KOMATSU PC58UU-3 EXCAVATOR 708-3S-00411 708-3S-01411 HYDRAULIC PUMP ASSY PARTS

KOMATSU PC58UU-3 EXCAVATOR 708-3S-00411 708-3S-01411 HYDRAULIC PUMP ASSY PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
708-3S-00411 708-3S-01411
PC58UU-3
Pos. Part No Qty Parts name Comments
1   708-3S-00411   [1]   PUMP ASS'Y Komatsu 34.601 kg.
  ["SN: 20001-UP"] analogs:["7083S00912"]
2   01010-81240   [2]   BOLT Komatsu 0.052 kg.
  ["SN: 20001-UP"] analogs:["801015573", "0101051240"]
3   01643-31232   [2]   WASHER Komatsu 0.027 kg.
  ["SN: 20001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
4   20U-62-41960   [1]   ELBOW Komatsu China
  ["SN: 20001-UP"]
5   20U-62-41950   [1]   ELBOW Komatsu China
  ["SN: 20001-UP"]
6   07002-12034   [2]   O-RING Komatsu China 0.94 kg.
  ["SN: 20001-UP"] analogs:["0700002034", "0700202034", "0700012034"]
7   20U-62-41910   [1]   ELBOW Komatsu China
  ["SN: 20001-UP"]
8   11Y-62-12730   [1]   ORIFICE Komatsu 0.001 kg.
  ["SN: 20001-UP"]
9   02782-10210   [1]   ELBOW Komatsu 0.08 kg.
  ["SN: 20001-UP"]
10   203-62-58880   [2]   ADAPTER Komatsu China
  ["SN: 20001-UP"]
11   07002-11423   [4]   O-RING Komatsu China 0.001 kg.
  ["SN: 20001-UP"] analogs:["0700201423"]
12   20U-62-41651   [1]   ELBOW Komatsu China
  ["SN: 20001-UP"]
13   07002-11823   [2]   O-RING Komatsu 0.36 kg.
  ["SN: 20001-UP"] analogs:["0700201823"]
14   20U-62-41860   [1]   ELBOW Komatsu China
  ["SN: 20001-UP"]
15   02896-11012   [2]   O-RING Komatsu China 0.17 kg.
  ["SN: 20001-UP"] analogs:["855051014"]
16   02896-11009   [3]   O-RING Komatsu China 0.01 kg.
  ["SN: 20001-UP"] analogs:["R0289611009", "0286911009"]
17   02896-11008   [1]   O-RING Komatsu China 0.12 kg.
  ["SN: 20001-UP"]
18   07040-11007   [3]   PLUG Komatsu 0.014 kg.
  ["SN: 20001-UP"]
19   07002-11023   [3]   O-RING Komatsu China 0.025 kg.
  ["SN: 20001-UP"] analogs:["0700201023"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-3S-00411   [1]   PUMP ASS'Y Komatsu 34.601 kg.
  ["SN: 20001-UP"] analogs:["7083S00912"] |$1.
        708-3S-01411   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 20001-UP"] |$4.
     708-3S-04170   [1]   CASE SUB ASS'Y Komatsu China
  ["SN: 20001-UP"] |$5.
4   708-1S-13411   [1]   CAM,ROCKER Komatsu 1.2 kg.
  ["SN: 20001-UP"]
5   04260-01270   [1]   BALL Komatsu OEM 0.009 kg.
  ["SN: 20001-UP"]
6   708-1S-14611   [1]   SPACER Komatsu 0.03 kg.
  ["SN: 20001-UP"] analogs:["7083S14140"]
7   708-1S-13420   [2]   PIN Komatsu China
  ["SN: 20001-UP"]
8   01252-60616   [1]   BOLT Komatsu 0.007 kg.
  ["SN: 20001-UP"] analogs:["0125230616"]
9   01252-61235   [4]   BOLT Komatsu 0.048 kg.
  ["SN: 20001-UP"] analogs:["801105554", "0125231235"]
10   04020-01024   [2]   PIN Komatsu 0.015 kg.
  ["SN: 20001-UP"] analogs:["PZF890001197"]
11   07000-11006   [5]   O-RING Komatsu 0.01 kg.
  ["SN: 20001-UP"] analogs:["0700001006"]
12   07000-12125   [1]   O-RING Komatsu OEM 0.005 kg.
