M5X130 swing motor parts

M5X130 swing motor parts

$1,000.00 USD
$1,000.00 USD
特價 售罄
結帳時計算運費。

Hitachi ZAX160-1/3 ZAX180W ZAX190W-3 ZAX200-1/3 ZAX220W-3 ZAX230-3 ZAX240-1/3 ZAX250-1/3 EX280
Caterpillar CAT320C/D CAT323C/D CAT324
Volvo EC210 EC460 ECR235C
Kobelco SK200-6E SK200-8 SK210-8
Daewoo DH220-5
Sany SY485

M5X130
(S=19.4)
ZX160 ZX160LC-3 ZX160W ZX170W-3 ZX180LC ZX180LC-3 ZX180W ZX190W-3 ZX200 ZX200-3 ZX200-3G ZX200-5G ZX210-3 ZX210H ZX210K ZX210K-3 ZX210K-3G ZX210W ZX210W-3 ZX220W-3 ZX225US ZX225US-3 ZX230 ZX240-3 ZX240-3G ZX240-5G  ZX450-3
Pos. Part No Qty Parts name Comments
4610138 [1]   MOTOR;OIL
10 788801 [1]   PISTON ASS'Y
10A. +++++++ [9]   PISTON
10B. +++++++ [9]   SHOE
20 788802 [1]   CASING ASS'Y
20A. +++++++ [1]   CASING
20B. +++++++ [2]   PIN;SPRING
51 4654845 [2]   VALVE;RELIEF
51A. A811030 [2]   O-RING
80 788803 [1]   PLUNGER
101 788804 [1]   SHAFT
111 788805 [1]   CYLINDER
114 788806 [1]   SPRING;PLATE
123 788807 [1]   RETAINER
124 788808 [1]   PLATE
131 788809 [1]   PLATE;VALVE
301 788810 [1]   CASING
351 409215 [2]   PLUNGER
355 409216 [2]   SPRING
390 +++++++ [1]   PLATE
391 625509 [2]   PIN
401 365318 [4]   BOLT;SOCKET
443 788811 [1]   BRG.;ROL.
444 677203 [1]   BRG.;ROL.
467 629404 [2]   PLUG
469 692708 [2]   PLUG
472 425115 [1]   O-RING I 1119003
472 1119003 [1]   O-RING
487 957366 [2]   O-RING
488 4506428 [2]   O-RING
491 788813 [1]   SEAL;OIL
702 788814 [1]   PISTON
706 353321 [1]   O-RING
707 425117 [1]   O-RING
712 788815 [24]   SPRING;BRAKE
742 788816 [3]   PLATE;FRICTION
743 788817 [4]   PLATE
807 788818 [1]   SPRING
808 221509 [1]   BALL;STEEL
809 4506407 [1]   O-RING
813 263019 [2]   PLUG
1000 814402 [1]   KIT;SEAL I 1119004
1000 1119004 [1]   KIT;SEAL
VOE14552686 EC200B EC200D EC210B EC210C EC210D EC220D EC220E EC235C EC235D
Pos. Part No Qty Parts name Comments
  VOE14552686   [1]   Swing motor
1   VOE14594933   [1]   Piston
2   VOE14550669   [1]   Casing
3   SA7223-00660   [2]   Spring pin
4   VOE14550664   [1]   Valve
  VOE14594353   [2]   Plug
5   VOE14591508   [2]   Relief valve
6   VOE990582   [1]   O-ring
7   VOE983526   [2]   O-ring
8   VOE14552320   [1]   Seal
9   VOE14512953   [1]   Piston
10   VOE14693875   [1]   O-ring
11   SA8230-25540   [1]   O-ring
12   VOE14529763   [20]   Spring
13   VOE14529762   [3]   Plate
14   VOE14529761   [4]   Plate
15   VOE14594354   [3]   Plug
16   VOE14612051   [1]   Plug
17   VOE14529774   [1]   Shaft
18   VOE14529773   [1]   Cylinder
19   VOE14529772   [1]   Spring
20   VOE14529771   [1]   Plate
21   VOE14529770   [1]   Plate
22   VOE14529769   [1]   Plate
23   VOE14529768   [1]   Casing
24   VOE14552322   [1]   Cover
25   SA8230-14160   [2]   Control plunger
26   SA8230-14150   [2]   Spring
27   SA8230-25820   [4]   Bolt
28   VOE14529766   [1]   Ring
29   SA8230-26520   [1]   Roller bearing
30   VOE14529765   [1]   Bearing
31   SA8230-25680   [2]   Plug
32   VOE14552321   [1]   O-ring
33   VOE14558299   [1]   Valve
34   VOE14550661   [1]   Casing
35   VOE14550218   [2]   Plug
36   SA8230-26191   [2]   O-ring
37   VOE14529757   [2]   O-ring
38   VOE14533603   [2]   O-ring
39   SA8240-03610   [4]   Screw
40   VOE14558298   [2]   Valve
41   VOE983509   [1]   O-ring
42   VOE14625240   [1]   Ring
43   VOE14529759   [1]   Plug
44   VOE14511643   [3]   Screw
100   VOE14552332   [1]   Sealing kit
