 ROTARY GROUP 671B2205-00 SOLAR 220LC-V SOLAR 220LL SOLAR 225LC-7A SOLAR 225LC-V SOLAR 225LL
Pos. Part No Qty Parts name Comments
*. 2401-9287KT [1]   SEAL KIT
-. 401-00454-A [2]
-. 300506-00054 [1]
100 1.409-00173 [1]
102 1.405-00023 [1]
103 1.412-00142 [1]
104 1.451-00048 [1]
107 1.412-00092 [1]   PLATE;RETAINER
108 1.148-00015 [1]   BALL;THRUST
109 1.412-00168 [1]
110 1.114-00286 [2]   WASHER
111 1.114-00006 [1]
112 1.409-00196 [1]
113 1.131-00049 [12]   SPRING
114 1.131-00048 [1]   SPRING
115 1.412-00059 [2]
116 1.412-00070 [2]
132 1.180-00521 [1]   SEAL;OIL
135 1.180-00145 [1]
139 1.180-00146 [1]
145 S6510620 [1]   RING;SNAP
149 1.109-00029 [1]   BEARING;BALL
150 1.109-00026 [1]   BEARING;BALL
151 1.109-00134 [5]   ROLLER
160 1.409-00180 [1]   PISTON KIT;2 SPEED
167 1.540-00006 [2]   PIVOT
171 1.123-00053 [2]   PIN,PARALLEL
193 1.131-00042 [1]   SPRING
200 1.420-00119 [2]   RELIEF VALVE ASS'Y
201 1.420-00011 [1]
202 1.425-00004 [1]   SLEEVE
203 1.115-00010 [1]   RETAINER;SPRING
204 1.181-00063 [1]   PLUG
205 1.114-00016 [1]   SHIM
206 1.131-00050 [1]   SPRING
208 S8000161 [1]   O-RING
209 S8000221 [1]   O-RING
210 S8000181 [1]   O-RING
211 S8060161 [2]   RING;BACK-UP
217 S8060221 [2]   RING;BACK UP
219 S8000291 [1]   O-RING
220 1.180-00527 [1]   SEAL;PISTON
300 674B4101-00-B [1]   REAR FLANGE KIT
300A. *NA00915 [1]   REAR FLANGE
300B. 1.424-00024 [1]   SPOOL
300C. 2.409-00058 [1]   PISTON
324 1.181-00059 [2]   PLUG;FOR MAIN
325 1.416-00009 [2]   STOPPER
326 1.181-00067 [2]   PLUG;CHECK
327 1.420-00013 [2]   VALVE;CHECK
328 1.131-00058 [2]   SPRING;FOR MAIN
330 1.129-00006 [2]   SPRING;CHECK
336 S8000321 [2]   O-RING
337 S8002731 [2]   O-RING
341 S5700891 [1]   PIN;PARALLEL
343 S2221471 [12]   BOLT,SOCKET
346 2181-1116D2 [4]   PLUG
352 2181-1890D2 [2]   PLUG
354 2.181-00370 [8]   PLUG
355 S8000181 [2]   O-RING
357 2181-1890D4 [2]   PLUG
358 S8000111 [2]   O-RING
359 S8000141 [2]   O-RING
363 1.424-00041 [1]   SPOOL;2 SPEED
366 1.131-00001 [1]   SPRING
368 S6250182 [2]   BALL
379 1.471-00001 [1]   FILTER
380 2.181-00460 [2]   PLUG
382 1.181-00062 [2]   PLUG
383 S8000051 [2]   O-RING
384 S8000081 [2]   O-RING
385 1.148-00012 [2]   BALL;STEEL
397 1.415-00005 [1]   ORIFICE
398 2181-1116D1 [4]   PLUG
99 671B2205-00 [1]   CYLINDER & PISTON KIT
