KOMATSU PW130ES-6K PW150ES-6K EXCAVATOR 20E-60-K2470 20E-60-K2490 20E-60-K2520 TRAVEL MOTOR ROTAYR GROUP AND SPARE PARTS

KOMATSU PW130ES-6K PW150ES-6K EXCAVATOR 20E-60-K2470 20E-60-K2490 20E-60-K2520 TRAVEL MOTOR ROTAYR GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
20E-60-K2470  20E-60-K2490  20E-60-K2520
PW130ES-6K PW150ES-6K
Pos. Part No Qty Parts name Comments
     20E-60-K2520   [1]   TRAVEL MOTOR ASS'Y,FRONT (20 KPH) Komatsu 0.000 kg.
  ["SN: K30001-UP"] analogs:["20E60K1113"] |1.
     20E-60-K2490   [1]   TRAVEL MOTOR ASS'Y,FRONT (20 KPH) Komatsu 0.000 kg.
  ["SN: K30001-UP"] |1.
     20E-60-K2470   [1]   TRAVEL MOTOR ASS'Y,FRONT (30 KPH) Komatsu 0.000 kg.
  ["SN: K30001-UP"] analogs:["20E60K1112"] |1.
   1.   20G-60-K2430   [1]   CYLINDER Komatsu 0.000 kg.
  ["SN: K30001-UP"]
   2.   20G-60-K4060   [1]   CONTROL Komatsu 0.000 kg.
  ["SN: K30001-UP"]
   3.   20G-60-K4070   [1]   PIN Komatsu 0.18 kg.
  ["SN: K30001-UP"]
   4.   20G-60-K2450   [7]   PISTON Komatsu China
  ["SN: K30001-UP"]
   5.   20G-60-K4080   [1]   SHIM Komatsu China
  ["SN: K30001-UP"]
   6.   20G-60-K4090   [1]   SPRING Komatsu 0.001 kg.
  ["SN: K30001-UP"]
   7.   20G-60-K2480   [1]   PLATE Komatsu 0.05 kg.
  ["SN: K30001-UP"]
   8.   20G-60-K2490   [14]   RING Komatsu China
  ["SN: K30001-UP"] analogs:["20E60K3060", "21P60K1870"]
   9.   20G-60-K2510   [14]   SCREW Komatsu China
  ["SN: K30001-UP"] analogs:["20E60K3530", "42R17H0S32", "42U17H0P71", "4919872M"]
   10.   20G-60-K4020   [1]   SHAFT Komatsu 0.000 kg.
  ["SN: K30001-UP"]
   11.   20G-60-K4030   [1]   SHIM Komatsu China
  ["SN: K30001-UP"] analogs:["42R17H0S58", "21P60K1570"]
   12.   20G-60-K4040   [1]   PLATE Komatsu China
  ["SN: K30001-UP"] analogs:["42R17H0S59", "42U17H0P68", "4920050M"]
   13.   20G-60-K4050   [1]   RING Komatsu China
  ["SN: K30001-UP"] analogs:["42R17H0S67"]
   14.   20E-60-K2360   [1]   VALVE Komatsu China
  ["SN: K30001-UP"] analogs:["42R17H0S05", "42U17H0P43", "4915122M", "20G60K4980", "21P60K2020"]
   15.   20E-60-K2370   [1]   BOLT Komatsu China
  ["SN: K30001-UP"]
   16.   20G-60-K3920   [1]   CONTROL Komatsu 16.7 kg.
  ["SN: K30001-UP"]
   17.   20G-60-K3930   [2]   STUD Komatsu China
  ["SN: K30001-UP"]
   18.   20G-60-K3940   [1]   HOUSING Komatsu China
  ["SN: K30001-UP"] analogs:["42R17H0S54"]
   19.   20G-60-K3950   [1]   SCREW Komatsu China
  ["SN: K30001-UP"] analogs:["26431164F", "42R17H0S18", "42U17H0P58", "4919864M", "4919846M", "PK26431164F", "PKP000879", "21P60K1540", "6810113250"]
   20.   20G-60-K3960   [1]   RING Komatsu 0.02 kg.
  ["SN: K30001-UP"]
   21.   20G-60-K1260   [1]   RING Komatsu 0.001 kg.
  ["SN: K30001-UP"] analogs:["20E60K2850"]
   22.   20G-60-K3970   [1]   PLATE Komatsu 0.9 kg.
  ["SN: K30001-UP"]
   23.   20G-60-K3980   [1]   O-RING Komatsu 0.005 kg.
  ["SN: K30001-UP"] analogs:["21P60K1530"]
   24.   20G-60-K3990   [1]   SCREW Komatsu China
  ["SN: K30001-UP"]
   25.   20G-60-K1480   [2]   NUT Komatsu China
  ["SN: K30001-UP"] analogs:["20E60K3590", "42R17H0R63", "42U17H0P59", "4915028M", "4918332M"]
   26.   20E-60-K2670   [1]   VALVE ASS'Y Komatsu 0.000 kg.
  ["SN: K30001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     20E-60-K2520   [1]   TRAVEL MOTOR ASS'Y,FRONT (20 KPH) Komatsu 0.000 kg.
  ["SN: K30001-UP"] analogs:["20E60K1113"] |1.
     20E-60-K2490   [1]   TRAVEL MOTOR ASS'Y,FRONT (20 KPH) Komatsu 0.000 kg.
  ["SN: K30001-UP"] |1.
     20E-60-K2470   [1]   TRAVEL MOTOR ASS'Y,FRONT (30 KPH) Komatsu 0.000 kg.
  ["SN: K30001-UP"] analogs:["20E60K1112"] |1.