  ["SN: 20001-UP"] analogs:["0700002125E", "0700002125"]
     708-3S-04272   [1]   CAP SUB ASS'Y Komatsu 7 kg.
  ["SN: 20001-UP"] |$18.
15   708-21-12760   [1]   BEARING Komatsu 0.086 kg.
  ["SN: 20001-UP"]
16   720-68-19610   [1]   PIN Komatsu 0.002 kg.
  ["SN: 20001-UP"]
17   708-1S-13430   [2]   BALL Komatsu China
  ["SN: 20001-UP"]
18   708-7T-16460   [2]   BALL Komatsu 0.003 kg.
  ["SN: 20001-UP"]
19   708-3S-11530   [2]   PLUG Komatsu China
  ["SN: 20001-UP"]
20   07000-11010   [2]   O-RING Komatsu 0.001 kg.
  ["SN: 20001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-3S-00411   [1]   PUMP ASS'Y Komatsu 34.601 kg.
  ["SN: 20001-UP"] analogs:["7083S00912"] |$1.
        708-3S-01411   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 20001-UP"] |$3.
1   708-3S-12121   [1]   SHAFT Komatsu China
  ["SN: 20001-UP"]
2   708-3S-12210   [1]   BEARING Komatsu 0.4 kg.
  ["SN: 20001-UP"]
3   708-21-12840   [1]   RING,SNAP Komatsu China
  ["SN: 20001-UP"]
4   708-1S-19910   [1]   HOLDER Komatsu 0.2 kg.
  ["SN: 20001-UP"]
5   207-09-11140   [1]   O-RING Komatsu 0.002 kg.
  ["SN: 20001-UP"]
6   708-7T-12230   [1]   SEAL,OIL Komatsu 0.04 kg.
  ["SN: 20001-UP"]
7   04065-06220   [1]   RING Komatsu 0.013 kg.
  ["SN: 20001-UP"]
8 708-3S-13120 [1]   BLOCK,CYLINDER Komatsu China
  ["SN: 20001-UP"]
9 708-3S-13230 [1]   PLATE,VALVE Komatsu 0.22 kg.
  ["SN: 20001-UP"]
10   708-3S-13160   [2]   WASHER Komatsu China
  ["SN: 20001-UP"]
11   708-3S-13150   [1]   SPRING Komatsu 0.15 kg.
  ["SN: 20001-UP"]
12   04065-03515   [1]   RING,SNAP Komatsu 0.003 kg.
  ["SN: 20001-UP"]
13   708-3S-13370   [1]   GUIDE,RETAINER Komatsu 0.14 kg.
  ["SN: 20001-UP"] analogs:["7081S13370"]
14   708-1S-13380   [3]   PIN Komatsu 0.06 kg.
  ["SN: 20001-UP"]
15   708-3S-13410   [1]   RETAINER,SHOE Komatsu 0.24 kg.
  ["SN: 20001-UP"]
16 708-1S-13320 [10]   PISTON SUB ASS'Y Komatsu 0.09 kg.
  ["SN: 20001-UP"] analogs:["R7081S13320"]
17   708-1S-14210   [1]   PLUG Komatsu China
  ["SN: 20001-UP"]
18   708-1S-14220   [1]   PLUG Komatsu China
  ["SN: 20001-UP"]
19   07002-11223   [2]   O-RING Komatsu China 0.001 kg.
  ["SN: 20001-UP"] analogs:["0700201223"]
20   708-1S-14230   [1]   PISTON SUB ASS'Y Komatsu 0.087 kg.
  ["SN: 20001-UP"] analogs:["7083S14250"]
21   708-1S-14241   [1]   SPRING Komatsu 0.01 kg.
  ["SN: 20001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-3S-00411   [1]   PUMP ASS'Y Komatsu 34.601 kg.
  ["SN: 20001-UP"] analogs:["7083S00912"] |$1.
        708-3S-03454   [1]   VALVE ASS'Y Komatsu China
  ["SN: 20001-UP"] analogs:["7083S03450", "7083S03452", "7083S03453", "7083S03451"] |$3.
     708-3S-03940   [1]   PISTON SUB ASS'Y Komatsu China
  ["SN: 20001-UP"] |$8.
6   07002-11623   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: 20001-UP"] analogs:["0700201623"]
7   708-1S-15390   [3]   SEAL Komatsu 0.001 kg.
