KOMATSU PW160-7 PW160-7E0 PW160-7K EXCAVATOR 708-1G-00014 708-1G-01014 HYDRAULIC PUMP ROTARY GROUP

KOMATSU PW160-7 PW160-7E0 PW160-7K EXCAVATOR 708-1G-00014 708-1G-01014 HYDRAULIC PUMP ROTARY GROUP

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
708-1G-00014 708-1G-01014
PW160-7 PW160-7E0 PW160-7K
Pos. Part No Qty Parts name Comments
     708-1G-00014   [1]   MAIN PUMP ASSEMBLY Komatsu 114 kg.
  ["SN: H50051-UP"] analogs:["RM7081G00014", "7081G00010"] |$1.
        708-1G-01014   [1]   PUMP SUB ASSEMBLY Komatsu 112 kg.
  ["SN: H50051-UP"] |$3.
     708-1G-04113   [1]   CASE ASSEMBLY Komatsu 50 kg.
  ["SN: H50051-UP"] |$4.
3   708-8E-16150   [2]   PLUG Komatsu 0.02 kg.
  ["SN: H50051-UP"]
4   07002-61023   [2]   O-RING Komatsu 0.22 kg.
  ["SN: H50051-UP"] analogs:["7082L23920"]
5   708-1L-29340   [1]   ORIFICE Komatsu 0.001 kg.
  ["SN: H50051-UP"]
6   04530-11222   [2]   BOLT Komatsu 0.122 kg.
  ["SN: H50051-UP"]
7   07044-12412   [1]   PLUG Komatsu 0.09 kg.
  ["SN: H50051-UP"] analogs:["0704402412", "R0704412412"]
8   07002-62434   [1]   O-RING Komatsu 0.001 kg.
  ["SN: H50051-UP"] analogs:["7081W28910"]
9   07040-12414   [1]   PLUG Komatsu 0.092 kg.
  ["SN: H50051-UP"] analogs:["0704002412", "0704012412"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-1G-00014   [1]   MAIN PUMP ASSEMBLY Komatsu 114 kg.
  ["SN: H50051-UP"] analogs:["RM7081G00014", "7081G00010"] |$1.
        708-1G-01014   [1]   PUMP SUB ASSEMBLY Komatsu 112 kg.
  ["SN: H50051-UP"] |$3.
     708-1G-04122   [1]   CAP ASSEMBLY Komatsu 27.5 kg.
  ["SN: H50051-UP"] |$4.
3   708-2G-12151   [1]   BEARING Komatsu 0.21 kg.
  ["SN: H50051-UP"]
4   07000-A5185   [1]   O-RING Komatsu OEM 0.02 kg.
  ["SN: H50051-UP"]
5   04020-01434   [1]   PIN Komatsu 0.044 kg.
  ["SN: H50051-UP"]
6   07000-B2012   [4]   O-RING Komatsu China 0.001 kg.
  ["SN: H50051-UP"]
7   01010-61660   [4]   BOLT Komatsu 0.127 kg.
  ["SN: H50051-UP"] analogs:["0101031660", "0101081660"]
8   01010-61670   [2]   BOLT Komatsu 0.142 kg.
  ["SN: H50051-UP"] analogs:["0101031670", "0101051670", "0101081670"]
9   07000-B2014   [2]   O-RING Komatsu China 0.001 kg.
  ["SN: H50051-UP"]
10   708-2L-25480   [2]   FILTER Komatsu OEM 0.5 kg.
  ["SN: H50051-UP"]
11   708-8E-16150   [4]   PLUG Komatsu 0.02 kg.
  ["SN: H50051-UP"]
12   07002-61023   [4]   O-RING Komatsu 0.22 kg.
  ["SN: H50051-UP"] analogs:["7082L23920"]
13   07040-12414   [1]   PLUG Komatsu 0.092 kg.
  ["SN: H50051-UP"] analogs:["0704002412", "0704012412"]
14   07002-62434   [1]   O-RING Komatsu 0.001 kg.
