| 708-7S-00550 WA380-6 WA430-6 WA430-6E0 WA450-6 WA470-6 WA470-6 WA480-6 GD675-3A |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-7S-00550
|
[1] |
MOTOR ASS'Y Komatsu
|
14.322 kg. |
|
["SN: 65001-UP"] |$1. |
|
1. |
07000-E2110
|
[1] |
O-RING Komatsu
|
0.006 kg. |
|
["SN: 65001-UP"] |
|
2. |
04020-00616
|
[2] |
PIN,DOWEL Komatsu
|
0.004 kg. |
|
["SN: 65001-UP"] |
|
3. |
01252-61255
|
[4] |
BOLT Komatsu China
|
|
|
["SN: 65001-UP"] analogs:["0125201255", "0125211255", "0125241255", "0125231255", "7051702670"] |
|
4. |
708-7S-12330
|
[1] |
SHAFT Komatsu
|
0.56 kg. |
|
["SN: 65001-UP"] |
|
5. |
708-7S-12140
|
[1] |
BEARING Komatsu
|
0.14 kg. |
|
["SN: 65001-UP"] |
|
6. |
708-7S-12220
|
[1] |
BEARING Komatsu China
|
|
|
["SN: 65001-UP"] |
|
7. |
708-7S-05110
|
[1] |
SHIM KIT Komatsu
|
0.016 kg. |
|
["SN: 65001-UP"] |
|
8. |
708-7T-12330
|
[1] |
SEAL,OIL Komatsu
|
0.042 kg. |
|
["SN: 65001-UP"] |
|
9. |
708-1S-11890
|
[1] |
SPACER Komatsu
|
0.05 kg. |
|
["SN: 65001-UP"] |
|
10. |
04065-04518
|
[1] |
RING,SNAP Komatsu
|
0.006 kg. |
|
["SN: 65001-UP"] |
|
11. |
708-7S-13120
|
[1] |
BLOCK,CYLINDER Komatsu China
|
|
|
["SN: 65001-UP"] |
|
12. |
708-7S-13250
|
[1] |
PLATE,VALVE Komatsu China
|
|
|
["SN: 65001-UP"] |
|
13. |
720-68-19610
|
[1] |
PIN Komatsu
|
0.002 kg. |
|
["SN: 65001-UP"] |
|
14. |
708-2L-23360
|
[3] |
PIN Komatsu
|
0.003 kg. |
|
["SN: 65001-UP"] |
|
15. |
708-7S-13530
|
[2] |
SPACER Komatsu China
|
|
|
["SN: 65001-UP"] |
|
16. |
708-7S-13560
|
[1] |
SPRING Komatsu China
|
|
|
["SN: 65001-UP"] |
|
17. |
04065-03212
|
[1] |
RING,SNAP Komatsu
|
0.002 kg. |
|
["SN: 65001-UP"] analogs:["4174317180"] |
|
18. |
708-7S-13550
|
[1] |
GUIDE,RETAINER Komatsu China
|
|
|
["SN: 65001-UP"] |
|
19. |
708-7S-13360
|
[1] |
RETAINER,SHOE Komatsu
|
0.13 kg. |
|
["SN: 65001-UP"] |
|
20. |
708-7S-13350
|
[5] |
PISTON SUB ASS'Y Komatsu
|
0.1 kg. |
|
["SN: 65001-UP"] |
|
21. |
708-7S-13420
|
[1] |
PLATE,THRUST Komatsu China
|
|
|
["SN: 65001-UP"] |
| Parts on group : |
|
|
|
|
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
708-7S-00550
|
[1] |
MOTOR ASS'Y Komatsu
|
14.322 kg. |
|
["SN: 65001-UP"] |$1. |
|
1. |
708-7S-11740
|
[1] |
CASE Komatsu China
|
|
|
["SN: 65001-UP"] |
|
2. |
07040-11007
|
[1] |
PLUG Komatsu
|
0.014 kg. |
|
["SN: 65001-UP"] |
|
3. |
07002-21023
|
[1] |
O-RING Komatsu
|
0.22 kg. |
|
["SN: 65001-UP"] |
|
|
708-7S-01430
|
[1] |
COVER SUB ASS'Y Komatsu China
|
|
|
["SN: 65001-UP"] |$7. |
| 5 |
708-7R-11210
|
[1] |
VALVE Komatsu
|
0.07 kg. |
|
["SN: 65001-UP"] |
| 6 |
722-10-91130
