LPV28 LPV30-PI hydraulic pump cylinder block rotor barrel 708-1S-13110

LPV28 LPV30-PI hydraulic pump cylinder block rotor barrel 708-1S-13110

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。

PC30-7 PC20MR-7 PC20MR-8  PC25MR-7 PC25MR-8  PC27MR-7 PC27MR-8  PC30MR-7 PC30MR-8 PC35MR-7 PC35MR-8

     708-1S-00150   [1]   PUMP ASS'Y Komatsu China
  ["SN: 10001-11474"] analogs:["7081S01131"] |1.
        708-1S-01131   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 10001-11474"] analogs:["7081S00150"] |1.
1   708-1S-13110   [1]   BLOCK,CYLINDER Komatsu 1.48 kg.
  ["SN: 10001-11474"]
2   708-1S-13221   [1]   VALVE,PLATE Komatsu China
  ["SN: 10001-11474"]
3   708-7S-13530   [2]   SPACER Komatsu China
  ["SN: 10001-11474"]
4   708-1S-13150   [1]   SPRING Komatsu China
  ["SN: 10001-11474"]
5   04065-03212   [1]   RING,SNAP Komatsu 0.002 kg.
  ["SN: 10001-11474"] analogs:["4174317180"]
6   708-1S-13350   [1]   GUIDE,RETAINER Komatsu China
  ["SN: 10001-11474"]
7   708-2L-23360   [3]   PIN Komatsu 0.003 kg.
  ["SN: 10001-11474"]
8   708-1S-13340   [1]   RETAINER,SHOE Komatsu 0.11 kg.
  ["SN: 10001-11474"]
9   708-1S-13310   [7]   PISTON SUB ASS'Y Komatsu 0.071 kg.
  ["SN: 10001-11474"]
10   708-1T-14210   [1]   BOLT,ADJUST Komatsu China
  ["SN: 10001-11474"]
11   07002-13034   [1]   O-RING Komatsu China 0.005 kg.
  ["SN: 10001-11474"] analogs:["0700203034"]
12   708-1T-14311   [1]   PLUG Komatsu China
  ["SN: 10001-11474"]
13   01583-02414   [1]   NUT Komatsu 0.068 kg.
  ["SN: 10001-11474"]
14   07002-12434   [1]   O-RING Komatsu China 0.01 kg.
  ["SN: 10001-11474"] analogs:["0700202434", "0700213434"]
15   708-1T-15141   [1]   PLUG Komatsu China
  ["SN: 10001-11474"]
16   01582-01210   [1]   NUT Komatsu 0.015 kg.
  ["SN: 10001-11474"]
17   07002-11223   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: 10001-11474"] analogs:["0700201223"]
18   708-1T-15121   [1]   SEAT Komatsu China
  ["SN: 10001-11474"]
19   708-1S-14410   [1]   SLIDER Komatsu 0.2 kg.
  ["SN: 10001-11474"]
20   708-1T-15590   [1]   SEAT Komatsu China