  ["SN: H50051-UP"] analogs:["7081W28910"]
15   01643-31645   [6]   WASHER Komatsu 0.072 kg.
  ["SN: H50051-UP"] analogs:["802170005", "0164301645"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-1G-00014   [1]   MAIN PUMP ASSEMBLY Komatsu 114 kg.
  ["SN: H50051-UP"] analogs:["RM7081G00014", "7081G00010"] |$1.
        708-1G-01014   [1]   PUMP SUB ASSEMBLY Komatsu 112 kg.
  ["SN: H50051-UP"] |$3.
1   708-1G-12110   [1]   SHAFT Komatsu China
  ["SN: H50051-UP"]
2   708-2G-12251   [1]   BEARING Komatsu China 0.875 kg.
  ["SN: H50051-UP"] analogs:["7082G12252"]
3   708-2G-05010   [1]   WASHER KIT Komatsu 0.75 kg.
  ["SN: H50051-UP"]
4   708-1F-12270   [1]   RING Komatsu 0.014 kg.
  ["SN: H50051-UP"]
5   708-2G-12220   [1]   SEAL Komatsu OEM 0.096 kg.
  ["SN: H50051-UP"]
6   708-8H-32160   [1]   SPACER Komatsu 0.05 kg.
  ["SN: H50051-UP"]
7   04065-07825   [1]   RING Komatsu 0.022 kg.
  ["SN: H50051-UP"]
     708-1G-04130   [1]   CYLINDER BLOCK ASSEMBLY Komatsu 7.75 kg.
  ["SN: H50051-UP"] analogs:["7082G04261", "7082G04262", "7082G04260"] |$14.
10   708-18-13230   [1]   PIN Komatsu 0.01 kg.
  ["SN: H50051-UP"]
11   04065-05520   [1]   RING Komatsu 0.01 kg.
  ["SN: H50051-UP"]
12   708-2G-13131   [1]   SEAT Komatsu 0.1 kg.
  ["SN: H50051-UP"]
13   708-2G-13152   [1]   SPRING Komatsu 0.2 kg.
  ["SN: H50051-UP"]
14   708-2G-13141   [1]   SEAT Komatsu 0.02 kg.
  ["SN: H50051-UP"]
15   708-2G-13510   [1]   GUIDE Komatsu OEM 0.21 kg.
  ["SN: H50051-UP"]
16   708-2H-23360   [3]   PIN Komatsu 0.006 kg.
  ["SN: H50051-UP"]
17   708-2G-13341   [1]   RETAINER Komatsu OEM 0.39 kg.
  ["SN: H50051-UP"]
18   708-2G-13311   [9]   PISTON SUB ASSEMBLY Komatsu OEM 0.29 kg.
  ["SN: H50051-UP"]
     708-2G-04290   [1]   CRADLE SUB ASSEMBLY Komatsu 5.302 kg.
  ["SN: H50051-UP"] |$26.
21   04020-01434   [1]   PIN Komatsu 0.044 kg.
  ["SN: H50051-UP"]
22   07000-B1009   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: H50051-UP"] analogs:["7082L23910"]
23   01252-61230   [6]   BOLT Komatsu 0.044 kg.
  ["SN: H50051-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-1G-00014   [1]   MAIN PUMP ASSEMBLY Komatsu 114 kg.
  ["SN: H50051-UP"] analogs:["RM7081G00014", "7081G00010"] |$1.
        708-1G-01014   [1]   PUMP SUB ASSEMBLY Komatsu 112 kg.
  ["SN: H50051-UP"] |$3.
1   708-2G-14120   [1]   SLIDER Komatsu 0.365 kg.
  ["SN: H50051-UP"]
     708-1G-03511   [1]   VALVE ASSEMBLY Komatsu 5.26 kg.
  ["SN: H50051-UP"] |$5.
     708-2G-03521   [1]   PISTON ASSEMBLY Komatsu 2.6 kg.
