KOMATSU PC78US-8 EXCAVATOR TRAVEL REDUCTION GEAR

KOMATSU PC78US-8 EXCAVATOR TRAVEL REDUCTION GEAR

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group :
Pos. Part No Qty Parts name Comments
     22P-60-11301   [2]   Motor Assembly Komatsu 83 kg.
  ["SN: 15001-UP"] |$0.
        TZ119D1000-00   [1]   Final Drive Assembly Komatsu China
  ["SN: 15001-UP"] |$1.
     TZ192-230-30BA   [1]   Floating Seal Assembly, (Kit : K01) Komatsu China
  ["SN: 15001-UP"] |$2.
2   TZ115D1001-00   [1]   Hub Komatsu China
  ["SN: 15001-UP"]
3   TZ115D1002-00   [1]   Spindle Komatsu China
  ["SN: 15001-UP"]
4   TZ111D1003-00   [1]   Carrier Komatsu China
  ["SN: 15001-UP"]
5   TZ111D1004-00   [1]   Gear, Sun Komatsu China
  ["SN: 15001-UP"]
6   TZ111D1005-00   [3]   Gear, Planetary Komatsu China
  ["SN: 15001-UP"]
7   TZ110D1006-00   [1]   Gear, Sun Komatsu China
  ["SN: 15001-UP"]
8   TZ110D1007-00   [4]   Gear, Planetary Komatsu China
  ["SN: 15001-UP"]
9   TZ400G1009-00   [1]   Collar Komatsu China
  ["SN: 15001-UP"]
10   TZ110D1010-00   [4]   Washer, Thrust Komatsu China
  ["SN: 15001-UP"]
11   TZ110D1011-00   [4]   Washer, Thrust Komatsu China
  ["SN: 15001-UP"]
12   TZ440D1012-00   [3]   Washer, Thrust Komatsu China
  ["SN: 15001-UP"]
13   TZ110D1013-00   [1]   Cover Komatsu China
  ["SN: 15001-UP"]
14   TZ110D1022-00   [1]   Nut, Ring Komatsu China
  ["SN: 15001-UP"]
15   TZ110D1024-00   [2]   Bearing Komatsu China
  ["SN: 15001-UP"]
16   TZ110D1027-00   [3]   Bearing Komatsu China
  ["SN: 15001-UP"]
17   TZ110D1028-00   [4]   Bearing Komatsu China
  ["SN: 15001-UP"]
18   TZ110D1029-00   [3]   Ring Komatsu China
  ["SN: 15001-UP"]
19   TZ110D1030-00   [4]   Ring Komatsu China
  ["SN: 15001-UP"]
20   TZ410D1033-01   [1]   Plug Komatsu China
  ["SN: 15001-UP"]
21   07000-05230   [1]   O-ring, (Kit : K01) Komatsu China 0.03 kg.
  ["SN: 15001-UP"] analogs:["0700015230"]
22   07000-12014   [3]   O-ring, (Kit : K01) Komatsu China 0.01 kg.
  ["SN: 15001-UP"] analogs:["0700002014"]
23   TZ810B2021-00   [2]   Plug Komatsu 0.03 kg.
  ["SN: 15001-UP"]
24   TZ1180082010L2   [3]   Bolt Komatsu China
  ["SN: 15001-UP"]
25   04260-00952   [1]   Ball Komatsu 0.004 kg.
  ["SN: 15001-UP"] analogs:["890001277"]
26   TZ263B2077-01   [2]   Pin, Dowel Komatsu 0.005 kg.
  ["SN: 15001-UP"]
27   07000-11007   [2]   O-ring, (Kit : K01) Komatsu 0.001 kg.
  ["SN: 15001-UP"] analogs:["YM24311000070", "0700001007"]
28   TZJW1516-G37-7   [1]   O-ring, (Kit : K01) Komatsu 0.02 kg.
  ["SN: 15001-UP"]
29   TZ810B1018-00   [1]   Ring Komatsu 0.06 kg.
  ["SN: 15001-UP"]
30   TZJB1177M812-B   [2]   Screw, Hexagon Socket Head Komatsu China
  ["SN: 15001-UP"]
31   04064-04518   [1]   Ring, Snap Komatsu China 0.007 kg.
  ["SN: 15001-UP"] analogs:["20Y3029190"]
32   TZ1180102010L   [4]   Bolt Komatsu China
  ["SN: 15001-UP"]
