KOMATSU PC300-8M0 PC300LC-8M0 PC350-8M0 PC350LC-8M0 EXCAVATOR 207-27-00590 708-8H-00430 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

KOMATSU PC300-8M0 PC300LC-8M0 PC350-8M0 PC350LC-8M0 EXCAVATOR 207-27-00590 708-8H-00430 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
207-27-00590 708-8H-00430
PC300-8M0 PC300LC-8M0 PC350-8M0 PC350LC-8M0
Pos. Part No Qty Parts name Comments
     207-27-00590   [1]   Final Drive Assembly Komatsu China
  ["SN: 80001-UP"] |$0.
        708-8H-00430   [1]   Motor Assembly Komatsu China
  ["SN: 80001-UP"] |$1.
     708-8H-04870   [1]   Case Subassembly Komatsu China
  ["SN: 80001-UP"] |$2.
1   708-8H-31360   [1]   Case, Motor Komatsu China
  ["SN: 80001-UP"]
     708-8H-04850   [1]   Cover Subassembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"] |$5.
9   706-75-42820   [1]   Pin, Dowel Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
10   708-8H-11530   [2]   Plug Komatsu 0.031 kg.
  ["SN: 80001-UP"]
11   07002-11423   [2]   O-ring Komatsu China 0.001 kg.
  ["SN: 80001-UP"] analogs:["0700201423"]
12   20B-27-11210   [1]   Bleeder Komatsu 0.02 kg.
  ["SN: 80001-UP"]
13   706-73-72420   [2]   Valve Komatsu China
  ["SN: 80001-UP"]
14   706-73-72440   [2]   Spring Komatsu China
  ["SN: 80001-UP"]
15   708-8H-36150   [2]   Plug Komatsu China
  ["SN: 80001-UP"]
16   07000-12018   [2]   O-ring Komatsu China 0.001 kg.
  ["SN: 80001-UP"] analogs:["KB9511301800", "YM24311000180", "0700002018", "2083811590"]
17   708-8H-36160   [2]   Ring, Back-up Komatsu China
  ["SN: 80001-UP"]
18   708-8F-36120   [2]   Ring Komatsu 0.01 kg.
  ["SN: 80001-UP"]
19   708-8H-36121   [2]   Spring Komatsu China
  ["SN: 80001-UP"]
20   708-8H-16141   [2]   Plug Komatsu 0.25 kg.
  ["SN: 80001-UP"]
21   07002-13634   [2]   O-ring Komatsu China 0.013 kg.
  ["SN: 80001-UP"] analogs:["0700203634"]
22   708-3D-15110   [2]   Valve Komatsu China
  ["SN: 80001-UP"]
23   708-8E-16160   [4]   Plug Komatsu 0.01 kg.
  ["SN: 80001-UP"]
24   07002-11023   [4]   O-ring Komatsu China 0.025 kg.
  ["SN: 80001-UP"] analogs:["0700201023"]
25   706-8J-71181   [2]   Valve Komatsu China
  ["SN: 80001-UP"] analogs:["7068J71180"]
26   706-8J-71190   [2]   Plug Komatsu China
  ["SN: 80001-UP"]
27   07002-11223   [2]   O-ring Komatsu China 0.001 kg.
  ["SN: 80001-UP"] analogs:["0700201223"]
28   708-8H-31210   [1]   O-ring Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
29   07000-12012   [2]   O-ring Komatsu China 0.001 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["0700002012", "7082E11790"]
30   04020-01228   [1]   Pin, Dowel Komatsu 0.026 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["21T3016190"]
31   01252-62055   [6]   Bolt Komatsu 0.222 kg.
  ["SN: 80001-UP", "SCC: C2"]
32   01252-62095   [2]   Bolt Komatsu 0.321 kg.
  ["SN: 80001-UP", "SCC: C2"]
Parts on group :
Pos. Part No Qty Parts name Comments
     207-27-00590   [1]   Final Drive Assembly Komatsu China
  ["SN: 80001-UP"] |$0.
        708-8H-00430   [1]   Motor Assembly Komatsu China
  ["SN: 80001-UP"] |$1.
1   708-8H-32180   [1]   Shaft Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
2   708-8H-32150   [1]   Bearing Komatsu 0.57 kg.
  ["SN: 80001-UP", "SCC: C2"]
3   708-8H-32170   [1]   Bearing Komatsu 0.34 kg.
