KOMATSU PW150ES-6 EXCAVATOR TRAVEL MOTOR (MOUNT) (20-30 KPH)

KOMATSU PW150ES-6 EXCAVATOR TRAVEL MOTOR (MOUNT) (20-30 KPH)

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
TRANSMISSION (MOUNT) (30 KPH) (20-30 KPH)
Pos. Part No Qty Parts name Comments
1   20E-60-K2461   [1]   TRAVEL MOTOR ASS'Y,REAR Komatsu 0.000 kg.
  ["SN: K30001-UP"]
2   20E-60-K2490   [1]   TRAVEL MOTOR ASS'Y,FRONT (SEE FIG.Y1651-01A0) Komatsu 0.000 kg.
  ["SN: K30001-UP"]
3   20E-62-K4111   [1]   BLOCK Komatsu China
  ["SN: K30001-UP"]
4   07000-13035   [2]   O-RING Komatsu China 0.03 kg.
  ["SN: K30001-UP"] analogs:["0700003035"]
5   01253-41220   [6]   BOLT Komatsu China
  ["SN: K30001-UP"] analogs:["0125371220", "7054180950"]
6   01252-41250   [2]   BOLT Komatsu China
  ["SN: K30001-UP"] analogs:["890001662", "0125201250", "0125261250", "0125231250", "0125211250", "41E6213860"]
7   01252-71245   [4]   BOLT Komatsu China
  ["SN: K30001-UP"] analogs:["3000455X"]
8   01643-31232   [4]   WASHER Komatsu 0.027 kg.
  ["SN: K30001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
9   01010-61655   [4]   BOLT Komatsu 0.119 kg.
  ["SN: K30001-UP"] analogs:["801015613", "0101031655", "0101051655", "0101081655"]
10   01643-31645   [4]   WASHER Komatsu 0.072 kg.
  ["SN: K30001-UP"] analogs:["802170005", "0164301645"]
11   20G-62-K8191   [1]   BLOCK Komatsu China
  ["SN: K30001-UP"] analogs:["20G62K8190"]
13   01010-81060   [8]   BOLT Komatsu 0.126 kg.
  ["SN: K30001-UP"] analogs:["0101051060"]
14   01643-31032   [8]   WASHER Komatsu 0.054 kg.
  ["SN: K30001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
15   07040-13316   [2]   PLUG Komatsu 0.22 kg.
  ["SN: K30001-UP"]
16   07002-13334   [2]   O-RING Komatsu China 0.025 kg.
  ["SN: K30001-UP"] analogs:["0700203334"]
Parts on group :
Pos. Part No Qty Parts name Comments
1   20G-14-K3102   [1]   TRANSMISSION ASS'Y,(SEE FIG.P1421-51A1) Komatsu China
  ["SN: K30027-UP"]
     20E-14-K1101   [1]   TRANSMISSION ASS'Y,(SEE FIG.P1421-51A1) Komatsu 0.000 kg.
  ["SN: K30001-K30026"] |1.
2   20G-47-K2170   [3]   BRACKET Komatsu China
  ["SN: K30001-UP"]
3   01010-61640   [6]   BOLT Komatsu 0.264 kg.
  ["SN: K30001-UP"] analogs:["801015186", "0101031640", "0101051640", "0101081640"]
4   01643-31645   [6]   WASHER Komatsu 0.072 kg.
  ["SN: K30001-UP"] analogs:["802170005", "0164301645"]
5   01011-61610   [3]   BOLT Komatsu 0.204 kg.
  ["SN: K30001-UP"]
7   203-62-61571   [3]   PLATE Komatsu China
  ["SN: K30001-UP"] analogs:["2036261572"]
8   203-54-21110   [6]   CUSHION Komatsu 0.085 kg.
  ["SN: K30001-UP"]
9   07000-13025   [3]   O-RING Komatsu China 0.001 kg.
  ["SN: K30001-UP"] analogs:["0700003025"]
10   20E-47-K1270   [3]   SPACER Komatsu China
  ["SN: K30001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     20G-14-K3102   [1]   TRANSMISSION ASS'Y Komatsu China
  ["SN: K30027-UP"] |1.
     20E-14-K1101   [1]   TRANSMISSION ASS'Y Komatsu 0.000 kg.
  ["SN: K30001-K30026"] |1.
