KOMATSU WA380-6 WA430-6 WA430-6E0 WHEEL LOADER 708-1U-00120 708-1U-01122 708-1U-00150 708-1U-00151 STEERING PUMP ROTARY GROUP AND SPARE PARTS

KOMATSU WA380-6 WA430-6 WA430-6E0 WHEEL LOADER 708-1U-00120 708-1U-01122 708-1U-00150 708-1U-00151 STEERING PUMP ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
708-1U-00120 708-1U-01122 708-1U-00150 708-1U-00151 WA380-6 WA430-6 WA430-6E0
Pos. Part No Qty Parts name Comments
     708-1U-00120   [1]   PUMP ASS'Y Komatsu 38 kg.
  ["SN: 65001-UP"] analogs:["7081U00150", "7081U00151", "7081U00140", "7081U00170", "7081U00171", "R7081U00120", "R7081U00171", "7081U01151"] |$1.
        708-1U-01122   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 65001-UP"] |$4.
     708-1U-04121   [1]   CASE ASS'Y Komatsu China
  ["SN: 65001-UP"] |$5.
3   708-8E-16160   [2]   PLUG Komatsu 0.01 kg.
  ["SN: 65001-UP"]
4   07002-11023   [2]   O-RING Komatsu China 0.025 kg.
  ["SN: 65001-UP"] analogs:["0700201023"]
5   07040-11409   [1]   PLUG Komatsu 0.033 kg.
  ["SN: 65001-UP"]
6   07002-11423   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: 65001-UP"] analogs:["0700201423"]
7   706-73-42370   [1]   O-RING Komatsu 0.005 kg.
  ["SN: 65001-UP"]
8   07000-B1009   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: 65001-UP"] analogs:["7082L23910"]
9   04020-01024   [1]   PIN Komatsu 0.015 kg.
  ["SN: 65001-UP"] analogs:["PZF890001197"]
10   01010-61470   [4]   BOLT Komatsu 0.109 kg.
  ["SN: 65001-UP"] analogs:["0101031470", "0101081470", "0101051470"]
11   01643-31445   [4]   WASHER Komatsu 0.019 kg.
  ["SN: 65001-UP"] analogs:["0164301432"]
     708-1U-04410   [1]   SHUTTLE VALVE ASS'Y Komatsu 0.052 kg.
  ["SN: 65001-UP"] analogs:["7081W04420"] |$17.
12   708-1U-15910   [1]   SLEEVE Komatsu China
  ["SN: 65001-UP"]
13   720-2M-15421   [1]   HOLDER Komatsu China
  ["SN: 65001-UP"]
14   720-2M-15430   [1]   SEAL Komatsu China
  ["SN: 65001-UP"]
15   700-84-11730   [1]   BALL Komatsu 0.01 kg.
  ["SN: 65001-UP"]
16   720-2M-15440   [1]   SEAL Komatsu China
  ["SN: 65001-UP"]
17   708-1U-11522   [1]   CAP,END Komatsu China
  ["SN: 65001-UP"]
18   708-1W-42120   [1]   BEARING Komatsu 0.2 kg.
  ["SN: 65001-UP"]
19   708-3T-13421   [2]   BALL Komatsu 0.42 kg.
  ["SN: 65001-UP"]
20   708-1U-13421   [1]   CAM,ROCKER Komatsu China
  ["SN: 65001-UP"]
21   04260-01270   [1]   BALL Komatsu OEM 0.009 kg.
  ["SN: 65001-UP"]
22   708-1U-12120   [1]   SHAFT Komatsu 1.7 kg.
  ["SN: 65001-UP"]
23   708-1W-42110   [1]   BEARING Komatsu 0.23 kg.
  ["SN: 65001-UP"]
24   708-1U-12320   [1]   CASE,SEAL Komatsu 0.2 kg.
  ["SN: 65001-UP"]
25   708-1W-42130   [1]   SEAL,OIL Komatsu 0.032 kg.
  ["SN: 65001-UP"]
26   07000-B2065   [1]   O-RING Komatsu 0.002 kg.
  ["SN: 65001-UP"]
27   708-1W-05810   [1]   SPACER KIT Komatsu 0.182 kg.
  ["SN: 65001-UP"]
28   04065-07225   [1]   RING Komatsu 0.02 kg.
  ["SN: 65001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-1U-00120   [1]   PUMP ASS'Y Komatsu 38 kg.
  ["SN: 65001-UP"] analogs:["7081U00150", "7081U00151", "7081U00140", "7081U00170", "7081U00171", "R7081U00120", "R7081U00171", "7081U01151"] |$1.
        708-1U-01122   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 65001-UP"] |$3.
1   708-1U-13110   [1]   BLOCK,CYLINDER Komatsu 3.6 kg.
  ["SN: 65001-UP"]
2   708-1U-13220   [1]   PLATE,VALVE Komatsu China
  ["SN: 65001-UP"]
3   720-68-19610   [1]   PIN Komatsu 0.002 kg.
  ["SN: 65001-UP"]
4   708-1W-43130   [2]   SEAT Komatsu China
  ["SN: 65001-UP"]
5   708-1W-43140   [1]   SPRING Komatsu 0.15 kg.
  ["SN: 65001-UP"]
6   04065-04818   [1]   RING Komatsu OEM 0.007 kg.
  ["SN: 65001-UP"]
7   708-1W-43350   [1]   GUIDE,RETAINER Komatsu 0.08 kg.
  ["SN: 65001-UP"]
8   708-3T-13360   [3]   PIN Komatsu 0.006 kg.
  ["SN: 65001-UP"]
9   708-1U-13341   [1]   RETAINER,SHOE Komatsu 0.34 kg.
  ["SN: 65001-UP"]
10   708-1U-13310   [7]   PISTON SUB ASS'Y Komatsu 0.2 kg.
  ["SN: 65001-UP"]
11   708-1W-44110   [1]   PISTON SUB ASS'Y Komatsu 0.095 kg.
  ["SN: 65001-UP"] analogs:["7081W44120", "7081W44130"]
12   708-3T-14120   [1]   SPRING Komatsu 0.002 kg.
  ["SN: 65001-UP"]
13   708-1U-14221   [2]   SCREW Komatsu China
  ["SN: 65001-UP"]
14   07000-12011   [2]   O-RING Komatsu 0.001 kg.
  ["SN: 65001-UP"] analogs:["YM24315000110", "0700002011"]
15   01643-31232   [2]   WASHER Komatsu 0.027 kg.
  ["SN: 65001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
16   01582-11210   [2]   NUT Komatsu 0.015 kg.
  ["SN: 65001-UP"]
