KUBOTA KX121-3 EXCAVATOR RD118-61114 RD118-61115 HYDRAULIC PISTON PUMP ASSY PARTS

KUBOTA KX121-3 EXCAVATOR RD118-61114 RD118-61115 HYDRAULIC PISTON PUMP ASSY PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
RD118-61114 RD118-61115 KX121-3
Pos. Part No Qty Parts name Comments
10 RD118-61114 [1]   ASSY PUMP PISTON
10 RD118-61115 [1]   ASSY PUMP,PISTON
20 RP801-79080 [1]   BEARING,NEEDLE
30 RD411-69210 [1]   BEARING,NEEDLE
40 RP401-79090 [1]   SEAL,OIL
50 04611-00420 [1]   CIR-CLIP,INTERNAL
60 RD411-69360 [1]   STOPPER
70 RD118-69220 [1]   SHAFT
80 RD201-69210 [1]   WASHER,THRUST
90 RD101-69560 [1]   WASHER,THRUST
100 RD118-69230 [1]   GASKET
110 68493-71450 [3]   PIN,STRAIGHT
120 04810-00030 [1]   O RING
130 RD118-69240 [2]   BUSH
140 RD411-69250 [2]   BOLT
150 RD118-69260 [1]   PLATE VALVE
160 RD411-69290 [1]   STOPPER
170 RD118-69272 [1]   PIN
180 04810-00080 [6]   O-RING
190 04810-00110 [4]   O - RING 2,4*10,8
200 RD201-69420 [13]   PLUG
210 RD118-69280 [1]   ORIFICE
230 RD118-69322 [1]   SPRING
240 RD118-69332 [1]   SPRING
250 RD118-69340 [2]   SEAT,SPRING
260 RD118-69302 [1]   ASSY VALVE
270 04810-00080 [1]   O-RING
280 04810-00210 [1]   O - RING
285 68651-72450 [1]   PLUG
290 04810-00140 [1]   O RING
300 RD411-69350 [1]   NUT
310 RD118-69400 [1]   PUMP,GEAR
320 01311-10845 [2]   BOLT,SOCKET HEAD
330 04012-50080 [2]   WASHER,PLAIN
340 01311-11235 [6]   BOLT,SOCKET HEAD
350 68651-72380 [2]   PLUG
360 RD118-69500 [1]   ASSY VALVE
370 RP401-70800 [1]   PLUG
380 04810-00080 [1]   O-RING
390 04810-00110 [1]   O - RING 2,4*10,8
400 04810-00200 [1]   O RING
410 04810-07220 [1]   O-RING
420 01311-10625 [2]   BOLT,SOCKET HEAD
430 01311-10645 [2]   BOLT,SOCKET HEAD
435 RD118-69310 [1]   PIN
440 RD118-69390 [1]   PIN
450 RD118-69430 [1]   O-RING
460 RD118-69380 [1]   O RING
465 04810-00140 [1]   O RING
470 RD118-69440 [1]   ORIFICE
480 RD118-69600 [1]   KIT SEAL
490 RD118-69700 [1]   KIT SEAL
500 RD411-69800 [1]   KIT SEAL VALVE
510 RD118-69100 [1]   KIT PLATE
520 RD118-69200 [1]   ASSY CYLINDER
KX121-3
Pos. Part No Qty Parts name Comments
10 68651-70610 [2]   SHAFT
20 68651-70620 [2]   BEARING BALL
30 RD118-78290 [2]   SWASH PLATE
40 RP801-70840 [4]   BALL
50 RD118-78200 [2]   ASSY CYLINDER PISTON
60 68651-70820 [4]   SPRING
80 RD118-78490 [2]   PLATE VALVE
90 68499-72560 [2]   PIN
100 68651-70760 [2]   BEARING,BALL
110 RD118-78400 [2]   ASSY PLATE BASE
120 68493-71540 [4]   SEAT SPRING
130 RD411-78330 [4]   SPRING
140 RD411-78440 [4]   CAP
150 68311-72410 [8]   ORIFICE
160 RD118-78350 [2]   SPRING
170 68651-72450 [2]   PLUG
180 68651-13630 [4]   PLUG
190 68651-72480 [2]   PLUG
200 68671-72410 [8]   ORIFICE
210 01311-11025 [12]   BOLT,SOCKET HEAD
220 68651-72320 [4]   PIN
230 RD411-78380 [2]   ASSY BLOCK RELIEF
240 01311-10835 [6]   BOLT,SOCKET HEAD
250 68651-72380 [4]   PLUG
260 RD118-78430 [4]   PLUG
262 RP401-70800 [4]   PLUG
264 68499-72880 [2]   PLUG
270 RD201-78140 [2]   SEAL,OIL
280 68651-70770 [2]   O RING
290 04810-00070 [4]   O RING
300 04810-00100 [4]   O RING
310 04810-00290 [4]   O RING
320 04810-00140 [8]   O RING
330 04810-00140 [4]   O RING
340 04810-00120 [6]   O RING
350 04810-00110 [4]   O - RING 2,4*10,8
360 04810-00080 [4]   O-RING
370 RD118-78600 [2]   KIT SEAL
