KOMATSU PC30MR-2 PC35MR-2 EXCAVATOR 708-1S-00611 708-1S-01253 HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

KOMATSU PC30MR-2 PC35MR-2 EXCAVATOR 708-1S-00611 708-1S-01253 HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
708-1S-00611 708-1S-01253 PC30MR-2 PC35MR-2
Pos. Part No Qty Parts name Comments
\0.   708-1S-00611   [1]   HYDRAULIC PUMP (FOR AIR CONDITIONING) Komatsu 28 kg.
  ["SN: F00103-UP"]
   \0.   708-1S-01253   [1]   PUMP Komatsu China
  ["SN: F00103-UP"]
\0.   708-1S-04253   [1]   CASE PUMP, ASSY. Komatsu 9 kg.
  ["SN: F00103-UP"] analogs:["7081S04252"]
1   708-1S-11213   [1]   CASE, PUMP Komatsu China
  ["SN: F00103-UP"]
2   708-21-12541   [5]   PLUG Komatsu China
  ["SN: F00103-UP"] analogs:["7068651180"]
3   708-1S-19810   [2]   PLUG Komatsu China
  ["SN: F00103-UP"] analogs:["7081U03530", "7081U15120"]
4   708-3S-13441   [1]   SWASH PLATE Komatsu 1.2 kg.
  ["SN: F00103-UP"] analogs:["7083S13440"]
5   04260-01270   [1]   BALL Komatsu OEM 0.009 kg.
  ["SN: F00103-UP"]
6   708-1S-14140   [1]   SPACER Komatsu China
  ["SN: F00103-UP"]
7   708-1S-13420   [2]   PIN Komatsu China
  ["SN: F00103-UP"]
8   01252-60616   [1]   BOLT Komatsu 0.007 kg.
  ["SN: F00103-UP"] analogs:["0125230616"]
9   01252-61235   [4]   BOLT Komatsu 0.048 kg.
  ["SN: F00103-UP"] analogs:["801105554", "0125231235"]
10   04020-01024   [2]   PIN Komatsu 0.015 kg.
  ["SN: F00103-UP"] analogs:["PZF890001197"]
11   07000-11006   [4]   O-RING Komatsu 0.01 kg.
  ["SN: F00103-UP"] analogs:["0700001006"]
12   07000-12125   [1]   O-RING Komatsu OEM 0.005 kg.
  ["SN: F00103-UP"] analogs:["0700002125E", "0700002125"]
\12.   708-1S-04261   [1]   COVER, ASSY. Komatsu China
  ["SN: F00103-UP"]
13   708-1S-11221   [1]   COVER Komatsu China
  ["SN: F00103-UP"]
15   708-21-12760   [1]   BEARING Komatsu 0.086 kg.
  ["SN: F00103-UP"]
16   720-68-19610   [1]   PIN Komatsu 0.002 kg.
  ["SN: F00103-UP"]
17   708-3S-13460   [2]   BALL Komatsu China
  ["SN: F00103-UP"]
18   708-1S-12311   [1]   SHAFT Komatsu 0.92 kg.
  ["SN: F00103-UP"]
19   708-3S-12210   [1]   BEARING Komatsu 0.4 kg.
  ["SN: F00103-UP"]
20   708-21-12840   [1]   RING, SNAP Komatsu China
  ["SN: F00103-UP"]
21   708-3S-12140   [1]   HOLDER Komatsu 0.215 kg.
  ["SN: F00103-UP"]
22   207-09-11140   [1]   O-RING Komatsu 0.002 kg.
  ["SN: F00103-UP"]
23   708-3S-12150   [1]   SEAL OIL Komatsu 0.02 kg.
  ["SN: F00103-UP"]
24   04065-06220   [1]   RING Komatsu 0.013 kg.
  ["SN: F00103-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
\0.   708-1S-00611   [1]   HYDRAULIC PUMP (FOR AIR CONDITIONING) Komatsu 28 kg.
  ["SN: F00103-UP"]
   \0.   708-1S-01253   [1]   PUMP Komatsu China
  ["SN: F00103-UP"]
1   708-1S-13510   [1]   CYLINDER BLOCK Komatsu China
  ["SN: F00103-UP"]
2   708-1S-13230   [1]   PLATE Komatsu 0.22 kg.
  ["SN: F00103-UP"]
3   708-3S-13160   [2]   WASHER Komatsu China
  ["SN: F00103-UP"]
4   708-3S-13430   [1]   SPRING Komatsu 0.07 kg.
