KOMATSU PW150ES-6K EXCAVATOR SWING REDUCTION GEAR

KOMATSU PW150ES-6K EXCAVATOR SWING REDUCTION GEAR

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group :SWING MOTOR (INNER PARTS) (1/3) (FOR ROTARY ARM) PW150ES-6K S/N K30001-UP Komatsu
Pos. Part No Qty Parts name Comments
     202-966-4911   [1]   MOTOR ASS'Y,SWING (TZ504S000002-A) Komatsu China
  ["SN: K30001-UP"] analogs:["RM2029664911", "2029664910"] |1.
        TZ501S1000-01   [1]   SWING MACHINERY A. Komatsu China
  ["SN: K30001-UP"] |1.
1   TZ501S1001-00   [1]   HUB ASS'Y Komatsu China
  ["SN: K30001-UP"]
2   TZGM3-8   [1]   PLUG Komatsu 0.03 kg.
  ["SN: K30001-UP"]
     TZ501S1101-00   [1]   SPINDLE KIT Komatsu China
  ["SN: K30001-UP"] |3.
     TZ501S1131-00   [1]   SPINDLE ASS'Y Komatsu 0.000 kg.
  ["SN: K30001-UP"] |3.
5   TZ550A1019-00   [3]   BOLT Komatsu 0.127 kg.
  ["SN: K30001-UP"]
     TZ550A1104-01   [1]   RV GEAR ASS'Y Komatsu 4.84 kg.
  ["SN: K30001-UP"] |6.
     TZ550A1204-00   [1]   RV GEAR KIT Komatsu 0.000 kg.
  ["SN: K30001-UP"] |6.
8   TZ550A1009-00   [3]   SHAFT Komatsu 5.1 kg.
  ["SN: K30001-UP"] analogs:["TZ550A101100"]
9   TZ550A1011-00   [1]   SPACER Komatsu 5.1 kg.
  ["SN: K30001-UP"] analogs:["TZ550A100900"]
10   TZ550A1022-01   [6]   BEARING,ROLLER Komatsu 0.11 kg.
  ["SN: K30001-UP"]
11   TZ550A1023-01   [6]   BEARING,NEEDLE Komatsu 0.08 kg.
  ["SN: K30001-UP"]
12   TZ501S1006-00   [1]   GEAR,INPUT Komatsu China
  ["SN: K30001-UP"]
     TZ552A1107-00   [1]   SPUR GEAR KIT Komatsu China
  ["SN: K30001-UP"] |13.
14   TZ550A1013-00   [3]   PIECE Komatsu China
  ["SN: K30001-UP"] analogs:["R550A10130", "TZ550A10130"]
15   TZ550A1014-00   [3]   PIECE Komatsu 0.05 kg.
  ["SN: K30001-UP"]
16   TZ550A1017-00   [36]   PIN Komatsu China
  ["SN: K30001-UP"] analogs:["R550A10170", "TZ550A10170"]
17   TZ501S1020-00   [1]   RING Komatsu China
  ["SN: K30001-UP"]
18   TZ510B1021-00   [1]   BEARING,BALL Komatsu 0.885 kg.
  ["SN: K30001-UP"]
19   TZ501S1024-00   [1]   NUT Komatsu China
  ["SN: K30001-UP"]
20   TZ501S1026-00   [1]   PLATE Komatsu China
  ["SN: K30001-UP"]
21   TZ501S1027-00   [2]   PLATE Komatsu China
  ["SN: K30001-UP"]
22   TZ500S1032-00   [1]   BEARING,ROLLER Komatsu China
  ["SN: K30001-UP"]
23   04064-02212   [3]   RING,SNAP Komatsu 0.002 kg.
  ["SN: K30001-UP"]
24   04065-04518   [3]   RING,SNAP Komatsu 0.006 kg.
  ["SN: K30001-UP"]
25   04064-01410   [1]   RING,SNAP Komatsu 0.001 kg.
  ["SN: K30001-UP"]
26   TZARP568-040-9   [1]   O-RING (KIT) Komatsu China
  ["SN: K30001-UP"]
27   TZTC105-135-14   [1]   SEAL,OIL (KIT) Komatsu China
  ["SN: K30001-UP"] analogs:["TZ10513514"]
28   01010-61035   [4]   BOLT Komatsu 0.033 kg.
  ["SN: K30001-UP"] analogs:["01010E1035", "0101031035"]
