| TRAVEL MOTOR (MOUNT) (20 KPH) PW150ES-6K S/N K30001-UP Komatsu |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1 |
20E-60-K2510
|
[1] |
TRAVEL MOTOR ASS'Y,REAR (SEE FIG.Y1651-11A0) Komatsu
|
0.000 kg. |
|
["SN: K30001-UP"] analogs:["20E60K2511"] |
| 2 |
20E-60-K2520
|
[1] |
TRAVEL MOTOR ASS'Y,FRONT (SEE FIG.Y1651-01A0) Komatsu
|
0.000 kg. |
|
["SN: K30001-UP"] analogs:["20E60K1113"] |
| 3 |
20E-62-K4111
|
[1] |
BLOCK Komatsu China
|
|
|
["SN: K30001-UP"] |
| 4 |
07000-13035
|
[2] |
O-RING Komatsu China
|
0.03 kg. |
|
["SN: K30001-UP"] analogs:["0700003035"] |
| 5 |
01253-41220
|
[6] |
BOLT Komatsu China
|
|
|
["SN: K30001-UP"] analogs:["0125371220", "7054180950"] |
| 6 |
01252-41250
|
[2] |
BOLT Komatsu China
|
|
|
["SN: K30001-UP"] analogs:["890001662", "0125201250", "0125261250", "0125231250", "0125211250", "41E6213860"] |
| 7 |
01252-71245
|
[4] |
BOLT Komatsu China
|
|
|
["SN: K30001-UP"] analogs:["3000455X"] |
| 8 |
01643-31232
|
[4] |
WASHER Komatsu
|
0.027 kg. |
|
["SN: K30001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] |
| 9 |
01010-81650
|
[4] |
BOLT Komatsu China
|
0.113 kg. |
|
["SN: K30001-UP"] analogs:["0101061650", "0101051650", "0101031650"] |
| 10 |
01643-31645
|
[4] |
WASHER Komatsu
|
0.072 kg. |
|
["SN: K30001-UP"] analogs:["802170005", "0164301645"] |
| 11 |
20G-62-K8191
|
[1] |
BLOCK Komatsu China
|
|
|
["SN: K30001-UP"] analogs:["20G62K8190"] |
| 13 |
01010-81060
|
[8] |
BOLT Komatsu
|
0.126 kg. |
|
["SN: K30001-UP"] analogs:["0101051060"] |
| 14 |
01643-31032
|
[8] |
WASHER Komatsu
|
0.054 kg. |
|
["SN: K30001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"] |
| 15 |
07040-13316
|
[2] |
PLUG Komatsu
|
0.22 kg. |
|
["SN: K30001-UP"] |
| 16 |
07002-13334
|
[2] |
O-RING Komatsu China
|
0.025 kg. |
|
["SN: K30001-UP"] analogs:["0700203334"] |
