20E-60-K2510
PW130-6K PW130ES-6K PW150ES-6K |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
20E-60-K2510
|
[1] |
TRAVEL MOTOR ASS'Y,REAR (20 KPH) Komatsu
|
0.000 kg. |
|
["SN: K30001-UP"] analogs:["20E60K2511"] |1. |
|
1. |
20E-60-K4430
|
[1] |
CYLINDER Komatsu
|
0.000 kg. |
|
["SN: K30001-UP"] |
|
2. |
20E-60-K4440
|
[1] |
CONTROL Komatsu
|
0.000 kg. |
|
["SN: K30001-UP"] |
|
3. |
20E-60-K4450
|
[1] |
PIN Komatsu China
|
|
|
["SN: K30001-UP"] |
|
4. |
20E-60-K4460
|
[7] |
PISTON Komatsu China
|
|
|
["SN: K30001-UP"] |
|
5. |
20E-60-K4470
|
[1] |
SHIM Komatsu China
|
|
|
["SN: K30001-UP"] |
|
6. |
20E-60-K4480
|
[1] |
SPRING Komatsu China
|
|
|
["SN: K30001-UP"] |
|
7. |
20E-60-K4490
|
[1] |
PLATE Komatsu China
|
|
|
["SN: K30001-UP"] |
|
8. |
20E-60-K4510
|
[14] |
RING Komatsu China
|
|
|
["SN: K30001-UP"] analogs:["20E60K3490", "4919873M"] |
|
9. |
20G-60-K4680
|
[14] |
SCREW Komatsu China
|
|
|
["SN: K30001-UP"] |
|
10. |
20E-60-K2550
|
[1] |
SHAFT Komatsu China
|
|
|
["SN: K30001-UP"] |
|
11. |
20E-60-K2620
|
[1] |
SHIM Komatsu China
|
|
|
["SN: K30001-UP"] |
|
12. |
20E-60-K2630
|
[1] |
PLATE Komatsu China
|
|
|
["SN: K30001-UP"] |
|
13. |
20E-60-K2640
|
[1] |
RING Komatsu China
|
|
|
["SN: K30001-UP"] analogs:["42U17H0R68"] |
|
14. |
20E-60-K2650
|
[1] |
BEARING Komatsu China
|
|
|
["SN: K30001-UP"] |
|
15. |
20E-60-K4420
|
[1] |
BEARING Komatsu
|
0.000 kg. |
|
["SN: K30001-UP"] |
|
16. |
20G-60-K3920
|
[1] |
CONTROL Komatsu
|
16.7 kg. |
|
["SN: K30001-UP"] |
|
17. |
20E-60-K1930
|
[2] |
STUD Komatsu
|
0.000 kg. |
|
["SN: K30001-UP"] analogs:["21P60K2670"] |
|
18. |
20E-60-K2570
|
[1] |
HOUSING Komatsu China
|
|
|
["SN: K30001-UP"] |
|
19. |
20G-60-K4450
|
[1] |
SCREW Komatsu China
|
|
|
["SN: K30001-UP"] analogs:["21P60K2310"] |
|
20. |
20G-60-K4460
|
[1] |
RING Komatsu
|
0.04 kg. |
|
["SN: K30001-UP"] |
|
21. |
20G-60-K4470
|
[1] |
SEAL Komatsu OEM
|
0.3 kg. |
|
["SN: K30001-UP"] analogs:["20E60K6640"] |
|
22. |
20G-60-K4480
|
[1] |
PLATE Komatsu
|
0.05 kg. |
|
["SN: K30001-UP"] |
|
23. |
20E-60-K2580
|
[1] |
O-RING Komatsu
|
0.005 kg. |
|
["SN: K30001-UP"] |
|
24. |
20G-60-K4510
|
[1] |
SCREW Komatsu China
|
|
|
["SN: K30001-UP"] analogs:["42R17H0R61"] |
|
25. |
20G-60-K1480
|
[2] |
NUT Komatsu China
|
|
|
["SN: K30001-UP"] analogs:["20E60K3590", "42R17H0R63", "42U17H0P59", "4915028M", "4918332M"] |