   1.   20E-14-K1870   [1]   CASE Komatsu China
  ["SN: K30001-UP"]
   1A.   20E-14-K1510   [4]   PLUG Komatsu 0.000 kg.
  ["SN: K30001-UP"] analogs:["CA0030755"]
   2.   20E-14-K1550   [1]   BREATHER Komatsu 0.001 kg.
  ["SN: K30001-UP"] analogs:["CA0104988", "42T22H0P45", "20G23H0P20"]
   3.   20E-14-K1230   [10]   BOLT Komatsu China
  ["SN: K30001-UP"]
   4.   20E-14-K1410   [1]   O-RING Komatsu 0.001 kg.
  ["SN: K30001-UP"]
   5.   20E-14-K1210   [5]   BOLT Komatsu China
  ["SN: K30001-UP"] analogs:["CA0020849"]
   6.   20E-14-K1280   [3]   NUT Komatsu China
  ["SN: K30001-UP"]
   7.   20E-14-K1430   [3]   O-RING Komatsu 0.02 kg.
  ["SN: K30001-UP"] analogs:["CA0028526"]
   8.   20E-14-K1240   [6]   BOLT Komatsu China
  ["SN: K30001-UP"]
   9.   20E-14-K1930   [3]   PLUG Komatsu China
  ["SN: K30001-UP"]
   10.   20E-14-K1310   [6]   WASHER Komatsu 0.01 kg.
  ["SN: K30001-UP"] analogs:["CA0023260"]
   11.   20E-14-K1910   [1]   COVER Komatsu China
  ["SN: K30001-UP"]
   12.   20E-14-K1610   [1]   WASHER Komatsu 0.000 kg.
  ["SN: K30001-UP"]
   13.   20E-14-K1490   [1]   PLUG Komatsu 0.000 kg.
  ["SN: K30001-UP"]
   14.   20E-14-K1320   [2]   RIVET Komatsu China
  ["SN: K30001-UP"]
   15.   20E-14-K1640   [1]   PLATE Komatsu China
  ["SN: K30001-UP"]
   15A.   20E-14-K1520   [2]   LABEL Komatsu China
  ["SN: K30001-UP"]
   16.   20E-14-K1740   [1]   CASE Komatsu China
  ["SN: K30001-UP"]
   17.   20E-14-K1270   [3]   PLUG Komatsu China
  ["SN: K30001-UP"] analogs:["CA0215650", "PZFCA0215650", "20G14K3130"]
   18.   20E-14-K1530   [4]   PIN Komatsu 0.001 kg.
  ["SN: K30001-UP"] analogs:["CA0072259"]
   19.   20E-14-K1220   [5]   BOLT Komatsu China
  ["SN: K30001-UP"] analogs:["CA0020852"]
   20.   20E-14-K1750   [1]   COVER Komatsu China
  ["SN: K30001-UP"]
   21.   20E-14-K1420   [1]   O-RING Komatsu 0.002 kg.
  ["SN: K30001-UP"]
   22.   20E-14-K1580   [1]   PLUG Komatsu China
  ["SN: K30001-UP"]
   23.   20E-14-K1570   [2]   PAD Komatsu 0.01 kg.
  ["SN: K30001-UP"]
   24.   20E-14-K1790   [1]   FORK Komatsu China
  ["SN: K30001-UP"]
   25.   20E-14-K1560   [1]   BOLT Komatsu China
  ["SN: K30001-UP"] analogs:["CA0106333", "PZFCA0106333"]
   26.   20E-14-K1440   [1]   O-RING Komatsu 0.001 kg.
  ["SN: K30001-UP"] analogs:["CA0028534"]
   27.   20E-14-K1770   [1]   LEVER Komatsu China
  ["SN: K30001-UP"]
   28.   20E-14-K1940   [1]   SPACER Komatsu China
  ["SN: K30001-UP"]
   29.   20E-14-K1840   [1]   PLATE Komatsu China
  ["SN: K30001-UP"]
   30.   20E-14-K1250   [4]   BOLT Komatsu China
  ["SN: K30001-UP"]
   31.   20E-14-K2020   [1]   PLUG Komatsu China
  ["SN: K30001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     20G-14-K3102   [1]   TRANSMISSION ASS'Y Komatsu China
  ["SN: K30027-UP"] |1.
     20E-14-K1101   [1]   TRANSMISSION ASS'Y Komatsu 0.000 kg.
  ["SN: K30001-K30026"] |1.