  ["SN: H50051-UP"] analogs:["7082G03520"] |$6.
4   708-2G-15320   [2]   SEAL Komatsu 0.002 kg.
  ["SN: H50051-UP"]
5   708-2G-15221   [1]   PLUG Komatsu China
  ["SN: H50051-UP"]
6   708-2L-35760   [1]   BALL Komatsu 0.001 kg.
  ["SN: H50051-UP"]
7   708-2L-35770   [1]   PLUG Komatsu 0.005 kg.
  ["SN: H50051-UP"]
8   708-2L-35690   [3]   SEAL Komatsu 0.003 kg.
  ["SN: H50051-UP"]
9   708-2L-35170   [1]   PIN Komatsu 0.01 kg.
  ["SN: H50051-UP"]
10   708-3M-15670   [1]   SPOOL Komatsu 0.03 kg.
  ["SN: H50051-UP"]
11   708-2G-15290   [1]   RETAINER Komatsu 0.05 kg.
  ["SN: H50051-UP"]
12   708-2G-15140   [1]   SEAT Komatsu 0.01 kg.
  ["SN: H50051-UP"]
13   708-2G-15270   [1]   SPRING Komatsu 2.1 kg.
  ["SN: H50051-UP"]
14   708-1G-15210   [1]   SPRING Komatsu China
  ["SN: H50051-UP"]
15   708-2G-15151   [1]   SEAT Komatsu 0.01 kg.
  ["SN: H50051-UP"]
16   708-1G-15220   [1]   SPRING Komatsu China
  ["SN: H50051-UP"]
17   708-2G-14340   [1]   SCREW Komatsu 0.622 kg.
  ["SN: H50051-UP"]
18   07000-B3038   [1]   O-RING Komatsu 0.002 kg.
  ["SN: H50051-UP"]
19   708-2G-15230   [1]   RING Komatsu 0.001 kg.
  ["SN: H50051-UP"]
20   708-2G-15260   [1]   SEAL Komatsu 0.003 kg.
  ["SN: H50051-UP"]
21   708-2G-15240   [1]   PLUG Komatsu 0.08 kg.
  ["SN: H50051-UP"]
22   07000-B2012   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: H50051-UP"]
23   07000-B2050   [1]   O-RING Komatsu 0.002 kg.
  ["SN: H50051-UP"]
24   708-2G-15310   [1]   RING Komatsu 0.001 kg.
  ["SN: H50051-UP"]
25   708-2G-14190   [1]   COVER Komatsu China
  ["SN: H50051-UP"]
26   01580-10806   [1]   NUT Komatsu 0.005 kg.
  ["SN: H50051-UP"] analogs:["801920104"]
27   708-2L-35290   [1]   NUT Komatsu 0.12 kg.
  ["SN: H50051-UP"]
28   708-2G-15330   [1]   RING Komatsu 0.005 kg.
  ["SN: H50051-UP"]
29   01252-61645   [4]   BOLT Komatsu 0.119 kg.
  ["SN: H50051-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-1G-00014   [1]   MAIN PUMP ASSEMBLY Komatsu 114 kg.
  ["SN: H50051-UP"] analogs:["RM7081G00014", "7081G00010"] |$1.
        708-1G-01014   [1]   PUMP SUB ASSEMBLY Komatsu 112 kg.
  ["SN: H50051-UP"] |$3.
     708-2G-03480   [1]   COVER ASSEMBLY Komatsu 2.01 kg.
  ["SN: H50051-UP"] analogs:["7082G03430"] |$4.
1   708-2G-14310   [1]   SCREW Komatsu 0.54 kg.
  ["SN: H50051-UP"]
2   07000-B3038   [1]   O-RING Komatsu 0.002 kg.
  ["SN: H50051-UP"]
3   708-2G-15230   [1]   RING Komatsu 0.001 kg.
  ["SN: H50051-UP"]
4   708-2L-35290   [1]   NUT Komatsu 0.12 kg.
