| 22L-60-21101 PC27MR-2 PC27MR-2-A PC27MR-2-B PC30MR-2 PC30MR-2-A PC30MR-2-B PC30MR-2-C PC30MR-2-D PC30MR-3(JPN) PC35MR-2 PC35MR-2-A PC35MR-2-B |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| \0. |
22L-60-21101
|
[2] |
MOTOR, ASSY. Komatsu
|
37.23 kg. |
|
["SN: F00103-UP"] |
| \0. |
FUMHB-1B24243
|
[1] |
KIT, BASE PLATE, ASSY. Komatsu
|
0.000 kg. |
|
["SN: F00103-UP"] |
| \3. |
FUMHSH-1B14333
|
[1] |
R.H. CYLINDER HEAD Komatsu China
|
|
|
["SN: F00103-UP"] |
| 6 |
FUFZD-4333-310
|
[1] |
PLATE Komatsu China
|
|
|
["SN: F00103-UP"] |
| 7 |
FUYB-5/8
|
[2] |
BALL Komatsu China
|
|
|
["SN: F00103-UP"] |
| \7. |
FUMHCB-1-2010
|
[1] |
CYLINDER, ASSY Komatsu
|
0.000 kg. |
|
["SN: F00103-UP"] |
| 18 |
FUFZD-4532-126
|
[1] |
DISK Komatsu
|
0.000 kg. |
|
["SN: F00103-UP"] |
| 19 |
FUFZD-4532-137
|
[2] |
PLATE Komatsu China
|
|
|
["SN: F00103-UP"] |
| 20 |
FUFZD-4243-127
|
[1] |
PISTON Komatsu China
|
|
|
["SN: F00103-UP"] |
| 21 |
FUFZD-4452-138
|
[1] |
SPACER Komatsu China
|
|
|
["SN: F00103-UP"] |
| 22 |
FUFZD-4700-129
|
[8] |
SPRING Komatsu China
|
|
|
["SN: F00103-UP"] |
| 27 |
07000-12125
|
[1] |
O-RING Komatsu OEM
|
0.005 kg. |
|
["SN: F00103-UP"] analogs:["0700002125E", "0700002125"] |
| 28 |
07000-11007
|
[2] |
O-RING Komatsu
|
0.001 kg. |
|
["SN: F00103-UP"] analogs:["YM24311000070", "0700001007"] |
| 29 |
FUTH-10X25
|
[7] |
SCREW Komatsu China
|
|
|
["SN: F00103-UP"] |
| 30 |
FUPP-H7-8X15
|
[1] |
PIN Komatsu China
|
|
|
["SN: F00103-UP"] |
| Parts on group : |
|
|
|
|
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| \0. |
22L-60-21101
|
[2] |
MOTOR, ASSY. Komatsu
|
37.23 kg. |
|
["SN: F00103-UP"] |
|
\0. |
FUMHB-1B-4243
|
[1] |
KIT, BASE PLATE, ASSY. Komatsu China
|
|
|
["SN: F00103-UP"] |
| 12 |
FUFZS-2448-247
|
[2] |
SPRING Komatsu China
|
|
|
["SN: F00103-UP"] |
| 13 |
FUFZD-4243-111
|
[1] |
SPRING Komatsu China
|
|
|
["SN: F00103-UP"] |
| 14 |
FUFZS-2448-26
|
[2] |
PLUG Komatsu China
|
|
|
["SN: F00103-UP"] |
| 15 |
FUFZS-2448-27
|
[2] |
PLUG Komatsu China
|
|
|
["SN: F00103-UP"] |
| 16 |
FUFZS2448-28
|
[2] |
PLUG Komatsu China
|
|
|
["SN: F00103-UP"] |
| 17 |
FUFZS-2448-30
|
[2] |
RING Komatsu China
|
|
|
["SN: F00103-UP"] |
| 18 |
FUTPUA-1/16
|
[8] |
PLUG Komatsu China
|
|
|
["SN: F00103-UP"] |
| 19 |
FU1701538687
|
[2] |
PLUG Komatsu China
|
|
|
["SN: F00103-UP"] |
| 20 |
07000-11008
|
[2] |
O-RING Komatsu China
|
0.01 kg. |
|
["SN: F00103-UP"] analogs:["0700001008", "2016018950"] |
| 22 |
07000-12014
|
[2] |
O-RING Komatsu China
|
0.01 kg. |
|
["SN: F00103-UP"] analogs:["0700002014"] |
| 23 |
07000-13025
|
[2] |
O-RING Komatsu China
|
0.001 kg. |
|
["SN: F00103-UP"] analogs:["0700003025"] |
| 24 |
FUHL68-5X5-05
|
[8] |
ORIFICE Komatsu China
|
|
|
["SN: F00103-UP"] |
| 25 |
FUTPHA-1/8
|
[2] |
PLUG Komatsu China
|
|
|
["SN: F00103-UP"] |
