KOMATSU PC27MRX-1 PC27MR-2 PC27MR-2-A PC27MR-2-B PC30MR-2 PC30UU-3 EXCAVATOR 708-1S-00252 708-1S-01252 HYDRAULIC PUMP ROTARY GROUP

KOMATSU PC27MRX-1 PC27MR-2 PC27MR-2-A PC27MR-2-B PC30MR-2 PC30UU-3 EXCAVATOR 708-1S-00252 708-1S-01252 HYDRAULIC PUMP ROTARY GROUP

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
708-1S-00252 708-1S-01252 PC27MRX-1  PC27MR-2 PC27MR-2-A PC27MR-2-B PC30MR-2 PC30UU-3
Pos. Part No Qty Parts name Comments
\0.    708-1S-00252   [1]   PUMP, ASSY. Komatsu 28 kg.
  ["SN: F00103-UP"] analogs:["7081S00251", "7081S00253", "7081S00254"]
   1.   708-1T-19210   [1]   JOINT Komatsu China
  ["SN: F00103-UP"] analogs:["890001673"]
   2.   700-30-63140   [1]   RING, SNAP Komatsu China
  ["SN: F00103-UP"] analogs:["890001674"]
   3.   708-1T-19230   [1]   RING Komatsu China
  ["SN: F00103-UP"] analogs:["890001675", "7081T19220"]
   4.   07000-12014   [1]   O-RING Komatsu China 0.01 kg.
  ["SN: F00103-UP"] analogs:["0700002014"]
   5.   07000-12060   [1]   O-RING Komatsu China 0.002 kg.
  ["SN: F00103-UP"] analogs:["0700002060"]
   6.   01252-60825   [4]   BOLT Komatsu 0.017 kg.
  ["SN: F00103-UP"] analogs:["0125240825", "0125230825"]
   7.   01643-30823   [4]   WASHER Komatsu 0.004 kg.
  ["SN: F00103-UP"] analogs:["802070008", "802150008", "0160510818", "0164310823", "802170001", "01643A0823"]
   11.   20B-27-11210   [1]   BREATHER Komatsu 0.02 kg.
  ["SN: F00103-UP"]
Pos. Part No Qty Parts name Comments
\0.   708-1S-00253   [1]   PUMP, ASSY. Komatsu 28 kg.
  ["SN: F00103-UP"] analogs:["7081S00251", "7081S00254"]
\0.   708-1S-00252   [1]   PUMP, ASSY. Komatsu 28 kg.
  ["SN: F00103-UP"] analogs:["7081S00251", "7081S00253", "7081S00254"]
   \0.   708-1S-01252   [1]   HYDRAULIC PUMP, ASSY. Komatsu China
  ["SN: F00103-UP"]
\0.   708-1S-04252   [1]   BODY, ASSY. Komatsu 9 kg.
  ["SN: F00103-UP"]
4   708-3S-13440   [1]   SWASH PLATE Komatsu 1.2 kg.
  ["SN: F00103-UP"]
5   04260-01270   [1]   BALL Komatsu OEM 0.009 kg.
  ["SN: F00103-UP"]
6   708-3S-14140   [1]   SPACER Komatsu 0.03 kg.
  ["SN: F00103-UP"]
7   708-1S-13240   [2]   PIN Komatsu China
  ["SN: F00103-UP"]
8   01252-60616   [1]   BOLT Komatsu 0.007 kg.
  ["SN: F00103-UP"] analogs:["0125230616"]
9   01252-61235   [4]   BOLT Komatsu 0.048 kg.
  ["SN: F00103-UP"] analogs:["801105554", "0125231235"]
10   04020-01024   [2]   PIN Komatsu 0.015 kg.
  ["SN: F00103-UP"] analogs:["PZF890001197"]
11   07000-11006   [4]   O-RING Komatsu 0.01 kg.
  ["SN: F00103-UP"] analogs:["0700001006"]
12   07000-12125   [1]   O-RING Komatsu OEM 0.005 kg.
  ["SN: F00103-UP"] analogs:["0700002125E", "0700002125"]
\12.   708-1S-04261   [1]   COVER, ASSY. Komatsu China
  ["SN: F00103-UP"]
15   708-21-12760   [1]   BEARING Komatsu 0.086 kg.
  ["SN: F00103-UP"]
16   720-68-19610   [1]   PIN Komatsu 0.002 kg.
  ["SN: F00103-UP"]
17   708-3S-13450   [2]   BALL Komatsu China
  ["SN: F00103-UP"]
18   708-1S-12311   [1]   SHAFT Komatsu 0.92 kg.
  ["SN: F00103-UP"]
19   708-3S-12210   [1]   BEARING Komatsu 0.4 kg.
  ["SN: F00103-UP"]
20   708-21-12840   [1]   RING, SNAP Komatsu China
  ["SN: F00103-UP"]
21   708-3S-12140   [1]   HOLDER Komatsu 0.215 kg.
  ["SN: F00103-UP"]
22   207-09-11140   [1]   O-RING Komatsu 0.002 kg.
  ["SN: F00103-UP"]
23   708-3S-12150   [1]   SEAL OIL Komatsu 0.02 kg.
  ["SN: F00103-UP"]
24   04065-06220   [1]   RING Komatsu 0.013 kg.
  ["SN: F00103-UP"]
Pos. Part No Qty Parts name Comments
\0.   708-1S-00252   [1]   PUMP, ASSY. Komatsu 28 kg.
  ["SN: F00103-UP"] analogs:["7081S00251", "7081S00253", "7081S00254"]
   \0.   708-1S-01252   [1]   HYDRAULIC PUMP, ASSY. Komatsu China
  ["SN: F00103-UP"]
1   708-1S-13510   [1]   CYLINDER BLOCK Komatsu China
  ["SN: F00103-UP"]
2   708-1S-13230   [1]   PLATE Komatsu 0.22 kg.
  ["SN: F00103-UP"]
3   708-3S-13160   [2]   WASHER Komatsu China
  ["SN: F00103-UP"]
4   708-3S-13430   [1]   SPRING Komatsu 0.07 kg.
  ["SN: F00103-UP"]
5   04065-03515   [1]   RING, SNAP Komatsu 0.003 kg.
  ["SN: F00103-UP"]
6   708-1S-13370   [1]   GUIDE, RETAINER Komatsu 0.045 kg.
  ["SN: F00103-UP"] analogs:["7083S13370", "R7081S13370"]
7   708-1S-13380   [3]   PIN Komatsu 0.06 kg.
  ["SN: F00103-UP"]
8   708-1S-13360   [1]   RETAINER Komatsu 0.18 kg.
  ["SN: F00103-UP"] analogs:["R7081S13360"]
9   708-1S-13520   [7]   PISTON Komatsu 0.09 kg.
  ["SN: F00103-UP"]
10   708-1S-14210   [1]   PLUG Komatsu China
  ["SN: F00103-UP"]
11   708-3S-14260   [1]   PLUG Komatsu China
  ["SN: F00103-UP"]
12   07002-11223   [2]   O-RING Komatsu China 0.001 kg.
  ["SN: F00103-UP"] analogs:["0700201223"]
13   708-3S-14250   [1]   PISTON Komatsu 0.087 kg.
  ["SN: F00103-UP"] analogs:["7081S14230"]
14   708-1S-14241   [1]   SPRING Komatsu 0.01 kg.
  ["SN: F00103-UP"]
   \0.   705-41-02700   [1]   GEAR PUMP, ASSY. Komatsu China
