| 708-1W-00740 708-1W-00741 708-1W-01740 708-1W-01741 WA380-6 WA430-6 |
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-1W-00741
|
[1] |
Pump Assembly Komatsu
|
45.8 kg. |
|
|
|
["SN: 66395-UP"] analogs:["7081W00882", "7081W00881", "7081W00810", "7081W00860", "7081W00830", "7081W00740", "7081W01741", "7081W01881", "7081W00883"] |$0. |
|
| |
708-1W-00740
|
[1] |
Pump Assembly Komatsu
|
45.8 kg. |
|
|
|
["SN: 66107-66394", "SCC: A2"] analogs:["7081W00882", "7081W00881", "7081W00810", "7081W00860", "7081W00830", "7081W00741", "7081W01741", "7081W01881", "7081W00883"] |$1. |
|
|
|
708-1W-01741
|
[1] |
Pump Subassembly Komatsu
|
45.8 kg. |
|
|
|
["SN: 66395-UP", "SCC: C2"] analogs:["7081W00882", "7081W00881", "7081W00810", "7081W00860", "7081W00830", "7081W00740", "7081W00741", "7081W01881", "7081W00883"] |$2. |
|
|
|
708-1W-01740
|
[1] |
Pump Subassembly Komatsu China
|
|
|
|
|
["SN: 66107-66394", "SCC: C2"] |$3. |
|
| 1 |
708-1W-43110
|
[1] |
Block, Cylinder Komatsu China
|
|
|
|
|
["SN: 66107-UP", "SCC: C2"] |
|
| 1 |
708-1W-43310
|
[1] |
Cylinder Block Komatsu
|
3.6 kg. |
|
|
|
["SN: 65949-66106", "SCC: C2"] |
|
| 2 |
708-1W-43230
|
[1] |
Plate, Valve Komatsu China
|
|
|
|
|
["SN: 66107-UP", "SCC: C2"] |
|
| 2 |
708-1W-43210
|
[1] |
Plate, Valve Komatsu
|
0.45 kg. |
|
|
|
["SN: 65949-66106", "SCC: C2"] |
|
| 3 |
720-68-19610
|
[1] |
Pin Komatsu
|
0.002 kg. |
|
|
|
["SN: 65949-UP", "SCC: C2"] |
|
| 4 |
708-1W-43130
|
[2] |
Seat Komatsu China
|
|
|
|
|
["SN: 65949-UP", "SCC: C2"] |
|
| 5 |
708-1W-43140
|
[1] |
Spring Komatsu
|
0.15 kg. |
|
|
|
["SN: 65949-UP", "SCC: C2"] |
|
| 6 |
04065-04818
|
[1] |
Ring, Snap Komatsu OEM
|
0.007 kg. |
|
|
|
["SN: 65949-UP", "SCC: C2"] |
|
| 7 |
708-1W-43320
|
[1] |
Guide, Retainer Komatsu
|
0.08 kg. |
|
|
|
["SN: 66395-UP", "SCC: C2"] analogs:["7081W43350"] |
|
| 7 |
708-1W-43350
|
[1] |
Guide, Retainer Komatsu
|
0.08 kg. |
|
|
|
["SN: 65949-66394", "SCC: C2"] |
|
| 8 |
708-3T-13360
|
[3] |
Pin Komatsu
|
0.006 kg. |
|
|
|
["SN: 65949-UP", "SCC: C2"] |
|
| 9 |
708-1W-43341
|
[1] |
Retainer, Shoe Komatsu
|
0.25 kg. |
|
|
|
["SN: 65949-UP", "SCC: C2"] |
|
| 10 |
708-1U-13310
|
[9] |
Piston Subassembly Komatsu
|
0.2 kg. |
|
|
|
["SN: 65949-UP", "SCC: C2"] |
|
| 11 |
708-1W-44170
|
[1] |
Piston Komatsu China
|
|
|
|
|
["SN: 66107-UP", "SCC: C2"] |
|
| 11 |
708-1W-44130
|
[1] |
Piston Komatsu
|
0.095 kg. |
|
|
|
["SN: 66067-66106", "SCC: C2"] analogs:["7081W44120", "7081W44110"] |
|
| 11 |
708-1W-44120
|
[1] |
Piston Komatsu
|
0.095 kg. |
|
|
|
["SN: 65949-66066", "SCC: C2"] analogs:["7081W44110", "7081W44130"] |
|
| 12 |
708-1W-44140
|
[1] |
Spring Komatsu China
|
|
|
|
|
["SN: 66107-UP", "SCC: C2"] |
|
| 12 |
708-3T-14120
|
[1] |
Spring Komatsu
|
0.002 kg. |
|
|
|
["SN: 65949-66106", "SCC: C2"] |
|
| 13 |
708-1U-14240
|
[2] |
Screw Komatsu
|
0.000 kg. |
|
|
|
["SN: 65949-UP", "SCC: C2"] |
|
| 14 |
07000-12011
|
[2] |
O-ring Komatsu
|
0.001 kg. |
|
|
|
["SN: 65949-UP", "SCC: C2"] analogs:["YM24315000110", "0700002011"] |
|
| 15 |
01643-31232
|
[2] |
Washer Komatsu
|
0.027 kg. |
|
|
|
["SN: 65949-UP", "SCC: C2"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] |
|
| 16 |
01582-11210
|
[2] |
Nut Komatsu
|
0.015 kg. |
|
|
|
["SN: 65949-UP", "SCC: C2"] |
|
