KOMATSU  PC58UU-3 EXCAVATOR 708-7R-00340 SWING MOTOR ROTARY GROUP

KOMATSU  PC58UU-3 EXCAVATOR 708-7R-00340 SWING MOTOR ROTARY GROUP

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
708-7R-00340  PC58UU-3
Pos. Part No Qty Parts name Comments
     708-7R-00340   [1]   MOTOR ASS'Y Komatsu China
  ["SN: 20001-UP"] |$1.
1   708-7R-11630   [1]   PLATE,SWASH Komatsu China
  ["SN: 20001-UP"]
2   708-7R-11710   [1]   WASHER Komatsu China
  ["SN: 20001-UP"]
3   708-7R-11720   [1]   FILTER Komatsu China
  ["SN: 20001-UP"]
     708-7R-04120   [1]   HOUSING SUB ASS'Y Komatsu China
  ["SN: 20001-UP"] |$8.
6   708-7R-11220   [2]   PLUG Komatsu China
  ["SN: 20001-UP"] analogs:["890001927"]
7   07002-11223   [2]   O-RING Komatsu China 0.001 kg.
  ["SN: 20001-UP"] analogs:["0700201223"]
8   708-7R-11210   [2]   VALVE Komatsu 0.07 kg.
  ["SN: 20001-UP"]
9   722-10-91130   [2]   SPRING Komatsu China
  ["SN: 20001-UP"]
10   709-32-12861   [2]   PLUG Komatsu China
  ["SN: 20001-UP"]
11   07002-11823   [2]   O-RING Komatsu 0.36 kg.
  ["SN: 20001-UP"] analogs:["0700201823"]
     708-7R-03020   [2]   VALVE SUB ASS'Y Komatsu China
  ["SN: 20001-UP"] analogs:["7087R11240", "7087R11230"] |$17.
14   708-7R-11250   [1]   PLUG Komatsu China
  ["SN: 20001-UP"]
16   708-7R-11270   [2]   PLUG Komatsu China
  ["SN: 20001-UP"]
18   431-40-11210   [1]   O-RING Komatsu China
  ["SN: 20001-UP"] analogs:["0289102126"]
19   720-68-19610   [2]   PIN Komatsu 0.002 kg.
  ["SN: 20001-UP"]
20   01252-61230   [8]   BOLT Komatsu 0.044 kg.
  ["SN: 20001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-7R-00340   [1]   MOTOR ASS'Y Komatsu China
  ["SN: 20001-UP"] |$1.
1   708-7R-12111   [1]   SHAFT Komatsu China
  ["SN: 20001-UP"] analogs:["7087R12130"]
2   708-7R-12140   [1]   BEARING Komatsu China
  ["SN: 20001-UP"]
3   708-7R-12150   [1]   BEARING Komatsu China
  ["SN: 20001-UP"]
4   04065-04218   [1]   RING,SNAP Komatsu 0.005 kg.
  ["SN: 20001-UP"]
5 708-7R-13111 [1]   BLOCK,CYLINDER Komatsu China
  ["SN: 20001-UP"]
6   708-7R-13220   [1]   PLATE,VALVE Komatsu China
  ["SN: 20001-UP"]
7   720-68-19610   [1]   PIN Komatsu 0.002 kg.
  ["SN: 20001-UP"]
8   708-7R-13540   [3]   PIN Komatsu China
  ["SN: 20001-UP"]
9   708-7R-13530   [2]   WASHER Komatsu China
  ["SN: 20001-UP"]
10   708-7R-13560   [1]   SPRING Komatsu China
  ["SN: 20001-UP"]
11   04065-03012   [1]   RING Komatsu 0.002 kg.
  ["SN: 20001-UP"] analogs:["802250530", "YM22252000300"]
12   708-7R-13590   [1]   GUIDE,RETAINER Komatsu China
  ["SN: 20001-UP"] analogs:["7087R13510"]
13   708-7R-13340   [1]   RETAINER,SHOE Komatsu China
  ["SN: 20001-UP"]
14   708-7R-13310   [7]   PISTON SUB ASS'Y Komatsu China
  ["SN: 20001-UP"]
15   708-7R-13420   [1]   PLATE,THRUST Komatsu China
  ["SN: 20001-UP"]
16   708-7R-15131   [4]   PLATE Komatsu 0.05 kg.
  ["SN: 20001-UP"] analogs:["7087R15130"]
17   708-7R-15122   [3]   DISC Komatsu 0.033 kg.
  ["SN: 20001-UP"]
18   708-7R-15180   [1]   PISTON,BRAKE Komatsu China
  ["SN: 20001-UP"]
19   07000-12115   [1]   O-RING Komatsu OEM 0.004 kg.
  ["SN: 20001-UP"] analogs:["0700002115"]
20   07000-12095   [1]   O-RING Komatsu China 0.003 kg.
  ["SN: 20001-UP"] analogs:["0700002095"]
21   708-7R-15150   [12]   SPRING Komatsu China
  ["SN: 20001-UP"]
22   708-7R-15160   [1]   RING Komatsu China
  ["SN: 20001-UP"]
23   708-7R-15712   [1]   PISTON Komatsu China
  ["SN: 20001-UP"]
24   708-7R-15722   [1]   SPRING Komatsu China
  ["SN: 20001-UP"]
     708-7R-03010   [1]   VALVE SUB ASS'Y Komatsu China
  ["SN: 20001-UP"] |$28.
27   708-7R-15670   [1]   SPRING Komatsu China
  ["SN: 20001-UP"]
28   706-73-72680   [1]   PLUG Komatsu China
  ["SN: 20001-UP"]
29   07002-11223   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: 20001-UP"] analogs:["0700201223"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-7R-00340   [1]   MOTOR ASS'Y Komatsu China
  ["SN: 20001-UP"] |$1.
        702-73-04141   [1]   VALVE ASS'Y,RELIEF Komatsu China
  ["SN: 20001-UP"] analogs:["7027304140"] |$3.
18   07000-12016   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 20001-UP"] analogs:["YM24311000160", "0700002016"]
19   723-60-22230   [1]   RING,BACK-UP Komatsu 0.001 kg.
  ["SN: 20001-UP"]
20   07002-12434   [1]   O-RING Komatsu China 0.01 kg.
  ["SN: 20001-UP"] analogs:["0700202434", "0700213434"]
   21.   02782-10315   [1]   ELBOW Komatsu 0.156 kg.
  ["SN: 20001-UP"]
   22.   07002-12034   [1]   O-RING Komatsu China 0.94 kg.
  ["SN: 20001-UP"] analogs:["0700002034", "0700202034", "0700012034"]
   23.   02896-11009   [1]   O-RING Komatsu China 0.01 kg.
  ["SN: 20001-UP"] analogs:["R0289611009", "0286911009"]
   24.   708-7R-11380   [1]   PLATE Komatsu China
  ["SN: 20001-UP"]
   25.   07000-11007   [3]   O-RING Komatsu 0.001 kg.
  ["SN: 20001-UP"] analogs:["YM24311000070", "0700001007"]
   26.   01252-60825   [2]   BOLT Komatsu 0.017 kg.
  ["SN: 20001-UP"] analogs:["0125240825", "0125230825"]