   1.   20E-14-K1330   [1]   RING Komatsu 0.001 kg.
  ["SN: K30001-UP"] analogs:["CA0024805"]
   2.   20E-14-K1350   [1]   RING Komatsu China
  ["SN: K30001-UP"]
   3.   20E-14-K1360   [1]   BEARING Komatsu 0.45 kg.
  ["SN: K30001-UP"]
   4.   20E-14-K1880   [1]   SUPPORT Komatsu China
  ["SN: K30001-UP"]
   5.   20E-14-K1830   [2]   SPRING Komatsu 0.03 kg.
  ["SN: K30001-UP"]
   6.   20E-14-K1470   [1]   RING Komatsu China
  ["SN: K30027-UP"] analogs:["20E14K1472", "20E14K1471"]
        20E-14-K1471   [1]   RING Komatsu China
  ["SN: K30001-K30026"] analogs:["20E14K1472", "20E14K1470"] |6.
   7.   20E-14-K1450   [1]   O-RING Komatsu China
  ["SN: K30001-UP"] analogs:["20E14K1451"]
   8.   20E-14-K1290   [1]   O-RING Komatsu China
  ["SN: K30001-UP"] analogs:["20E14K1291"]
   9.   20E-14-K1480   [1]   RING Komatsu 0.01 kg.
  ["SN: K30001-UP"] analogs:["20E14K1481"]
   10.   20E-14-K1380   [1]   BEARING Komatsu 0.35 kg.
  ["SN: K30001-UP"] analogs:["CA0025809"]
   11.   20E-14-K1920   [1]   PISTON Komatsu China
  ["SN: K30001-UP"]
   12.   20E-14-K1890   [1]   PLATE Komatsu China
  ["SN: K30001-UP"]
   13.   20E-14-K1760   [1]   HUB,BRAKE Komatsu China
  ["SN: K30001-UP"]
   14.   20E-14-K1620   [2]   BOLT Komatsu 0.04 kg.
  ["SN: K30001-UP"] analogs:["CA0123918"]
   15.   20E-14-K1630   [2]   WASHER Komatsu 0.12 kg.
  ["SN: K30001-UP"] analogs:["CA0123921"]
   16.   20E-14-K1860   [2]   FLANGE Komatsu China
  ["SN: K30001-UP"]
   17.   20E-14-K1590   [2]   SEAL Komatsu 0.18 kg.
  ["SN: K30001-UP"] analogs:["CA0139420"]
   18.   20E-14-K1340   [1]   RING Komatsu China
  ["SN: K30001-UP"]
   19.   20E-14-K1680   [6]   DISC Komatsu 0.11 kg.
  ["SN: K30001-UP"]
   20.   20E-14-K1690   [6]   PLATE Komatsu 0.1 kg.
  ["SN: K30001-UP"]
   21.   20E-14-K1650   [1]   SHIM¤ 0.05MM Komatsu China
  ["SN: K30001-UP"]
        20E-14-K1660   [1]   SHIM¤ 0.10MM Komatsu China
  ["SN: K30001-UP"] |21.
        20E-14-K1670   [1]   SHIM¤ 0.20MM Komatsu China
  ["SN: K30001-UP"] |21.
   22.   20E-14-K1780   [1]   WASHER Komatsu China
  ["SN: K30001-UP"]
   23.   20E-14-K1390   [1]   BEARING Komatsu China
  ["SN: K30001-UP"]
   25.   20E-14-K1720   [1]   GEAR Komatsu China
  ["SN: K30001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     20G-14-K3102   [1]   TRANSMISSION ASS'Y Komatsu China
  ["SN: K30027-UP"] |1.
     20E-14-K1101   [1]   TRANSMISSION ASS'Y Komatsu 0.000 kg.
  ["SN: K30001-K30026"] |1.
   1.   20G-14-K3220   [1]   PLATE Komatsu 0.000 kg.
  ["SN: K30001-UP"]
   2.   20G-14-K3210   [4]   SCREW Komatsu China
  ["SN: K30027-UP"]
        20G-14-K3530   [4]   SCREW Komatsu China
  ["SN: K30001-K30026"] |2.
   4.   20G-14-K3190   [1]   PLUG Komatsu China
  ["SN: K30001-UP"] analogs:["CA0307650", "PZFCA0307650", "20E23K1470"]
   5.   20G-14-K3160   [1]   O-RING Komatsu 0.002 kg.
