KOMATSU WA470-6 WA470-6A WA480-6 wheel loader 708-1G-00060 708-1G-01060 loader pump rotary group

Name: KOMATSU WA470-6 WA470-6A WA480-6 wheel loader 708-1G-00060 708-1G-01060 loader pump rotary group
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

KOMATSU WA470-6 WA470-6A WA480-6 wheel loader 708-1G-00060 708-1G-01060 loader pump rotary group

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

708-1G-00060 708-1G-01060 WA470-6 WA470-6A WA480-6

Pos.	Part No	Qty	Parts name	Comments
	708-1G-00060	[1]	Pump Assembly Komatsu	0.000 kg.
			["SN: 90216-UP"] \|$0.
	708-1G-01060	[1]	Pump Subassembly Komatsu China
			["SN: 90216-UP"] \|$1.
	708-1G-04310	[1]	Case Assembly,Front Komatsu China
			["SN: 90216-UP", "SCC: C2"] \|$2.
3	708-8E-16150	[2]	Plug Komatsu	0.02 kg.
			["SN: 90216-UP"]
4	07002-21023	[2]	O-ring Komatsu	0.22 kg.
			["SN: 90216-UP"]
6	04530-11222	[2]	Bolt, Eye Komatsu	0.122 kg.
			["SN: 90216-UP"]
7	07044-12412	[1]	Plug Komatsu	0.09 kg.
			["SN: 90216-UP"] analogs:["0704402412", "R0704412412"]
8	07002-22434	[1]	O-ring Komatsu	1.1 kg.
			["SN: 90216-UP"] analogs:["0700232434", "R0700222434"]
	708-1G-04320	[1]	Cap Assembly, End Komatsu China
			["SN: 90216-UP", "SCC: C2"] \|$11.
11	708-2G-12151	[1]	Bearing Komatsu	0.21 kg.
			["SN: 90216-UP", "SCC: C2"]
12	07000-E5185	[1]	O-ring Komatsu	0.03 kg.
			["SN: 90216-UP"] analogs:["0700035185"]
13	04020-01434	[1]	Pin, Dowel Komatsu	0.044 kg.
			["SN: 90216-UP"]
14	07000-F2012	[3]	O-ring Komatsu	0.007 kg.
			["SN: 90216-UP"] analogs:["0700022012"]
15	01010-61660	[6]	Bolt Komatsu	0.127 kg.
			["SN: 90216-UP"] analogs:["0101031660", "0101081660"]
16	01643-51645	[6]	Washer Komatsu	0.021 kg.
			["SN: 90216-UP"]
17	07000-F2014	[2]	O-ring Komatsu	0.002 kg.
			["SN: 90216-UP"] analogs:["0700022014"]
18	708-2L-25480	[2]	Filter Komatsu OEM	0.5 kg.
			["SN: 90216-UP"]
21	708-1G-12160	[1]	Shaft Komatsu China
			["SN: 90216-UP", "SCC: C2"]
22	708-2G-12251	[1]	Bearing Komatsu China	0.875 kg.
			["SN: 90216-UP", "SCC: C2"] analogs:["7082G12252"]
23	708-2G-05010	[1]	Washer Kit Komatsu	0.75 kg.
			["SN: 90216-UP", "SCC: C2"]
24	708-1F-12270	[1]	Ring, Snap Komatsu	0.014 kg.
			["SN: 90216-UP", "SCC: C2"]
25	708-2G-12220	[1]	Seal, Oil Komatsu OEM	0.096 kg.
			["SN: 90216-UP"]
26	708-8H-32160	[1]	Spacer Komatsu	0.05 kg.
			["SN: 90216-UP"]
27	04065-07825	[1]	Ring, Snap Komatsu	0.022 kg.
			["SN: 90216-UP"]

Pos.	Part No	Qty	Parts name	Comments
	708-1G-00060	[1]	Pump Assembly Komatsu	0.000 kg.
			["SN: 90216-UP"] \|$0.
	708-1G-01060	[1]	Pump Subassembly Komatsu China
			["SN: 90216-UP"] \|$1.
	708-2G-04272	[1]	Block Assembly Komatsu	7.75 kg.
			["SN: 90216-UP", "SCC: C2"] analogs:["7082G04270"] \|$2.
3	708-18-13230	[1]	Pin Komatsu	0.01 kg.
			["SN: 90216-UP", "SCC: C2"]
4	04065-05520	[1]	Ring, Snap Komatsu	0.01 kg.
			["SN: 90216-UP", "SCC: C2"]
5	708-2G-13131	[1]	Seat Komatsu	0.1 kg.
			["SN: 90216-UP", "SCC: C2"]
6	708-2G-13152	[1]	Spring Komatsu	0.2 kg.
			["SN: 90216-UP", "SCC: C2"]
7	708-2G-13141	[1]	Seat Komatsu	0.02 kg.
			["SN: 90216-UP", "SCC: C2"]
8	708-2G-13510	[1]	Guide, Retainer Komatsu OEM	0.21 kg.
			["SN: 90216-UP", "SCC: C2"]
9	708-2H-23360	[3]	Pin Komatsu	0.006 kg.
			["SN: 90216-UP", "SCC: C2"]
10	708-2G-13350	[1]	Retainer, Shoe Komatsu China
			["SN: 90216-UP", "SCC: C2"]
11	708-2G-13370	[9]	Piston Subassembly Komatsu	0.28 kg.
			["SN: 90216-UP", "SCC: C2"]
	708-2G-04290	[1]	Cradle Subassembly Komatsu	5.302 kg.
			["SN: 90216-UP", "SCC: C2"] \|$14.
14	04020-01434	[1]	Pin, Dowel Komatsu	0.044 kg.
			["SN: 90216-UP", "SCC: C2"]
15	07000-F1009	[1]	O-ring Komatsu	0.001 kg.
			["SN: 90216-UP", "SCC: C2"]
16	01252-61230	[6]	Bolt, Hexagon Socket Head Komatsu	0.044 kg.
			["SN: 90216-UP", "SCC: C2"]