|
[1] |
SPRING Komatsu China
|
|
|
["SN: 65001-UP"] |
| 7 |
709-32-12861
|
[1] |
PLUG Komatsu China
|
|
|
["SN: 65001-UP"] |
| 8 |
07002-21823
|
[1] |
O-RING Komatsu
|
0.36 kg. |
|
["SN: 65001-UP"] analogs:["0700231823"] |
| 10 |
708-7S-18120
|
[1] |
SPRING Komatsu China
|
|
|
["SN: 65001-UP"] |
| 11 |
708-7S-18310
|
[1] |
SPACER Komatsu China
|
|
|
["SN: 65001-UP"] |
| 12 |
708-7S-18320
|
[1] |
COVER Komatsu
|
1.55 kg. |
|
["SN: 65001-UP"] |
| 13 |
07000-E2020
|
[1] |
O-RING Komatsu China
|
0.036 kg. |
|
["SN: 65001-UP"] |
| 14 |
07000-E2025
|
[1] |
O-RING Komatsu
|
0.002 kg. |
|
["SN: 65001-UP"] |
| 15 |
07000-E2012
|
[1] |
O-RING Komatsu
|
0.001 kg. |
|
["SN: 65001-UP"] analogs:["0700032012"] |
| 16 |
01252-60845
|
[4] |
BOLT Komatsu
|
0.025 kg. |
|
["SN: 65001-UP"] analogs:["0125230845"] |
| |
708-7S-01440
|
[1] |
PILOT VALVE ASS'Y Komatsu
|
0.95 kg. |
|
["SN: 65001-UP"] |$21. |
| 17 |
702-21-56241
|
[1] |
SOLENOID Komatsu
|
0.21 kg. |
|
["SN: 65001-UP"] |
| 18 |
702-21-55870
|
[1] |
O-RING Komatsu
|
0.001 kg. |
|
["SN: 65001-UP"] |
| 21 |
702-21-56220
|
[1] |
SPRING Komatsu
|
0.002 kg. |
|
["SN: 65001-UP"] |
| 22 |
708-21-12541
|
[1] |
PLUG Komatsu China
|
|
|
["SN: 65001-UP"] analogs:["7068651180"] |
| 23 |
01252-60616
|
[2] |
BOLT Komatsu
|
0.007 kg. |
|
["SN: 65001-UP"] analogs:["0125230616"] |
| 24 |
708-2L-25490
|
[1] |
O-RING Komatsu
|
0.001 kg. |
|
["SN: 65001-UP"] |
| 25 |
708-2L-25480
|
[1] |
FILTER Komatsu OEM
|
0.5 kg. |
|
["SN: 65001-UP"] |
| 26 |
702-21-54180
|
[2] |
SCREW Komatsu China
|
|
|
["SN: 65001-UP"] |
| 27 |
07000-F1008
|
[1] |
O-RING Komatsu
|
0.001 kg. |
|
["SN: 65001-UP"] |
| 28 |
708-7S-18230
|
[1] |
O-RING Komatsu
|
0.001 kg. |
|
["SN: 65001-UP"] |
| 31 |
708-2L-29460
|
[1] |
ORIFICE Komatsu China
|
|
|
["SN: 65001-UP"] |
| 32 |
708-1S-18180
|
[1] |
COVER Komatsu China
|
|
|
["SN: 65001-UP"] |
| 33 |
708-7S-18480
|
[1] |
VALVE Komatsu China
|
|
|
["SN: 65001-UP"] |
| 35 |
01252-60825
|
[4] |
BOLT Komatsu
|
0.017 kg. |
|
["SN: 65001-UP"] analogs:["0125240825", "0125230825"] |
| 36 |
708-7T-02281
|
[1] |
VALVE ASS'Y,RELIEF Komatsu
|
0.2 kg. |
|
["SN: 65204-UP"] |
| 36 |
708-7T-02280
|
[1] |
VALVE ASS'Y,RELIEF Komatsu
|
0.2 kg. |
|
["SN: 65001-65203"] analogs:["7087T02281"] |
| 37 |
07000-F2016
|
[1] |
O-RING Komatsu
|
0.001 kg. |
|
["SN: 65001-UP"] analogs:["0700022016"] |
| 38 |
07001-02016
|
[1] |
RING Komatsu
|
0.005 kg. |
|
["SN: 65001-UP"] |
| 39 |
07002-12434
|
[1] |
O-RING Komatsu China
|
0.01 kg. |
|
["SN: 65001-UP"] analogs:["0700202434", "0700213434"] |
