KOMATSU WA600-6 WA600-6R WD600-6 WHEEL LOADER 708-1T-00433 708-1T-01433 FAN PUMP PARTS

Name: KOMATSU WA600-6 WA600-6R WD600-6 WHEEL LOADER 708-1T-00433 708-1T-01433 FAN PUMP PARTS
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

KOMATSU WA600-6 WA600-6R WD600-6 WHEEL LOADER 708-1T-00433 708-1T-01433 FAN PUMP PARTS

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

708-1T-00433 708-1T-01433 WA600-6 WA600-6R WD600-6

Pos.	Part No	Qty	Parts name	Comments
	708-1T-00433	[1]	Pump Assembly Komatsu	27.8 kg.
			["SN: 60982-UP"] analogs:["7081T00431"] \|$0.
	708-1T-01433	[1]	Pump Subassembly Komatsu	27.8 kg.
			["SN: 60982-UP", "SCC: C2"] analogs:["7081T00431", "7081T00433"] \|$1.
	708-1T-04411	[1]	Case Assembly Komatsu China
			["SN: 60982-UP", "SCC: C2"] \|$2.
1	708-1T-11211	[1]	Case Komatsu China
			["SN: 60982-UP", "SCC: C2"]
5	708-1T-13430	[1]	Cam, Rocker Komatsu China
			["SN: 60982-UP", "SCC: C2"]
6	04260-01270	[1]	Ball Komatsu OEM	0.009 kg.
			["SN: 60638-UP", "SCC: C2"]
7	708-3S-14141	[1]	Spacer Komatsu	0.03 kg.
			["SN: 60982-UP", "SCC: C2"] analogs:["7083S14140"]
8	708-1S-13420	[2]	Pin Komatsu China
			["SN: 60638-UP", "SCC: C2"]
9	01252-60616	[1]	Bolt, Hexagon Socket Head Komatsu	0.007 kg.
			["SN: 60638-UP", "SCC: C2"] analogs:["0125230616"]
10	708-1T-33432	[1]	Ball, Retainer Komatsu	0.000 kg.
			["SN: 60982-UP", "SCC: C2"]
11	708-1T-33470	[1]	Ball, Retainer Komatsu China
			["SN: 60982-UP", "SCC: C2"]
12	01252-61240	[4]	Bolt, Hexagon Socket Head Komatsu	0.053 kg.
			["SN: 60638-UP"] analogs:["0125231240"]
13	04020-01024	[2]	Pin, Dowel Komatsu	0.015 kg.
			["SN: 60638-UP", "SCC: C2"] analogs:["PZF890001197"]
14	708-1S-19920	[1]	Plate Komatsu China
			["SN: 60638-UP"]
15	07000-52065	[1]	O-ring Komatsu	0.002 kg.
			["SN: 60982-UP"]
16	01010-61025	[4]	Bolt Komatsu China	0.03 kg.
			["SN: 60982-UP"] analogs:["0101031025", "01010E1025", "0104041025"]
17	01643-31032	[4]	Washer Komatsu	0.054 kg.
			["SN: 60638-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
	708-1T-04421	[1]	Cap Subassembly Komatsu China
			["SN: 60982-UP", "SCC: C2"] \|$20.
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	708-1T-00433	[1]	Pump Assembly Komatsu	27.8 kg.
			["SN: 60982-UP"] analogs:["7081T00431"] \|$0.
	708-1T-01433	[1]	Pump Subassembly Komatsu	27.8 kg.
			["SN: 60982-UP", "SCC: C2"] analogs:["7081T00431", "7081T00433"] \|$1.
1	708-1S-12260	[1]	Bearing Komatsu	0.12 kg.
			["SN: 60982-UP"]
2	720-68-19610	[1]	Pin Komatsu	0.002 kg.
			["SN: 60638-UP", "SCC: C2"]
3	708-7T-05030	[1]	Spacer Kit Komatsu China
			["SN: 60982-UP", "SCC: C2"]
4	708-1S-12280	[1]	Ring, Wear Komatsu	0.001 kg.
			["SN: 60982-UP"]
5	708-1S-12330	[1]	Retainer Komatsu	0.01 kg.
			["SN: 60982-UP"]
6	07000-51006	[1]	O-ring Komatsu	0.001 kg.
			["SN: 60982-UP", "SCC: C2"]
7	07000-52130	[1]	O-ring Komatsu OEM	0.005 kg.
			["SN: 60982-UP", "SCC: C2"] analogs:["0700042130"]
8	708-3T-11310	[1]	Orifice Komatsu China
			["SN: 60982-UP"]
9	708-2L-25480	[1]	Filter Komatsu OEM	0.5 kg.
			["SN: 60982-UP"]
10	708-2H-25390	[1]	O-ring Komatsu	0.63 kg.
			["SN: 60982-UP"]
11	702-21-55620	[1]	Plug Komatsu	0.05 kg.
			["SN: 60638-UP", "SCC: C2"]
12	07040-11409	[1]	Plug Komatsu	0.033 kg.
			["SN: 60638-UP", "SCC: C2"]
13	07002-51423	[2]	O-ring Komatsu	0.03 kg.
			["SN: 60982-UP", "SCC: C2"] analogs:["0700241423"]
14	708-1T-12430	[1]	Shaft Komatsu China
			["SN: 60982-UP"]
15	706-73-40890	[1]	Bearing Komatsu	0.26 kg.
			["SN: 60638-UP", "SCC: C2"] analogs:["7088E12141"]
16	708-1S-12340	[1]	Case Komatsu	0.18 kg.
			["SN: 60638-UP"]
17	708-1T-11980	[1]	Seal, Oil Komatsu	0.03 kg.
			["SN: 60982-UP"]
18	708-1T-19910	[1]	O-ring Komatsu	0.001 kg.
			["SN: 60982-UP"]
19	04065-06220	[1]	Ring, Snap Komatsu	0.013 kg.
			["SN: 60638-UP"]
20	708-1T-13440	[1]	Cylinder Block Komatsu China
			["SN: 60982-UP"]
21	708-1T-13450	[1]	Plate, Valve Komatsu China
			["SN: 60982-UP"]
22	708-1T-13710	[2]	Spacer Komatsu China
			["SN: 60982-UP"]
23	708-3S-13430	[1]	Spring Komatsu	0.07 kg.
			["SN: 60982-UP"]
24	04065-03515	[1]	Ring, Snap Komatsu	0.003 kg.
			["SN: 60982-UP"]
25	708-1T-13690	[1]	Guide, Retainer Komatsu China
			["SN: 60982-UP"]
26	708-1S-13380	[3]	Pin Komatsu	0.06 kg.
			["SN: 60982-UP"]
27	708-1T-13670	[1]	Retainer, Shoe Komatsu China
			["SN: 60982-UP"]
28	708-1S-13520	[10]	Piston Subassembly Komatsu	0.09 kg.
			["SN: 60982-UP", "SCC: C2"]
29	708-3S-14290	[1]	Piston Subassembly Komatsu	0.087 kg.
			["SN: 60982-UP"] analogs:["7081S14230", "7083S14250"]
30	708-1S-14241	[1]	Spring Komatsu	0.01 kg.
			["SN: 60638-UP", "SCC: C2"]