  ["SN: F00103-UP"]
5   04056-03515   [1]   RING, SNAP Komatsu China
  ["SN: F00103-UP"]
6   708-1S-13370   [1]   GUIDE, RETAINER Komatsu 0.045 kg.
  ["SN: F00103-UP"] analogs:["7083S13370", "R7081S13370"]
7   708-1S-13380   [3]   PIN Komatsu 0.06 kg.
  ["SN: F00103-UP"]
8   708-1S-13360   [1]   RETAINER Komatsu 0.18 kg.
  ["SN: F00103-UP"] analogs:["R7081S13360"]
9   708-1S-13520   [7]   PISTON Komatsu 0.09 kg.
  ["SN: F00103-UP"]
10   708-1S-14210   [1]   PLUG Komatsu China
  ["SN: F00103-UP"]
11   708-3S-14261   [1]   PLUG Komatsu China
  ["SN: F00103-UP"]
12   07002-11223   [2]   O-RING Komatsu China 0.001 kg.
  ["SN: F00103-UP"] analogs:["0700201223"]
13   708-3S-14250   [1]   PISTON Komatsu 0.087 kg.
  ["SN: F00103-UP"] analogs:["7081S14230"]
14   708-1S-14241   [1]   SPRING Komatsu 0.01 kg.
  ["SN: F00103-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
\0.   708-1S-00611   [1]   HYDRAULIC PUMP (FOR AIR CONDITIONING) Komatsu 28 kg.
  ["SN: F00103-UP"]
   \0.   708-1S-03423   [1]   VALVE, ASSY. Komatsu China
  ["SN: F00103-UP"]
\0.   708-3S-04460   [1]   CASE PUMP, ASSY. Komatsu China
  ["SN: F00103-UP"]
1   708-3S-15350   [1]   CASE, PUMP Komatsu China
  ["SN: F00103-UP"]
2   708-1S-19810   [7]   PLUG Komatsu China
  ["SN: F00103-UP"] analogs:["7081U03530", "7081U15120"]
\2.   708-1S-04310   [1]   SLEEVE, ASSY. Komatsu China
  ["SN: F00103-UP"]
3   708-1S-15450   [1]   SLEEVE Komatsu China
  ["SN: F00103-UP"]
4   708-1S-15460   [1]   PISTON Komatsu China
  ["SN: F00103-UP"]
5   708-3S-15790   [1]   GASKET Komatsu China
  ["SN: F00103-UP"]
6   07000-11010   [1]   O-RING Komatsu 0.001 kg.
  ["SN: F00103-UP"]
7   07001-01010   [1]   RING Komatsu 0.001 kg.
  ["SN: F00103-UP"]
8   07002-11623   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: F00103-UP"] analogs:["0700201623"]
9   708-1S-15470   [1]   SPOOL Komatsu China
  ["SN: F00103-UP"]
10   708-1S-15240   [1]   SEAT, SPRING Komatsu China
  ["SN: F00103-UP"]
11   708-1S-15410   [1]   SPRING Komatsu China
  ["SN: F00103-UP"]
12   708-1S-15480   [1]   RETAINER Komatsu China
  ["SN: F00103-UP"]
13   07000-11006   [1]   O-RING Komatsu 0.01 kg.
  ["SN: F00103-UP"] analogs:["0700001006"]
14   708-1S-15490   [1]   PLUG Komatsu China
  ["SN: F00103-UP"]
15   01582-11210   [1]   NUT Komatsu 0.015 kg.
  ["SN: F00103-UP"]
16   708-1S-15270   [1]   LEVER Komatsu China
  ["SN: F00103-UP"]
17   708-1S-15280   [1]   SPACER Komatsu China
  ["SN: F00103-UP"]
19   708-1S-15290   [1]   PLUG Komatsu China
  ["SN: F00103-UP"]
20   708-1S-15310   [1]   PLUG Komatsu China
  ["SN: F00103-UP"]
21   708-1S-15540   [1]   SPOOL Komatsu China
  ["SN: F00103-UP"]
22   708-1S-15520   [1]   PLUG Komatsu China
  ["SN: F00103-UP"] analogs:["7081U15640"]
23   07002-11223   [2]   O-RING Komatsu China 0.001 kg.
  ["SN: F00103-UP"] analogs:["0700201223"]
24   708-1S-15340   [1]   SPRING Komatsu China
  ["SN: F00103-UP"]
25   708-1S-15530   [1]   SEAT, SPRING Komatsu China
  ["SN: F00103-UP"] analogs:["7081U15630"]
26   708-1S-15930   [1]   ORIFICE Komatsu China
  ["SN: F00103-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
\0.   708-1S-00611   [1]   HYDRAULIC PUMP (FOR AIR CONDITIONING) Komatsu 28 kg.
