KOMATSU WA500-7 LOADER HYDRAULIC PUMP FAN PUMP PARTS

Name: KOMATSU WA500-7 LOADER HYDRAULIC PUMP FAN PUMP PARTS
Brand: +8613035309093
Price: 5000.0 USD
Availability: InStock

KOMATSU WA500-7 LOADER HYDRAULIC PUMP FAN PUMP PARTS

$5,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

HYDRAULIC PUMP, FAN PUMP (2/4) (#10001-) WA500-7 S/N 10001-UP Komatsu 708-1T-00590 708-1T-01590 WA500-7

Pos.	Part No	Qty	Parts name	Comments
	708-1T-00590	[1]	Pump Assembly Komatsu China
			["SN: 10001-UP"] \|$0.
	708-1T-01590	[1]	Pump Subassembly Komatsu China
			["SN: 10001-UP", "SCC: C2"] \|$1.
1	708-1T-12430	[1]	Shaft Komatsu China
			["SN: 10001-UP", "SCC: C2"]
2	706-73-40890	[1]	Bearing Komatsu	0.26 kg.
			["SN: 10001-UP", "SCC: C2"] analogs:["7088E12141"]
3	708-1S-12340	[1]	Case Komatsu	0.18 kg.
			["SN: 10001-UP", "SCC: C2"]
4	708-21-12970	[1]	Seal, Oil Komatsu	0.046 kg.
			["SN: 10001-UP"]
5	708-1S-12350	[1]	O-ring Komatsu	0.003 kg.
			["SN: 10001-UP"]
6	04065-06220	[1]	Ring, Snap Komatsu	0.013 kg.
			["SN: 10001-UP"]
7	708-1T-13440	[1]	Cylinder Block Komatsu China
			["SN: 10001-UP", "SCC: C2"]
8	708-1T-13460	[1]	Plate, Valve Komatsu China
			["SN: 10001-UP", "SCC: C2"]
9	708-1T-13710	[2]	Spacer Komatsu China
			["SN: 10001-UP", "SCC: C2"]
10	708-3S-13430	[1]	Spring Komatsu	0.07 kg.
			["SN: 10001-UP", "SCC: C2"]
11	04065-03515	[1]	Ring, Snap Komatsu	0.003 kg.
			["SN: 10001-UP", "SCC: C2"]
12	708-1T-13690	[1]	Guide, Retainer Komatsu China
			["SN: 10001-UP", "SCC: C2"]
13	708-1S-13380	[3]	Pin Komatsu	0.06 kg.
			["SN: 10001-UP", "SCC: C2"]
14	708-1T-13670	[1]	Retainer, Shoe Komatsu China
			["SN: 10001-UP", "SCC: C2"]
15	708-1S-13520	[10]	Piston Subassembly Komatsu	0.09 kg.
			["SN: 10001-UP", "SCC: C2"]
16	708-3S-14290	[1]	Piston Subassembly Komatsu	0.087 kg.
			["SN: 10001-UP", "SCC: C2"] analogs:["7081S14230", "7083S14250"]
17	708-1S-14241	[1]	Spring Komatsu	0.01 kg.
			["SN: 10001-UP", "SCC: C2"]
Pos.	Part No	Qty	Parts name	Comments
	708-1T-00590	[1]	Pump Assembly Komatsu China
			["SN: 10001-UP"] \|$0.
	708-1T-01590	[1]	Pump Subassembly Komatsu China
			["SN: 10001-UP", "SCC: C2"] \|$1.
	708-1T-04660	[1]	Case Assembly Komatsu China
			["SN: 10001-UP", "SCC: C2"] \|$2.
5	708-1S-13490	[1]	Cam, Rocker Komatsu China
			["SN: 10001-UP", "SCC: C2"]
6	04260-01270	[1]	Ball Komatsu OEM	0.009 kg.
			["SN: 10001-UP", "SCC: C2"]
7	708-3S-14141	[1]	Spacer Komatsu	0.03 kg.
			["SN: 10001-UP", "SCC: C2"] analogs:["7083S14140"]
8	708-1S-13420	[2]	Pin Komatsu China
			["SN: 10001-UP", "SCC: C2"]
9	01252-60616	[1]	Bolt, Hexagon Socket Head Komatsu	0.007 kg.
			["SN: 10001-UP", "SCC: C2"] analogs:["0125230616"]
10	708-1T-33432	[1]	Ball, Retainer Komatsu	0.000 kg.
			["SN: 10001-UP", "SCC: C2"]
11	708-1T-33470	[1]	Ball, Retainer Komatsu China
			["SN: 10001-UP", "SCC: C2"]
12	01252-61235	[4]	Bolt, Hexagon Socket Head Komatsu	0.048 kg.
			["SN: 10001-UP", "SCC: C2"] analogs:["801105554", "0125231235"]
13	04020-01024	[2]	Pin, Dowel Komatsu	0.015 kg.
			["SN: 10001-UP", "SCC: C2"] analogs:["PZF890001197"]
14	708-3T-11310	[1]	Orifice Komatsu China
			["SN: 10001-UP", "SCC: C2"]
	708-1T-04680	[1]	Cap Subassembly Komatsu China
			["SN: 10001-UP", "SCC: C2"] \|$17.
17	708-1S-12260	[1]	Bearing Komatsu	0.12 kg.
			["SN: 10001-UP", "SCC: C2"]
18	720-68-19610	[1]	Pin Komatsu	0.002 kg.
			["SN: 10001-UP", "SCC: C2"]
19	708-7T-05030	[1]	Spacer Kit Komatsu China
			["SN: 10001-UP", "SCC: C2"]
20	708-1S-12280	[1]	Ring, Wear Komatsu	0.001 kg.
			["SN: 10001-UP", "SCC: C2"]
21	708-1S-12330	[1]	Retainer Komatsu	0.01 kg.
			["SN: 10001-UP", "SCC: C2"]
22	07000-B1006	[1]	O-ring Komatsu China
			["SN: 10001-UP", "SCC: C2"]
23	07000-B2130	[1]	O-ring Komatsu	0.01 kg.
			["SN: 10001-UP", "SCC: C2"]
24	708-2L-25480	[1]	Filter Komatsu OEM	0.5 kg.
			["SN: 10001-UP"]
25	708-2L-25490	[1]	O-ring Komatsu	0.001 kg.
			["SN: 10001-UP"]
26	702-21-55620	[2]	Plug Komatsu	0.05 kg.
			["SN: 10001-UP"]
27	07002-61423	[2]	O-ring Komatsu	0.001 kg.
			["SN: 10001-UP"] analogs:["7082L23950"]
21	702-21-61500	[1]	Valve, Pilot Komatsu	0.000 kg.
