KOMATSU PC300-8M0 PC300LC-8M0 PC350-8M0 PC350LC-8M0 EXCAVATOR 706-7H-01050 706-7H-03010 SWING MOTOR ROTARY GROUP AND SPARE PARTS

KOMATSU PC300-8M0 PC300LC-8M0 PC350-8M0 PC350LC-8M0 EXCAVATOR 706-7H-01050 706-7H-03010 SWING MOTOR ROTARY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
706-7H-01050 706-7H-03010
PC300-8M0 PC300LC-8M0 PC350-8M0 PC350LC-8M0
Pos. Part No Qty Parts name Comments
     706-7H-01050   [1]   Motor Assembly Komatsu China
  ["SN: 80001-UP"] |$0.
        706-7H-03010   [1]   Motor Subassembly Komatsu China
  ["SN: 80001-UP"] |$1.
1   706-7H-12210   [1]   Case Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
2   07040-11409   [2]   Plug Komatsu 0.033 kg.
  ["SN: 80001-UP"]
3   07002-61423   [2]   O-ring Komatsu 0.001 kg.
  ["SN: 80001-UP"] analogs:["7082L23950"]
4   706-7H-12220   [1]   Housing Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
5   706-7H-11560   [1]   Bushing Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
6   706-75-42830   [1]   Pin, Dowel Komatsu 0.02 kg.
  ["SN: 80001-UP", "SCC: C2"]
7   706-77-72280   [1]   Plug Komatsu 0.08 kg.
  ["SN: 80001-UP"]
8   07002-62034   [1]   O-ring Komatsu 0.94 kg.
  ["SN: 80001-UP"]
9   709-74-92810   [2]   Valve Komatsu 0.063 kg.
  ["SN: 80001-UP"]
10   709-75-92220   [2]   Spring Komatsu 0.001 kg.
  ["SN: 80001-UP"]
11   709-74-92821   [2]   Plug Komatsu 0.4 kg.
  ["SN: 80001-UP"]
12   708-2L-23960   [2]   O-ring Komatsu 0.001 kg.
  ["SN: 80001-UP"]
13   700-93-11330   [2]   Ring, Back-up Komatsu 0.01 kg.
  ["SN: 80001-UP"]
14   708-8K-16150   [2]   Valve Komatsu China
  ["SN: 80001-UP"]
15   708-8K-16160   [2]   Spring Komatsu China
  ["SN: 80001-UP"]
16   708-8K-16170   [2]   Plug Komatsu China
  ["SN: 80001-UP"]
17   07002-63634   [2]   O-ring Komatsu 0.001 kg.
  ["SN: 80001-UP"] analogs:["7082L24620"]
18   706-7K-40040   [1]   O-ring Komatsu 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"]
19   01010-61460   [8]   Bolt Komatsu 0.097 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["0101081460", "0101051460", "0104071460"]
20   01643-31445   [8]   Washer, Flat Komatsu 0.019 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["0164301432"]
Parts on group :
Pos. Part No Qty Parts name Comments
     706-7H-01050   [1]   Motor Assembly Komatsu China
  ["SN: 80001-UP"] |$0.
        706-7H-03010   [1]   Motor Subassembly Komatsu China
  ["SN: 80001-UP"] |$1.
1   706-7H-11440   [1]   Shaft Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
2   706-8J-41010   [1]   Bearing Komatsu 8.22 kg.
  ["SN: 80001-UP", "SCC: C2"]
3   706-7H-11450   [1]   Spacer Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
4   706-77-42890   [1]   Bearing Komatsu 1.185 kg.
  ["SN: 80001-UP", "SCC: C2"]
5   706-77-05010   [1]   Spacer Kit Komatsu 0.172 kg.
  ["SN: 80001-UP", "SCC: C2"]
6   04064-06525   [1]   Ring, Snap, for Shaft Side Komatsu China 0.021 kg.
  ["SN: 80001-UP", "SCC: C2"]
7   706-8J-41420   [1]   Seal, Oil Komatsu 0.662 kg.
  ["SN: 80001-UP"]
8   706-7K-41920   [1]   Spacer Komatsu 0.04 kg.
  ["SN: 80001-UP"]
9   04065-07525   [1]   Ring, Snap, for Hole Side Komatsu 0.021 kg.
  ["SN: 80001-UP"]
10 706-7H-11460 [1]   Block, Cylinder Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
11 706-7H-11550 [1]   Plate, Valve Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
12   708-18-13230   [1]   Pin Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
13 706-7H-11530 [1]   Shaft Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
14   706-7H-11540   [1]   Ring Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
15   706-7H-11520   [1]   Spring Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
16-17   706-7H-11570   [1]   Retainer Kit Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
18 706-7H-11510 [7]   Piston Subassembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
19   706-7H-13610   [1]   Plate Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
20   706-7H-13560   [4]   Plate Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
21   706-7H-13570   [3]   Disc Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
22   706-7H-13580   [1]   Piston, Brake Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
23   07000-B5230   [1]   O-ring Komatsu 0.033 kg.
  ["SN: 80001-UP", "SCC: C2"]
24   07000-B5200   [1]   O-ring Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
25   706-7H-13590   [4]   Spring Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
Parts on group :
Pos. Part No Qty Parts name Comments
     706-7H-01050   [1]   Motor Assembly Komatsu China
  ["SN: 80001-UP"] |$0.
   1.   702-77-02170   [1]   Valve, Relief Komatsu China
  ["SN: 80001-UP"]
2   07000-F3022   [1]   O-ring Komatsu China 0.002 kg.
  ["SN: 80001-UP"] analogs:["0700023022"]
3   07001-03022   [2]   Ring, Back-up Komatsu 0.01 kg.
  ["SN: 80001-UP"]
4   07002-63634   [1]   O-ring Komatsu 0.001 kg.
  ["SN: 80001-UP"] analogs:["7082L24620"]
   5.   706-7G-71290   [1]   Plate Komatsu China
  ["SN: 80001-UP"]
   6.   07000-B1009   [2]   O-ring Komatsu China 0.001 kg.
  ["SN: 80001-UP"] analogs:["7082L23910"]
   7.   01252-60825   [2]   Bolt, Hexagon Socket Head Komatsu 0.017 kg.
  ["SN: 80001-UP"] analogs:["0125240825", "0125230825"]
   8.   07000-B3042   [1]   O-ring Komatsu 0.002 kg.
  ["SN: 80001-UP"]