  ["SN: 20001-UP"]
17   708-1S-15290   [1]   PLUG Komatsu China
  ["SN: 20001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-3S-00411   [1]   PUMP ASS'Y Komatsu 34.601 kg.
  ["SN: 20001-UP"] analogs:["7083S00912"] |$1.
        708-3S-03454   [1]   VALVE ASS'Y Komatsu China
  ["SN: 20001-UP"] analogs:["7083S03450", "7083S03452", "7083S03453", "7083S03451"] |$3.
9   702-21-55911   [1]   SOLENOID Komatsu 0.34 kg.
  ["SN: 20001-UP"] analogs:["7022157410"]
10   10S-914-4290   [1]   O-RING Komatsu China
  ["SN: 20001-UP"]
15   01252-60612   [2]   BOLT Komatsu 0.006 kg.
  ["SN: 20001-UP"]
17   708-3S-15920   [1]   ORIFICE Komatsu China
  ["SN: 20001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-3S-00411   [1]   PUMP ASS'Y Komatsu 34.601 kg.
  ["SN: 20001-UP"] analogs:["7083S00912"] |$1.
   1.   708-2L-25480   [6]   FILTER Komatsu OEM 0.5 kg.
  ["SN: 20001-UP"]
   2.   708-2L-25490   [6]   O-RING Komatsu 0.001 kg.
  ["SN: 20001-UP"]
   3.   708-1S-19710   [1]   ORIFICE Komatsu 0.002 kg.
  ["SN: 20001-UP"]
   4.   01252-60640   [4]   BOLT Komatsu 0.012 kg.
  ["SN: 20001-UP"]
   5.   07000-13040   [1]   O-RING Komatsu China 0.002 kg.
  ["SN: 20001-UP"] analogs:["0700003040", "0700003040E", "YM24311000400"]
   6.   04020-00616   [2]   PIN Komatsu 0.004 kg.
  ["SN: 20001-UP"]
   7.   07000-11008   [1]   O-RING Komatsu China 0.01 kg.
  ["SN: 20001-UP"] analogs:["0700001008", "2016018950"]
   8.   708-3S-04541   [1]   PUMP ASS'Y Komatsu 4.8 kg.
  ["SN: 20001-UP"] analogs:["7083S04571", "7083S04570", "7083S04573", "7083S04572"]
   9.   708-1T-19210   [1]   COUPLING Komatsu China
  ["SN: 20001-UP"] analogs:["890001673"]
   10.   700-30-63140   [1]   RING,SNAP Komatsu China
  ["SN: 20001-UP"] analogs:["890001674"]
   11.   708-1T-19230   [1]   RING Komatsu China
  ["SN: 20001-UP"] analogs:["890001675", "7081T19220"]
   12.   07000-12014   [1]   O-RING Komatsu China 0.01 kg.
  ["SN: 20001-UP"] analogs:["0700002014"]
   13.   07000-12070   [1]   O-RING Komatsu China 0.03 kg.
  ["SN: 20001-UP"] analogs:["0700002070"]
   14.   01010-80830   [4]   BOLT Komatsu 0.017 kg.
  ["SN: 20001-UP"] analogs:["6735511120", "0101050830", "0737200830", "1240145H1"]
   15.   01643-30823   [4]   WASHER Komatsu 0.004 kg.
  ["SN: 20001-UP"] analogs:["802070008", "802150008", "0160510818", "0164310823", "802170001", "01643A0823"]
   17.   708-3S-19110   [1]   ORIFICE Komatsu China
  ["SN: 20001-UP"]
   18.   708-3S-15810   [2]   PLUG Komatsu China
  ["SN: 20001-UP"]
   19.   708-3S-15820   [2]   NUT Komatsu China
  ["SN: 20001-UP"]
   20.   07000-11003   [2]   O-RING Komatsu 0.001 kg.
  ["SN: 20001-UP"] analogs:["0700001003"]
   21.   07001-01003   [2]   RING,BACK-UP Komatsu 0.001 kg.
  ["SN: 20001-UP"]
   22.   20B-27-11210   [1]   BLEEDER Komatsu 0.02 kg.
  ["SN: 20001-UP"]
   23.   04530-10815   [1]   BOLT,EYE Komatsu 0.05 kg.
  ["SN: 20001-UP"]
