| Parts on group :TRAVEL MOTOR AND FINAL DRIVE, CARRIER, R.H. (#80001-) PC300-8M0 S/N 80001-UP Komatsu |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
207-27-00590
|
[1] |
Final Drive Assembly Komatsu China
|
|
|
["SN: 80001-UP"] |$0. |
|
|
207-27-00510
|
[1] |
Floating Seal Assembly Komatsu China
|
|
|
["SN: 80001-UP"] |$1. |
|
3. |
207-27-72290
|
[1] |
Hub Komatsu China
|
|
|
["SN: 80001-UP"] |
|
4. |
207-27-72220
|
[2] |
Bearing Komatsu China
|
|
|
["SN: 80001-UP"] |
|
5. |
207-27-52350
|
[1] |
O-ring Komatsu China
|
0.02 kg. |
|
["SN: 80001-UP"] |
|
6. |
207-27-72260
|
[1] |
Lock Komatsu China
|
|
|
["SN: 80001-UP"] |
|
7. |
207-27-72250
|
[1] |
Nut, Lock Komatsu China
|
|
|
["SN: 80001-UP"] |
|
8. |
01010-81020
|
[2] |
Bolt Komatsu
|
0.161 kg. |
|
["SN: 80001-UP"] analogs:["801014093", "0101051020", "801015108"] |
|
9. |
207-27-72170
|
[1] |
Carrier Komatsu China
|
|
|
["SN: 80001-UP"] |
|
10. |
207-27-72140
|
[4] |
Gear Komatsu
|
0.000 kg. |
|
["SN: 80001-UP"] |
|
11. |
207-27-72210
|
[4] |
Bearing Komatsu China
|
|
|
["SN: 80001-UP"] |
|
12. |
21M-27-11260
|
[8] |
Washer, Thrust Komatsu OEM
|
0.24 kg. |
|
["SN: 80001-UP"] |
|
13. |
208-27-71250
|
[4] |
Pin Komatsu OEM
|
2.16 kg. |
|
["SN: 80001-UP"] |
|
14. |
20Y-27-21290
|
[4] |
Pin Komatsu OEM
|
0.03 kg. |
|
["SN: 80001-UP"] |
|
15. |
20Y-27-13310
|
[1] |
Washer, Thrust Komatsu China
|
0.08 kg. |
|
["SN: 80001-UP"] |
|
16. |
207-27-72130
|
[1] |
Gear Komatsu
|
0.000 kg. |
|
["SN: 80001-UP"] |
|
17. |
207-27-72150
|
[1] |
Gear, Ring Komatsu
|
0.000 kg. |
|
["SN: 80001-UP"] |
|
18. |
207-27-72240
|
[1] |
Washer, Thrust Komatsu China
|
|
|
["SN: 80001-UP"] |
|
19. |
207-27-72160
|
[1] |
Carrier Komatsu China
|
|
|
["SN: 80001-UP"] |
|
20. |
207-27-72120
|
[3] |
Gear Komatsu
|
0.000 kg. |
|
["SN: 80001-UP"] |
|
21. |
22U-26-21320
|
[3] |
Bearing Komatsu
|
1.1 kg. |
|
["SN: 80001-UP"] |
|
22. |
206-26-71520
|
[6] |
Washer, Thrust Komatsu
|
0.1 kg. |
|
["SN: 80001-UP"] |
|
23. |
207-27-72230
|
[3] |
Pin Komatsu China
|
|
|
["SN: 80001-UP"] |
|
24. |
20Y-27-21280
|
[3] |
Pin Komatsu China
|
0.01 kg. |
|
["SN: 80001-UP"] |
|
25. |
207-27-72110
|
[1] |
Shaft Komatsu
|
0.000 kg. |
|
["SN: 80001-UP"] |
|
26. |
20Y-27-11250
|
[1] |
Spacer Komatsu OEM
|
0.044 kg. |
|
["SN: 80001-UP"] analogs:["2052771570"] |
|
27. |
04260-01905
|
[1] |
Ball Komatsu OEM
|
0.029 kg. |
|
["SN: 80001-UP"] |
|
28. |
207-27-72180
|
[1] |
Cover Komatsu China
|
|
|
["SN: 80001-UP"] |
|
29. |
01011-61890
|
[22] |
Bolt Komatsu China
|
|
|
["SN: 80001-UP"] analogs:["0101131890", "0101151890", "0101181890"] |
|
30. |
01643-31845
|
[22] |
Washer Komatsu China
|
0.02 kg. |
|
["SN: 80001-UP"] analogs:["0164321845", "R0164331845"] |
|
31. |
07049-01215
|
[2] |
Plug Komatsu
|
0.001 kg. |
|
["SN: 80001-UP"] |
|
32. |
07044-12412
|
[3] |
Plug Komatsu
|
0.09 kg. |
|
["SN: 80001-UP"] analogs:["0704402412", "R0704412412"] |
|
33. |
07002-02434
|
[3] |
O-ring Komatsu China
|
0.01 kg. |
|
["SN: 80001-UP"] analogs:["0700212434", "0700213434"] |
|
34. |
207-27-72270
|
[1] |
Sprocket Komatsu
|
0.000 kg. |
|
["SN: 80001-UP"] |
|
35. |
207-27-51311
|
[24] |
Bolt Komatsu China
|
0.222 kg. |
|
["SN: 80001-UP"] analogs:["2072751310", "20727K1120", "20727K1130"] |
