KUBOTA KX121-3 EXCAVATOR RD118-61700 SWIVEL MOTOR ASSY PARTS

KUBOTA KX121-3 EXCAVATOR RD118-61700 SWIVEL MOTOR ASSY PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
RD118-61700 KX121-3
Pos. Part No Qty Parts name Comments
10 RD118-61700 [1]   ASSY MOTOR SWIVEL
20 RC411-73330 [1]   BEARING,BALL
30 RC411-73323 [1]   SHAFT
40 04612-00220 [1]   CIR-CLIP,EXTERNAL
50 58700-11070 [1]   PLATE,THRUST
60 RC411-73470 [1]   WASHER,SPRING
70 RC411-73460 [1]   SPRING
80 RC411-73470 [1]   WASHER,SPRING
90 04611-00370 [1]   CIR-CLIP,INTERNAL
100 RC411-73710 [3]   PIN
110 RC411-73430 [1]   PLATE,RETAINER
120 RC411-73420 [1]   HOLDER RETAINER
130 RC411-73210 [1]   PLATE,FRICTION
140 RC411-73220 [1]   PISTON
150 04811-51100 [1]   RING
160 04811-51300 [1]   O RING
165 RC411-73314 [1]   HOUSING MOTER VALVE
170 RC411-73270 [12]   SPRING
180 RC301-72244 [2]   POPPET
190 RC301-72280 [2]   SPRING
200 RC101-72630 [2]   PLUG
210 04817-00140 [2]   O RING
230 RC301-72290 [2]   PLUG
240 04817-00180 [2]   O RING
250 RD118-72300 [2]   ASSY VALVE,RELIEF
260 04817-00180 [2]   O RING
270 04817-00140 [2]   O RING
280 34076-66250 [4]   RING,BACK UP
290 04817-00060 [2]   O RING
300 RC101-72840 [2]   RING,BACK UP
320 04817-00120 [2]   O RING
330 68551-61420 [4]   RING,BACK UP
340 03650-60816 [2]   SCREW,SET
350 02052-60080 [2]   NUT
360 RC411-72213 [1]   COVER
370 68311-13350 [2]   PLUG      <=20943
370 15521-96030 [2]   PLUG      >=20944
380 08101-06203 [1]   BEARING,BALL
390 RC411-73450 [1]   PLATE,VALVE
400 05012-00410 [1]   PIN,STRAIGHT
410 05012-00612 [2]   PIN, STRAIGHT
420 05012-00818 [2]   PIN,STRAIGHT
430 04811-51450 [1]   RING
440 04817-00220 [2]   O RING
450 RC411-73520 [5]   BOLT,HEX-SOC-HD
460 RC411-73510 [1]   O RING
470 RC411-73520 [2]   BOLT,HEX-SOC-HD
480 RC411-73532 [1]   FILTER
490 04811-00140 [1]   RING
510 01138-51440 [6]   BOLT,SEMS
520 RP821-73560 [1]   ASSY BLOCK,CYLINDER
530 RD411-73570 [1]   ASSY HOUSING SWING
540 RC411-73550 [1]   KIT SEAL
