KOMATSU PW150ES-6K SWING CIRCLE AND RELATED PARTS

Name: KOMATSU PW150ES-6K SWING CIRCLE AND RELATED PARTS
Brand: +8613035309093
Price: 5000.0 USD
Availability: InStock

KOMATSU PW150ES-6K SWING CIRCLE AND RELATED PARTS

$5,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

Parts on group :SWING MACHINERY (RELATED PARTS) PW150ES-6K S/N K30001-UP Komatsu

Pos.	Part No	Qty	Parts name	Comments
1	20G-26-K1111	[1]	SWING MACHINERY A. Komatsu	0.000 kg.
			["SN: K30174-UP"] analogs:["20G26K1110"]
	20G-26-K1110	[1]	SWING MACHINERY A. Komatsu	0.000 kg.
			["SN: K30001-K30173"] analogs:["20G26K1111"] \|1.
2	01010-62060	[10]	BOLT Komatsu China	0.2 kg.
			["SN: K30001-UP"] analogs:["0101052060", "0101032060", "0101082060"]
3	01643-32060	[10]	WASHER Komatsu China	0.044 kg.
			["SN: K30001-UP"] analogs:["802170007", "0164322045", "0164302045"]
4	07000-05220	[1]	O-RING Komatsu China	0.03 kg.
			["SN: K30001-UP"] analogs:["0700015220", "0700015220"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	20G-26-K1111	[1]	SWING MACHINERY A. Komatsu	0.000 kg.
			["SN: K30174-UP"] analogs:["20G26K1110"] \|1.
	20G-26-K1110	[1]	SWING MACHINERY A. Komatsu	0.000 kg.
			["SN: K30001-K30173"] analogs:["20G26K1111"] \|1.
1.	21P-26-K1250	[1]	HOUSING ASS'Y Komatsu	78.91 kg.
			["SN: K30001-UP"]
2	21P-26-K1140	[1]	SEAL Komatsu	0.15 kg.
			["SN: K30001-UP"]
3	21P-26-K1170	[1]	BEARING,BALL Komatsu	6.31 kg.
			["SN: K30001-UP"]
4	21P-26-K1230	[1]	SEAL,RING Komatsu	0.1 kg.
			["SN: K30001-UP"]
5	21P-26-K1240	[1]	BEARING,BALL Komatsu	1.72 kg.
			["SN: K30001-UP"]
6	21P-26-K0160	[1]	RETAINER Komatsu	0.4 kg.
			["SN: K30001-UP"]
7.	21P-26-K1190	[6]	WASHER Komatsu China
			["SN: K30174-UP"] analogs:["2266015140", "843200443", "843200522", "PZF843200443"]
8.	21P-26-K1210	[4]	PLUG Komatsu China
			["SN: K30174-UP"] analogs:["2266015130", "843200728", "843200009", "PZF843200009", "21D6016160"]
9.	21P-26-K0220	[2]	TUBE Komatsu China
			["SN: K30001-K30173"]
10.	21P-26-K0230	[1]	ELBOW Komatsu China
			["SN: K30001-K30173"]
11.	21P-26-K1270	[1]	GEAR ASS'Y Komatsu	22.85 kg.
			["SN: K30001-UP"]
12	21P-26-K1220	[2]	O-RING Komatsu	0.05 kg.
			["SN: K30001-UP"]
13.	21P-26-K0090	[1]	FLANGE Komatsu China
			["SN: K30001-UP"]
14.	21P-26-K1280	[4]	SCREW Komatsu China
			["SN: K30001-UP"]
15.	21P-26-K1290	[12]	SCREW Komatsu China
			["SN: K30001-UP"]
16.	21P-26-K1330	[1]	GEAR ASS'Y Komatsu China
			["SN: K30001-UP"]
17	21P-26-K1310	[2]	O-RING Komatsu China
			["SN: K30001-UP"] analogs:["2266016220", "843200702"]
18.	21P-26-K1340	[1]	RING,SNAP Komatsu China
			["SN: K30001-UP"]
19.	21P-26-K0310	[1]	SPACER Komatsu China
			["SN: K30001-UP"]
20.	21P-26-K1350	[1]	PLUG Komatsu China
			["SN: K30001-UP"]
21.	21P-26-K1490	[1]	HOUSING,BRAKE Komatsu China
			["SN: K30001-UP"]
22.	21P-26-K1360	[11]	SCREW Komatsu China
			["SN: K30001-UP"]
23.	21P-26-K1370	[2]	O-RING Komatsu China
			["SN: K30001-UP"]
24.	21P-26-K0020	[1]	SHAFT,DRIVE Komatsu China
			["SN: K30001-UP"]
25.	21P-26-K0330	[5]	DISC Komatsu	0.04 kg.
			["SN: K30001-UP"]
26.	21P-26-K0320	[6]	DISC Komatsu	0.1 kg.
			["SN: K30001-UP"] analogs:["2266016330"]
27.	21P-26-K0340	[1]	SPACER Komatsu China
			["SN: K30001-UP"]
28.	21P-26-K1380	[1]	O-RING Komatsu China
			["SN: K30001-UP"]
29.	21P-26-K0040	[1]	CARRIER Komatsu China
			["SN: K30001-UP"]
30.	21P-26-K0350	[18]	SPRING Komatsu	0.01 kg.
			["SN: K30001-UP"] analogs:["21P27K1360"]
31.	21P-26-K0030	[1]	DISC Komatsu China
			["SN: K30001-UP"]
32.	21P-26-K1390	[1]	RING,SNAP Komatsu China
			["SN: K30001-UP"]
33.	21P-26-K1410	[1]	O-RING Komatsu China
			["SN: K30001-UP"] analogs:["843200630"]
34.	21P-26-K1420	[1]	WASHER Komatsu China
			["SN: K30001-UP"]
35.	21P-26-K1430	[1]	ELBOW Komatsu China
			["SN: K30001-UP"]
36.	21P-26-K1440	[1]	PLUG Komatsu China
			["SN: K30001-UP"]
37.	21P-26-K1450	[8]	SCREW Komatsu China
			["SN: K30001-UP"]
38.	21P-26-K1460	[2]	SCREW Komatsu China
			["SN: K30001-UP"]
39.	21P-26-K1510	[1]	FLANGE Komatsu China
			["SN: K30001-UP"]
40.	21P-26-K1470	[1]	O-RING Komatsu China
			["SN: K30001-UP"]
41.	21P-26-K1480	[1]	FILLER Komatsu China
			["SN: K30001-UP"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
1	21P-60-K1183	[1]	MOTOR ASS'Y,SWING Komatsu	28.4 kg.
			["SN: K30135-UP"] analogs:["21P60K5190", "21P60K1182"]
	21P-60-K1181	[1]	MOTOR ASS'Y,SWING Komatsu China
			["SN: K30001-K30134"] \|1.
2	01010-61645	[2]	BOLT Komatsu China	0.104 kg.
			["SN: K30001-UP"] analogs:["801015187", "0101031645", "0101051645", "0101081645", "37A0911184", "801014184"]
3	01643-31645	[2]	WASHER Komatsu	0.072 kg.
			["SN: K30001-UP"] analogs:["802170005", "0164301645"]