  ["SN: 80001-UP", "SCC: C2"]
4   708-8H-05050   [1]   Spacer Kit Komatsu 0.105 kg.
  ["SN: 80001-UP", "SCC: C2"]
5   708-1F-12281   [1]   Seal, Oil Komatsu 0.1 kg.
  ["SN: 80001-UP"] analogs:["7081F12280"]
6   708-8H-32160   [1]   Spacer Komatsu 0.05 kg.
  ["SN: 80001-UP"]
7   04065-07825   [1]   Ring, Snap Komatsu 0.022 kg.
  ["SN: 80001-UP"]
     708-8H-04860   [1]   Cylinder Block Assembly Komatsu China
  ["SN: 80001-UP", "SCC: C2"] |$16.
10   708-18-13230   [1]   Pin Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
11   708-8H-33360   [3]   Pin Komatsu 0.01 kg.
  ["SN: 80001-UP", "SCC: C2"]
12   708-8H-33141   [2]   Spacer Komatsu 0.06 kg.
  ["SN: 80001-UP", "SCC: C2"]
13   708-8H-33750   [1]   Spring Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
14   04065-06020   [1]   Ring, Snap Komatsu 0.011 kg.
  ["SN: 80001-UP", "SCC: C2"]
15   708-8H-33512   [1]   Guide, Retainer Komatsu 0.23 kg.
  ["SN: 80001-UP", "SCC: C2"]
16   708-8H-33340   [1]   Retainer, Shoe Komatsu 0.44 kg.
  ["SN: 80001-UP", "SCC: C2"]
17   708-8H-33650   [9]   Piston Subassembly Komatsu 0.302 kg.
  ["SN: 80001-UP", "SCC: C2"]
18   708-8H-33940   [1]   Cam, Rocker Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
19   04260-02857   [2]   Ball, Retainer Komatsu 0.1 kg.
  ["SN: 80001-UP", "SCC: C2"]
20   708-8H-34320   [1]   Piston Komatsu China
  ["SN: 80001-UP"]
21   708-8H-34330   [1]   Spring Komatsu China
  ["SN: 80001-UP"]
22   708-8H-35130   [4]   Plate Komatsu 0.16 kg.
  ["SN: 80001-UP", "SCC: C2"]
23   708-8H-35180   [3]   Disc Komatsu 0.36 kg.
  ["SN: 80001-UP", "SCC: C2"]
24   708-8H-35141   [1]   Piston, Brake Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
25   07000-15175   [1]   O-ring Komatsu China 0.03 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["0700005175"]
26   07001-05175   [1]   Ring, Back-up Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
27   07000-15195   [1]   O-ring Komatsu China 0.038 kg.
  ["SN: 80001-UP", "SCC: C2"] analogs:["0700005195"]
28   07001-05195   [1]   Ring, Back-up Komatsu 0.016 kg.
  ["SN: 80001-UP", "SCC: C2"]
29   708-8H-35150   [1]   Spring Komatsu China
  ["SN: 80001-UP", "SCC: C2"]
Parts on group :
Pos. Part No Qty Parts name Comments
     207-27-00590   [1]   Final Drive Assembly Komatsu China
  ["SN: 80001-UP"] |$0.
        708-8H-00430   [1]   Motor Assembly Komatsu China
  ["SN: 80001-UP"] |$1.
1   702-75-04601   [1]   Valve Assembly, Relief Komatsu 0.85 kg.
  ["SN: 80001-UP"] analogs:["7027504600"]
2   07000-22018   [1]   O-ring Komatsu 0.001 kg.
  ["SN: 80001-UP"] analogs:["07000F2018"]
3   702-75-11830   [2]   Ring, Back-up Komatsu China
  ["SN: 80001-UP"]
4   07000-12021   [1]   O-ring Komatsu China 0.01 kg.
  ["SN: 80001-UP"] analogs:["0700002021"]
5   702-75-11840   [1]   Ring, Back-up Komatsu China
  ["SN: 80001-UP"]
6   702-75-11520   [1]   O-ring Komatsu 0.001 kg.
  ["SN: 80001-UP"]
7   702-75-11850   [1]   Ring, Back-up Komatsu China
  ["SN: 80001-UP"]
8   07002-13634   [1]   O-ring Komatsu China 0.013 kg.
  ["SN: 80001-UP"] analogs:["0700203634"]