  ["SN: K30027-UP"]
        20G-14-K3540   [1]   O-RING Komatsu China
  ["SN: K30001-K30026"] |5.
   6.   20G-14-K3230   [4]   BOLT Komatsu China
  ["SN: K30001-UP"]
   7.   20G-14-K3490   [4]   BEARING Komatsu 0.45 kg.
  ["SN: K30001-UP"] analogs:["20E14K1360"]
   8.   20G-14-K3330   [2]   O-RING Komatsu 0.02 kg.
  ["SN: K30001-UP"] analogs:["20G14K3331"]
   9.   20G-14-K3410   [4]   SPRING Komatsu 0.11 kg.
  ["SN: K30001-UP"]
   10.   20G-14-K3180   [1]   SPACER Komatsu 0.000 kg.
  ["SN: K30001-UP"]
   11.   20G-14-K3340   [1]   SLEEVE Komatsu 0.23 kg.
  ["SN: K30001-UP"]
   12.   20G-14-K3320   [1]   O-RING Komatsu 0.001 kg.
  ["SN: K30001-UP"] analogs:["20G14K3321"]
   13.   20G-14-K3350   [1]   PISTON Komatsu 0.000 kg.
  ["SN: K30001-UP"]
   14.   20G-14-K3360   [10]   DISC Komatsu 0.52 kg.
  ["SN: K30001-UP"]
   15.   20G-14-K3370   [11]   DISC Komatsu 0.02 kg.
  ["SN: K30001-UP"]
   16.   20G-14-K3420   [1]   SHAFT Komatsu China
  ["SN: K30001-UP"]
   17.   20G-14-K3390   [1]   RING Komatsu 0.01 kg.
  ["SN: K30001-UP"]
   18.   20G-14-K3380   [1]   PLATE Komatsu 0.29 kg.
  ["SN: K30001-UP"]
   19.   20G-14-K3460   [1]   WASHER Komatsu China
  ["SN: K30001-UP"]
   20.   20G-14-K3450   [1]   BEARING Komatsu 0.1 kg.
  ["SN: K30001-UP"] analogs:["20G14K3451"]
   21.   20G-14-K3440   [1]   WASHER Komatsu China
  ["SN: K30001-UP"]
   22.   20G-14-K3170   [1]   BOLT Komatsu 0.04 kg.
  ["SN: K30001-UP"] analogs:["CA0123918"]
   23.   20G-14-K3470   [1]   HOUSING Komatsu 0.000 kg.
  ["SN: K30001-UP"]
   24.   20G-14-K3430   [2]   SEAL Komatsu 0.05 kg.
  ["SN: K30001-UP"]
   25.   20G-14-K3480   [1]   SHAFT Komatsu 3.84 kg.
  ["SN: K30001-UP"]
   26.   20G-14-K3140   [1]   RING Komatsu 0.02 kg.
  ["SN: K30001-UP"] analogs:["20E14K1950"]
Parts on group :
Pos. Part No Qty Parts name Comments
     20G-14-K3102   [1]   TRANSMISSION ASS'Y Komatsu China
  ["SN: K30027-UP"] |1.
     20E-14-K1101   [1]   TRANSMISSION ASS'Y Komatsu 0.000 kg.
  ["SN: K30001-K30026"] |1.
   1.   20G-60-K5480   [1]   PUMP Komatsu 1.02 kg.
  ["SN: K30001-UP"]
   2.   20G-14-K3290   [8]   BOLT Komatsu China
  ["SN: K30001-UP"] analogs:["CA0021375"]
   3.   20G-14-K3130   [2]   PLUG Komatsu China
  ["SN: K30001-UP"] analogs:["CA0215650", "PZFCA0215650", "20E14K1270"]
   4.   20G-14-K3310   [1]   COVER Komatsu China
  ["SN: K30001-UP"]
   5.   20G-14-K3150   [1]   PLUG Komatsu China
  ["SN: K30001-UP"]
   6.   20G-14-K3250   [4]   BOLT Komatsu 0.000 kg.
  ["SN: K30001-UP"]
   7.   20G-14-K3280   [1]   PLUG Komatsu China
  ["SN: K30001-UP"]
   8.   20G-14-K3510   [1]   HOUSING,TRANSMISSION Komatsu 0.000 kg.
  ["SN: K30001-UP"]
   9.   20G-14-K3260   [1]   GEAR Komatsu China
  ["SN: K30001-UP"]