   1.   20G-60-K2630   [1]   HOUSING Komatsu China
  ["SN: K30001-UP"] analogs:["20E60K3330"]
   2.   20G-60-K2640   [1]   BUSHING Komatsu China
  ["SN: K30001-UP"] analogs:["4905796M", "4920062M"]
   3.   20G-60-K2650   [1]   PISTON Komatsu China
  ["SN: K30001-UP"]
   4.   20G-60-K2660   [1]   BUSHING Komatsu 0.001 kg.
  ["SN: K30001-UP"]
   5.   20G-60-K2670   [1]   BOLT Komatsu China
  ["SN: K30001-UP"] analogs:["42R17H0R88", "42U17H0P19", "4919888M", "20E60K3370"]
   6.   20G-60-K4290   [1]   SPRING Komatsu China
  ["SN: K30001-UP"]
   7.   20G-60-K2690   [1]   SPRING Komatsu China
  ["SN: K30001-UP"] analogs:["42R17H0S84", "42U17H0P16", "4920058M", "20E60K3390"]
   8.   20G-60-K4310   [1]   O-RING Komatsu 0.01 kg.
  ["SN: K30001-UP"]
   9.   20G-60-K2710   [4]   SCREW Komatsu China
  ["SN: K30001-UP"] analogs:["20E60K3420"]
   10.   20G-60-K4320   [1]   SCREW Komatsu China
  ["SN: K30001-UP"] analogs:["42U17H0P11", "42U17H0R96", "4919882M", "21P60K2210"]
   11.   20G-60-K2730   [1]   RING Komatsu China
  ["SN: K30001-UP"] analogs:["20E60K2730", "42R17H0R93", "42U17H0P23", "4918622M", "20E60K2260"]
   12.   20G-60-K1490   [1]   STUD Komatsu 0.000 kg.
  ["SN: K30001-UP"]
   13.   20G-60-K2740   [1]   PIN Komatsu China
  ["SN: K30001-UP"]
   14.   20G-60-K1520   [1]   NUT Komatsu China
  ["SN: K30001-UP"] analogs:["42R17H0R27", "3031961M", "3075626M", "4903247M", "4903378M", "4912671M", "4918341M", "21P60K4620"]
   15.   20G-60-K2750   [1]   PIN Komatsu 0.000 kg.
  ["SN: K30001-UP"]
   16.   20G-60-K2760   [1]   DISC Komatsu China
  ["SN: K30001-UP"] analogs:["20E60K2320", "20E60K2760"]
   17.   20G-60-K4330   [1]   COVER Komatsu China
  ["SN: K30001-UP"]
   18.   20G-60-K4340   [1]   SCREW Komatsu China
  ["SN: K30001-UP"] analogs:["20E60K3520", "20K6032340"]
   19.   20G-60-K4350   [4]   SCREW Komatsu China
  ["SN: K30001-UP"]
   20.   20G-60-K4360   [1]   O-RING Komatsu 0.01 kg.
  ["SN: K30001-UP"]
   22.   20G-60-K4130   [2]   VALVE ASS'Y Komatsu 0.07 kg.
  ["SN: K30001-UP"] analogs:["20E60K2660"]
   23.   20G-60-K4140   [1]   PLATE Komatsu China
  ["SN: K30001-UP"]
   24.   20G-60-K4150   [1]   PISTON Komatsu China
  ["SN: K30001-UP"]
   25.   20G-60-K4160   [1]   TRUNNION Komatsu China
  ["SN: K30001-UP"] analogs:["20E60K3140"]
   26.   20G-60-K4170   [1]   RETAINER Komatsu China
  ["SN: K30001-UP"] analogs:["42U17H0P52"]
   27.   20G-60-K4180   [1]   PIN Komatsu China
  ["SN: K30001-UP"]
   28.   20G-60-K4190   [2]   PLUG Komatsu China
  ["SN: K30001-UP"] analogs:["42R17H0S38", "20E60K3180", "20K6032270"]
   29.   20G-60-K2560   [4]   SCREW Komatsu China
  ["SN: K30001-UP"] analogs:["42R17H0S78"]
   30.   20G-60-K4210   [4]   SCREW Komatsu China
  ["SN: K30001-UP"]
   31.   20G-60-K4220   [2]   O-RING Komatsu 0.002 kg.
  ["SN: K30001-UP"]
   32.   20G-60-K4230   [3]   O-RING Komatsu 0.002 kg.
  ["SN: K30001-UP"] analogs:["21P60K1510"]
   33.   20G-60-K4240   [2]   O-RING Komatsu 0.001 kg.
  ["SN: K30001-UP"]
   34.   20G-60-K4250   [1]   SCREW Komatsu China
  ["SN: K30001-UP"]
   35.   20G-60-K4260   [3]   RING Komatsu China
  ["SN: K30001-UP"] analogs:["42U17H0P53"]
   36.   20G-60-K2580   [2]   PIN Komatsu China
  ["SN: K30001-UP"] analogs:["42U17H0P44", "42R17H0S37", "4918239M"]
   37.   20G-60-K1270   [1]   PIN Komatsu China
  ["SN: K30001-UP"] analogs:["20G60K4270", "21P60K3760", "21P60K2250", "21P60K3540"]
   38.   20G-60-K2590   [1]   PIN Komatsu China
  ["SN: K30001-UP"] analogs:["42R17H0P79", "20E60K2130"]
   39.   20G-60-K4280   [1]   O-RING Komatsu 0.01 kg.
  ["SN: K30001-UP"]
   40.   20G-60-K3950   [2]   SCREW Komatsu China
  ["SN: K30001-UP"] analogs:["26431164F", "42R17H0S18", "42U17H0P58", "4919864M", "4919846M", "PK26431164F", "PKP000879", "21P60K1540", "6810113250"]