Pos.	Part No	Qty	Parts name	Comments
	708-1G-00060	[1]	Pump Assembly Komatsu	0.000 kg.
			["SN: 90216-UP"] \|$0.
	708-1G-01060	[1]	Pump Subassembly Komatsu China
			["SN: 90216-UP"] \|$1.
1	708-2G-14120	[1]	Slider Komatsu	0.365 kg.
			["SN: 90216-UP", "SCC: C2"]
1	708-1G-03540	[1]	Valve Assembly Komatsu China
			["SN: 90216-UP", "SCC: C2"]
1	708-2G-03590	[1]	Piston Assembly, Servo Komatsu	3.65 kg.
			["SN: 90216-UP", "SCC: C2"]
4	708-2G-15320	[1]	Seal Komatsu	0.002 kg.
			["SN: 90216-UP", "SCC: C2"]
5	708-2G-15222	[1]	Plug Komatsu China
			["SN: 90968-UP", "SCC: C2"]
5	708-2G-15221	[1]	Plug Komatsu China
			["SN: 90216-90967", "SCC: C2"]
6	708-2L-35760	[1]	Ball Komatsu	0.001 kg.
			["SN: 90216-UP", "SCC: C2"]
7	708-2L-35770	[1]	Plug Komatsu	0.005 kg.
			["SN: 90216-UP", "SCC: C2"]
8	708-2L-35690	[3]	Seal Komatsu	0.003 kg.
			["SN: 90216-UP", "SCC: C2"]
9	708-2L-35170	[1]	Pin Komatsu	0.01 kg.
			["SN: 90216-UP", "SCC: C2"]
10	708-2L-35860	[1]	Spool Komatsu	0.03 kg.
			["SN: 90216-UP", "SCC: C2"]
11	708-2G-15290	[1]	Retainer Komatsu	0.05 kg.
			["SN: 90216-UP", "SCC: C2"]
12	708-2G-15140	[1]	Seat Komatsu	0.01 kg.
			["SN: 90216-UP", "SCC: C2"]
13	708-2G-15180	[1]	Spring Komatsu China
			["SN: 90216-UP", "SCC: C2"]
14	708-1G-15270	[1]	Spring Komatsu China
			["SN: 90216-UP", "SCC: C2"]
15	708-2G-14340	[1]	Screw Komatsu	0.622 kg.
			["SN: 90216-UP", "SCC: C2"]
16	07000-F3038	[1]	O-ring Komatsu	0.002 kg.
			["SN: 90216-UP", "SCC: C2"] analogs:["0700023038"]
17	708-2G-15230	[1]	Ring, Back-up Komatsu	0.001 kg.
			["SN: 90216-UP", "SCC: C2"]
18	708-2G-15260	[1]	Seal Komatsu	0.003 kg.
			["SN: 90216-UP", "SCC: C2"]
19	708-2G-15390	[1]	Plug Komatsu China
			["SN: 90216-UP", "SCC: C2"]
20	07000-F2012	[1]	O-ring Komatsu	0.007 kg.
			["SN: 90216-UP", "SCC: C2"] analogs:["0700022012"]
21	07000-F2050	[1]	O-ring Komatsu	0.003 kg.
			["SN: 90216-UP", "SCC: C2"]
22	708-2G-15310	[1]	Ring, Back-up Komatsu	0.001 kg.
			["SN: 90216-UP", "SCC: C2"]
23	708-2G-14190	[1]	Cover Komatsu China
			["SN: 90216-UP", "SCC: C2"]
24	01580-10806	[1]	Nut Komatsu	0.005 kg.
			["SN: 90216-UP", "SCC: C2"] analogs:["801920104"]
25	708-2L-35290	[1]	Nut Komatsu	0.12 kg.
			["SN: 90216-UP", "SCC: C2"]
26	708-2G-15330	[1]	Ring, Wear Komatsu	0.005 kg.
			["SN: 90216-UP", "SCC: C2"]
27	01252-61645	[4]	Bolt, Hexagon Socket Head Komatsu	0.119 kg.
			["SN: 90216-UP", "SCC: C2"]

Pos.	Part No	Qty	Parts name	Comments
	708-1G-00060	[1]	Pump Assembly Komatsu	0.000 kg.
			["SN: 90216-UP"] \|$0.
1.	702-21-57700	[1]	Valve, Pilot Komatsu	0.45 kg.
