KOMATSU PC300-3 PC300LC-3 EXCAVATOR 706-77-11000 706-77-11001 706-77-11002 SWING MOTOR PARTS

Name: KOMATSU PC300-3 PC300LC-3 EXCAVATOR 706-77-11000 706-77-11001 706-77-11002 SWING MOTOR PARTS
Brand: +8613035309093
Price: 5000.0 USD
Availability: InStock

KOMATSU PC300-3 PC300LC-3 EXCAVATOR 706-77-11000 706-77-11001 706-77-11002 SWING MOTOR PARTS

$5,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

706-77-11000 706-77-11001 706-77-11002 PC300-3 PC300LC-3

Pos.	Part No	Qty	Parts name	Comments
	706-77-11002	[1]	MOTOR ASS'Y Komatsu China
			["SN: 12001-UP"] analogs:["RM7067711002", "7067711001", "7067711103"] \|$0.
	706-77-11001	[1]	MOTOR ASS'Y Komatsu China
			["SN: (12001-.)"] analogs:["RM7067711001", "7067711002", "7067711103"] \|$1.
	706-77-11000	[1]	MOTOR ASS'Y Komatsu China
			["SN: (12001-12238)"] \|$2.
	706-77-42190	[1]	BLOCK,CYLINDER Komatsu	5.64 kg.
			["SN: .-UP"] analogs:["7068740091", "7067743191"] \|$3.
1.	706-87-40091	[1]	BLOCK,CYLINDER Komatsu	5.64 kg.
			["SN: 12001-."] analogs:["7067743191"]
2.	706-77-42160	[7]	PISTON SUB ASS'Y Komatsu	0.46 kg.
			["SN: 12001-UP"]
3.	706-77-42081	[1]	SHAFT,CENTER Komatsu	0.5 kg.
			["SN: 12001-UP"]
4.	706-77-42110	[1]	SPRING Komatsu	0.23 kg.
			["SN: 12001-UP"]
5.	706-77-43130	[1]	RING,CENTER Komatsu China
			["SN: 12001-UP"]
6.	706-77-42071	[1]	BUSHING Komatsu	0.03 kg.
			["SN: 12001-UP"]
7.	706-77-42830	[1]	PLATE,VALVE Komatsu	1 kg.
			["SN: .-UP"] analogs:["7067743850", "7067743840"]
7.	706-77-42851	[1]	PLATE,VALVE Komatsu	1 kg.
			["SN: 12001-."] analogs:["7067743850", "7067743840"]
8.	04020-01024	[1]	PIN,DOWEL Komatsu	0.015 kg.
			["SN: 12001-UP"] analogs:["PZF890001197"]
9.	706-77-42260	[1]	RETAINER Komatsu	0.335 kg.
			["SN: 12001-UP"] analogs:["7067705020"]
10.	706-77-42861	[1]	SHAFT,DRIVE Komatsu	7.78 kg.
			["SN: 12239-UP"] analogs:["7067742862"]
10.	706-77-42860	[1]	SHAFT,DRIVE Komatsu	7.78 kg.
			["SN: 12001-12238"] analogs:["7067742861", "7067742862"]
11.	706-75-41271	[7]	SCREW Komatsu	0.004 kg.
			["SN: 12001-UP"]
12.	706-77-43021	[1]	CASE,BRAKE Komatsu China
			["SN: 12239-UP"] analogs:["7067743020"]
12.	706-77-43020	[1]	CASE,BRAKE Komatsu China
			["SN: 12001-12238"] analogs:["7067743021"]
13.	706-77-42881	[1]	BEARING Komatsu	5.5 kg.
			["SN: .-UP"]
13.	706-77-42880	[1]	BEARING Komatsu	5.5 kg.
			["SN: 12001-."] analogs:["7067742881"]
14.	706-77-42890	[1]	BEARING Komatsu	1.185 kg.
			["SN: 12001-UP"]
15.	706-77-42041	[1]	SEAT Komatsu	0.1 kg.
			["SN: 12239-UP"]
15.	706-77-42040	[1]	SEAT Komatsu China
			["SN: 12001-12238"]
16.	706-77-42051	[2]	SPRING Komatsu	0.14 kg.
			["SN: 12239-UP"]
16.	706-77-42050	[2]	SPRING Komatsu China
			["SN: 12001-12238"]
17.	706-77-05010	[1]	SPACER KIT Komatsu	0.172 kg.
			["SN: 12239-UP"]
17.	706-77-42030	[1]	SPACER Komatsu China
			["SN: 12001-12238"]
18.	04064-06525	[1]	RING,SNAP Komatsu China	0.021 kg.
			["SN: 12001-UP"]
19.	706-77-42060	[1]	COVER Komatsu	1.561 kg.
			["SN: 12001-UP"]
20.	07000-02115	[1]	O-RING Komatsu OEM	0.004 kg.
			["SN: 12001-UP"] analogs:["0700012115"]
21.	706-77-42920	[1]	SEAL,OIL Komatsu	0.096 kg.
			["SN: 12001-UP"]
22.	04071-00130	[1]	RING,SNAP Komatsu	0.12 kg.
			["SN: 12001-UP"]
23.	07000-05250	[1]	O-RING Komatsu China	0.026 kg.
			["SN: 12001-UP"] analogs:["0700015250"]
24.	01010-51860	[8]	BOLT Komatsu	0.17 kg.
			["SN: 12001-UP"] analogs:["0101031860", "0101061860", "0101081860", "0104031860"]
25.	01602-21852	[8]	WASHER,SPRING Komatsu China
			["SN: 12001-UP"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	706-77-11002	[1]	MOTOR ASS'Y Komatsu China
			["SN: 12001-UP"] analogs:["RM7067711002", "7067711001", "7067711103"] \|$0.
	706-77-11001	[1]	MOTOR ASS'Y Komatsu China
			["SN: (12001-.)"] analogs:["RM7067711001", "7067711002", "7067711103"] \|$1.
	706-77-11000	[1]	MOTOR ASS'Y Komatsu China
			["SN: (12001-12238)"] \|$2.
1.	706-77-72112	[1]	HOUSING Komatsu	56 kg.
			["SN: 12001-UP"]
2.	706-77-72130	[2]	VALVE Komatsu	0.31 kg.
			["SN: 12001-UP"]
3.	706-77-72140	[2]	SPRING Komatsu	0.02 kg.
			["SN: 12001-UP"]
4.	706-77-72150	[2]	PLUG Komatsu	0.52 kg.
			["SN: 12001-UP"]
5.	07002-14234	[2]	O-RING Komatsu China	0.002 kg.
			["SN: 12001-UP"] analogs:["0700204234"]
6.	706-77-72170	[7]	PLUG Komatsu	0.115 kg.
			["SN: 12001-UP"]
7.	07002-12434	[7]	O-RING Komatsu China	0.01 kg.
			["SN: 12001-UP"] analogs:["0700202434", "0700213434"]
	706-77-76701	[2]	RELIEF VALVE ASS'Y Komatsu China
			["SN: 12001-UP"] analogs:["7067575130", "7067776700"] \|$10.
18	07000-23022	[1]	O-RING Komatsu China	0.002 kg.
			["SN: 12001-UP"] analogs:["07000F3022"]
19	07001-03022	[2]	RING,BACK-UP Komatsu	0.01 kg.
			["SN: 12001-UP"]
20	07002-13634	[1]	O-RING Komatsu China	0.013 kg.
			["SN: 12001-UP"] analogs:["0700203634"]
