KUBOTA KX161-3 EXCAVATOR RD511-61700 SWIVEL MOTOR ASSY ROTARY GROUP

KUBOTA KX161-3 EXCAVATOR RD511-61700 SWIVEL MOTOR ASSY ROTARY GROUP

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
RD511-61700 KX161-3
Pos. Part No Qty Parts name Comments
10 RD511-61700 [1]   ASSY MOTOR SWIVEL
20 RC411-73330 [1]   BEARING,BALL
30 RD411-73322 [1]   SHAFT
40 58700-11070 [1]   PLATE,THRUST
50 RC411-73470 [1]   WASHER,SPRING
60 RC411-73460 [1]   SPRING
70 RC411-73470 [1]   WASHER,SPRING
80 04611-00370 [1]   CIR-CLIP,INTERNAL
90 RC411-73710 [3]   PIN
100 RC411-73430 [1]   PLATE,RETAINER
110 RC411-73420 [1]   HOLDER RETAINER
120 RC411-73210 [1]   PLATE,FRICTION
130 RC411-73220 [1]   PISTON
140 04811-51100 [1]   RING
150 04811-51300 [1]   O RING
160 RC411-73270 [12]   SPRING
170 RC301-72244 [2]   POPPET
180 RC301-72280 [2]   SPRING
190 RC101-72630 [2]   PLUG
200 04817-00140 [2]   O RING
210 RC301-72290 [2]   PLUG
220 04817-00180 [2]   O RING
230 RD511-72300 [2]   ASSY VALVE,RELIEF
240 04817-00180 [2]   O RING
250 04817-00140 [2]   O RING
260 34076-66250 [4]   RING,BACK UP
262 04817-00060 [2]   O RING
264 RC101-72840 [2]   RING,BACK UP
270 04817-00120 [2]   O RING
280 68551-61420 [4]   RING,BACK UP
282 03650-60816 [2]   SCREW,SET
284 02052-60080 [2]   NUT
290 RC411-72213 [1]   COVER
300 15521-96030 [2]   PLUG
310 08101-06203 [1]   BEARING,BALL
320 RC411-73450 [1]   PLATE,VALVE
330 05012-00410 [1]   PIN,STRAIGHT
340 05012-00612 [2]   PIN, STRAIGHT
350 05012-00818 [2]   PIN,STRAIGHT
360 04811-51450 [1]   RING
370 04817-00220 [2]   O RING
380 RC411-73520 [5]   BOLT,HEX-SOC-HD
390 RC411-73510 [1]   O RING
400 RC411-73520 [2]   BOLT,HEX-SOC-HD
410 RC411-73532 [1]   FILTER
420 68811-17430 [1]   PLUG      <=20661
420 RC411-72660 [1]   PLUG      >=20662
430 04817-00110 [1]   O RING
440 01138-51640 [7]   BOLT,SEMS
450 RD411-73550 [1]   KIT SEAL
460 RP821-73560 [1]   ASSY BLOCK,CYLINDER
470 RD411-73570 [1]   ASSY HOUSING SWING
