KOMATSU PC58UU-3 EXCAVATOR SWING MACHINERY (INNER PARTS)

Name: KOMATSU PC58UU-3 EXCAVATOR SWING MACHINERY (INNER PARTS)
Brand: +8613035309093
Price: 5000.0 USD
Availability: InStock

KOMATSU PC58UU-3 EXCAVATOR SWING MACHINERY (INNER PARTS)

$5,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量



Pos.	Part No	Qty	Parts name	Comments
1	20U-26-00121	[1]	SWING MACHINERY A. Komatsu China
			["SN: 20001-UP"]
2	01010-81245	[8]	BOLT Komatsu	0.056 kg.
			["SN: 20001-UP"] analogs:["0101051245", "801015574"]
3	01643-31232	[8]	WASHER Komatsu	0.027 kg.
			["SN: 20001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
Parts on group : Parts on group :SWING MACHINERY AND RELATED PARTS PC58UU-3 S/N 20001-UP (For North America) Komatsu

Pos.	Part No	Qty	Parts name	Comments
	20U-26-00121	[1]	SWING MACHINERY A. Komatsu China
			["SN: 20001-UP"] \|$2.
1.	20T-26-81180	[1]	CARRIER Komatsu China
			["SN: 20001-UP"]
2.	20T-26-81121	[3]	GEAR Komatsu China
			["SN: 20001-UP"]
3.	20S-26-81260	[3]	PIN Komatsu China
			["SN: 20001-UP"]
4.	20T-26-81430	[3]	BEARING Komatsu China
			["SN: 20001-UP"]
5.	20S-26-71160	[12]	WASHER Komatsu	0.01 kg.
			["SN: 20001-UP"]
6.	20S-26-71190	[6]	RING Komatsu	0.01 kg.
			["SN: 20001-UP"]
7.	20S-26-71250	[6]	PIN Komatsu China
			["SN: 20001-UP"] analogs:["890001458"]
8.	20T-26-81190	[1]	CARRIER Komatsu China
			["SN: 20001-UP"]
9.	20T-26-81140	[3]	GEAR Komatsu China
			["SN: 20001-UP"]
10.	20T-26-81250	[3]	PIN Komatsu China
			["SN: 20001-UP"]
11.	20T-26-71190	[3]	BEARING Komatsu China
			["SN: 20001-UP"] analogs:["R20T2671190"]
12.	20T-26-81151	[1]	GEAR Komatsu China
			["SN: 20001-UP"] analogs:["20T2681150"]
13.	20T-26-81231	[1]	SPACER Komatsu China
			["SN: 20001-UP"]
14.	20U-26-32110	[1]	SHAFT Komatsu China
			["SN: 20001-UP"]
15.	20T-26-71221	[1]	BEARING Komatsu China
			["SN: 20001-UP"]
16.	20U-26-31150	[1]	BEARING Komatsu China
			["SN: 20001-UP"]
17.	20T-26-81210	[1]	SEAL Komatsu	0.1 kg.
			["SN: 20001-UP"]
18.	20U-26-31160	[1]	CASE Komatsu China
			["SN: 20001-UP"]
19.	01253-61210	[5]	BOLT Komatsu	0.115 kg.
			["SN: 20001-UP"]
20.	01252-61290	[2]	BOLT Komatsu China
			["SN: 20001-UP"] analogs:["890001864", "0125251290", "0125241290", "0125231290", "7051702750"]
21.	01643-51232	[7]	WASHER Komatsu	0.024 kg.
			["SN: 20001-UP"]
22.	20T-26-81240	[2]	WASHER Komatsu China
			["SN: 20001-UP"]
23.	20U-26-31140	[1]	SEAL Komatsu China
			["SN: 20001-UP"]
24.	20T-26-81110	[1]	GEAR Komatsu China
			["SN: 20001-UP"]
25.	20T-26-81130	[1]	GEAR Komatsu China
			["SN: 20001-UP"]
26.	07049-01215	[2]	PLUG Komatsu	0.001 kg.
			["SN: 20001-UP"]
27.	04064-04018	[1]	RING,SNAP Komatsu	0.001 kg.
			["SN: 20001-UP"] analogs:["802250040"]
28.	04020-01434	[2]	PIN,DOWEL Komatsu	0.044 kg.
			["SN: 20001-UP"]
29.	708-7R-00340	[1]	MOTOR ASS'Y Komatsu China
			["SN: 20001-UP"]
30.	20S-26-81310	[1]	RING Komatsu China
			["SN: 20001-UP"]
31.	708-7T-51210	[1]	O-RING Komatsu	0.01 kg.
			["SN: 20001-UP"]
32.	02783-10315	[1]	ELBOW Komatsu	0.12 kg.
			["SN: 20001-UP"]
33.	02896-11009	[1]	O-RING Komatsu China	0.01 kg.
			["SN: 20001-UP"] analogs:["R0289611009", "0286911009"]
34.	07002-12034	[1]	O-RING Komatsu China	0.94 kg.
			["SN: 20001-UP"] analogs:["0700002034", "0700202034", "0700012034"]
35.	21X-62-21140	[1]	ELBOW Komatsu	0.9 kg.
			["SN: 20001-UP"]
36.	02782-10315	[1]	ELBOW Komatsu	0.156 kg.
			["SN: 20001-UP"]
39.	02782-10210	[1]	ELBOW Komatsu	0.08 kg.
			["SN: 20001-UP"]
40.	02896-11008	[1]	O-RING Komatsu China	0.12 kg.
			["SN: 20001-UP"]
41.	07002-11423	[1]	O-RING Komatsu China	0.001 kg.
			["SN: 20001-UP"] analogs:["0700201423"]
42.	02783-10210	[1]	ELBOW Komatsu	0.06 kg.
			["SN: 20001-UP"]
