| Parts on group : |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
21W-60-41201
|
[1] |
MOTOR ASS'Y Komatsu
|
81 kg. |
|
["SN: 4001-UP"] analogs:["21W6041202"] |1. |
|
|
TZ507D1000-02
|
[1] |
FINAL DRIVE ASS'Y Komatsu
|
130 kg. |
|
["SN: 4001-UP"] |1. |
| 3 |
TZ500D1019-00
|
[3] |
BOLT,REAMER Komatsu China
|
|
|
["SN: 4001-UP"] |
| |
TZ507D1107-00
|
[1] |
SPUR GEAR KIT Komatsu
|
1.73 kg. |
|
["SN: 4001-UP"] |10. |
| |
TZES20423232-B
|
[1] |
FLOATING SEAL ASS'Y Komatsu
|
1.5 kg. |
|
["SN: 4001-UP"] |11. |
| 11 |
TZES100-204-B
|
[2] |
SEAL,FLOATING (KIT) Komatsu China
|
|
|
["SN: 4001-UP"] |
| 12 |
TZ507D1001-00
|
[1] |
HUB,MOTOR Komatsu China
|
|
|
["SN: 4001-UP"] |
| 13 |
TZ507D1006-00
|
[1] |
GEAR Komatsu China
|
|
|
["SN: 4001-UP"] |
| 14 |
TZ500D1008-00
|
[1] |
COVER Komatsu China
|
|
|
["SN: 4001-UP"] |
| 15 |
TZ500D1015-00
|
[1] |
SHAFT Komatsu China
|
|
|
["SN: 4001-UP"] |
| 16 |
TZ500D1017-00
|
[28] |
PIN Komatsu China
|
|
|
["SN: 4001-UP"] |
| 17 |
TZ810B1018-00
|
[1] |
RING Komatsu
|
0.06 kg. |
|
["SN: 4001-UP"] |
| 20 |
TZJB2804-S19
|
[1] |
RING,SNAP Komatsu
|
0.002 kg. |
|
["SN: 4001-UP"] |
| 21 |
04064-02512
|
[6] |
RING,SNAP Komatsu
|
0.002 kg. |
|
["SN: 4001-UP"] |
| 22 |
07000-11008
|
[2] |
O-RING (KIT) Komatsu China
|
0.01 kg. |
|
["SN: 4001-UP"] analogs:["0700001008", "2016018950"] |
| 23 |
07000-15230
|
[1] |
O-RING (KIT) Komatsu China
|
0.03 kg. |
|
["SN: 4001-UP"] analogs:["0700005230"] |
| 24 |
TZJW1516-G35-7
|
[1] |
O-RING (KIT) Komatsu China
|
|
|
["SN: 4001-UP"] |
| 25 |
TZ410D1033-01
|
[1] |
PLUG Komatsu China
|
|
|
["SN: 4001-UP"] |
| 26 |
TZ810B2021-00
|
[2] |
PLUG Komatsu
|
0.03 kg. |
|
["SN: 4001-UP"] |
| 27 |
07000-12014
|
[3] |
O-RING (KIT) Komatsu China
|
0.01 kg. |
|
["SN: 4001-UP"] analogs:["0700002014"] |
| 28 |
04260-00952
|
[1] |
BALL Komatsu
|
0.004 kg. |
|
["SN: 4001-UP"] analogs:["890001277"] |
| 29 |
TZJ1354-8-22
|
[2] |
PIN Komatsu China
|
|
|
["SN: 4001-UP"] |
| K. |
TZ505D9000-00
|
[1] |
SEAL KIT Komatsu
|
1.68 kg. |
|
["SN: 4001-UP"] |