  ["SN: H50051-UP"]
5   708-2G-14170   [1]   COVER Komatsu 1.5 kg.
  ["SN: H50051-UP"]
6   07000-B2050   [1]   O-RING Komatsu 0.002 kg.
  ["SN: H50051-UP"]
7   708-2G-15310   [1]   RING Komatsu 0.001 kg.
  ["SN: H50051-UP"]
8   01252-61645   [4]   BOLT Komatsu 0.119 kg.
  ["SN: H50051-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-1G-00014   [1]   MAIN PUMP ASSEMBLY Komatsu 114 kg.
  ["SN: H50051-UP"] analogs:["RM7081G00014", "7081G00010"] |$1.
        708-2L-06751   [1]   VALVE ASSEMBLY Komatsu China
  ["SN: H50051-UP"] analogs:["7082L06750"] |$3.
1   708-2L-35311   [1]   SLEEVE Komatsu 0.36 kg.
  ["SN: H50051-UP"]
2   708-2L-24680   [4]   SEAL Komatsu 0.003 kg.
  ["SN: H50051-UP"]
3   708-2L-35550   [1]   SPOOL Komatsu China
  ["SN: H50051-UP"]
4   708-2L-28540   [1]   PISTON Komatsu 0.01 kg.
  ["SN: H50051-UP"]
5   708-2L-35360   [1]   SLEEVE Komatsu 0.04 kg.
  ["SN: H50051-UP"]
6   708-2L-35331   [1]   SEAT Komatsu 0.01 kg.
  ["SN: H50051-UP"]
7   708-2L-35410   [1]   SPRING Komatsu 0.01 kg.
  ["SN: H50051-UP"]
8   708-2L-35341   [1]   SEAT Komatsu 0.001 kg.
  ["SN: H50051-UP"]
9   708-2L-35351   [1]   PLUG Komatsu 0.04 kg.
  ["SN: H50051-UP"]
10   07000-B1009   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: H50051-UP"] analogs:["7082L23910"]
11   07001-01009   [1]   RING Komatsu 0.001 kg.
  ["SN: H50051-UP"]
12   01583-11408   [1]   NUT Komatsu 0.4 kg.
  ["SN: H50051-UP"] analogs:["801713411"]
13   07002-62434   [1]   O-RING Komatsu 0.001 kg.
  ["SN: H50051-UP"] analogs:["7081W28910"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-1G-00014   [1]   MAIN PUMP ASSEMBLY Komatsu 114 kg.
  ["SN: H50051-UP"] analogs:["RM7081G00014", "7081G00010"] |$1.
   1.   702-21-55600   [1]   PILOT VALVE Komatsu 0.42 kg.
  ["SN: H50051-UP"] analogs:["7022157600"]
   2.   01252-60635   [2]   BOLT Komatsu 0.011 kg.
  ["SN: H50051-UP"]
   3.   20Y-62-22790   [1]   BAND, RED Komatsu 0.001 kg.
  ["SN: H50051-UP"]
   6.   20Y-62-22830   [1]   BAND, WHITE Komatsu 0.001 kg.
  ["SN: H50051-UP"]
   7.   708-2L-35941   [1]   PLUG Komatsu 0.05 kg.
  ["SN: H50051-UP"]
   8.   07000-B1008   [1]   O-RING Komatsu 0.001 kg.
  ["SN: H50051-UP"]
   9.   07001-01008   [2]   RING Komatsu 0.001 kg.
  ["SN: H50051-UP"]
   10.   07002-61423   [1]   O-RING Komatsu 0.001 kg.
  ["SN: H50051-UP"] analogs:["7082L23950"]
   11.   01643-51232   [2]   WASHER Komatsu 0.024 kg.
  ["SN: H50051-UP"]
   12.   01010-81220   [2]   BOLT Komatsu 0.032 kg.
  ["SN: H50051-UP"] analogs:["0101051220"]
   13.   08193-21012   [2]   CLIP Komatsu 0.011 kg.
  ["SN: H50051-UP"]