  ["SN: F00103-UP"]
   \0.   705-41-02700   [1]   GEAR PUMP, ASSY. Komatsu China
  ["SN: F00103-UP"]
1   705-41-83213   [1]   BRACKET, ASSY. Komatsu China
  ["SN: F00103-UP"]
\1.   705-41-83223   [1]   BRACKET Komatsu China
  ["SN: F00103-UP"]
\1.   705-40-83630   [1]   BUSHING Komatsu China
  ["SN: F00103-UP"]
\1.   705-40-83640   [1]   BUSHING Komatsu 0.012 kg.
  ["SN: F00103-UP"]
2   705-40-83720   [2]   SPACER, THRUST Komatsu 0.02 kg.
  ["SN: F00103-UP"] analogs:["7054080720", "7054080710"]
3   705-40-83760   [1]   GASKET Komatsu 0.002 kg.
  ["SN: F00103-UP"]
4   705-40-80881   [1]   PLATE Komatsu China
  ["SN: F00103-UP"] analogs:["7054080880"]
5   705-40-80760   [1]   GASKET Komatsu 0.003 kg.
  ["SN: F00103-UP"]
6   705-41-20A70   [1]   HOUSING, ASSY. Komatsu China
  ["SN: F00103-UP"]
\6.   705-41-20A80   [1]   HOUSING Komatsu China
  ["SN: F00103-UP"]
7   705-41-20J10   [1]   GEAR Komatsu China
  ["SN: F00103-UP"]
8   705-41-20H10   [1]   GEAR Komatsu China
  ["SN: F00103-UP"]
9   04020-00514   [2]   PIN Komatsu 0.002 kg.
  ["SN: F00103-UP"]
10   01252-71050   [4]   BOLT Komatsu China
  ["SN: F00103-UP"] analogs:["3000895X"]
11   01643-51032   [4]   WASHER Komatsu 0.17 kg.
  ["SN: F00103-UP"] analogs:["R0164351032"]
Parts on group :
Pos. Part No Qty Parts name Comments
\0.   708-1S-00611   [1]   HYDRAULIC PUMP (FOR AIR CONDITIONING) Komatsu 28 kg.
  ["SN: F00103-UP"]
   1.   708-1T-19210   [1]   JOINT Komatsu China
  ["SN: F00103-UP"] analogs:["890001673"]
   2.   700-30-63140   [1]   RING, SNAP Komatsu China
  ["SN: F00103-UP"] analogs:["890001674"]
   3.   708-1T-19230   [1]   RING Komatsu China
  ["SN: F00103-UP"] analogs:["890001675", "7081T19220"]
   4.   07000-12014   [1]   O-RING Komatsu China 0.01 kg.
  ["SN: F00103-UP"] analogs:["0700002014"]
   5.   07000-12060   [1]   O-RING Komatsu China 0.002 kg.
  ["SN: F00103-UP"] analogs:["0700002060"]
   6.   01252-60825   [4]   BOLT Komatsu 0.017 kg.
  ["SN: F00103-UP"] analogs:["0125240825", "0125230825"]
   7.   01643-30823   [4]   WASHER Komatsu 0.004 kg.
  ["SN: F00103-UP"] analogs:["802070008", "802150008", "0160510818", "0164310823", "802170001", "01643A0823"]
   8.   708-2L-25480   [5]   FILTER Komatsu OEM 0.5 kg.
  ["SN: F00103-UP"]
   9.   708-2L-25490   [5]   O-RING Komatsu 0.001 kg.
  ["SN: F00103-UP"]
   10.   708-1S-19710   [1]   ORIFICE Komatsu 0.002 kg.
  ["SN: F00103-UP"]
   11.   20B-27-11210   [1]   BREATHER Komatsu 0.02 kg.
  ["SN: F00103-UP"]
   12.   01252-60630   [3]   BOLT Komatsu 0.01 kg.
  ["SN: F00103-UP"] analogs:["0125240630"]
   13.   01252-60645   [1]   BOLT Komatsu 0.013 kg.
  ["SN: F00103-UP"]
   14.   07000-13040   [1]   O-RING Komatsu China 0.002 kg.
  ["SN: F00103-UP"] analogs:["0700003040", "0700003040E", "YM24311000400"]
   15.   04020-00616   [2]   PIN Komatsu 0.004 kg.
  ["SN: F00103-UP"]
