KOMATSU PC210LC-8K EXCAVATOR FINAL DRIVE INNER PARTS TRAVEL MOTOR

Name: KOMATSU PC210LC-8K EXCAVATOR FINAL DRIVE INNER PARTS TRAVEL MOTOR
Brand: +8613035309093
Price: 5000.0 USD
Availability: InStock

KOMATSU PC210LC-8K EXCAVATOR FINAL DRIVE INNER PARTS TRAVEL MOTOR

$5,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

PC210LC-8K FINAL DRIVE (STD) (LC) (#K53707)

Pos.	Part No	Qty	Parts name	Comments
	20Y-27-00560	[2]	FINAL DRIVE ASSEMBLY Komatsu	370 kg.
			["SN: K53707-UP"] \|1.
	20Y-27-00110	[1]	FLOATING SEAL A. Komatsu OEM	2.65 kg.
			["SN: K53707-UP"] \|1.
3.	20Y-27-42520	[1]	HUB Komatsu	0.000 kg.
			["SN: K53707-UP"]
4.	20Y-27-41260	[2]	BEARING Komatsu	4.5 kg.
			["SN: K53707-UP"]
5.	20Y-27-22280	[1]	O-RING Komatsu China	0.02 kg.
			["SN: K53707-UP"]
6.	20Y-27-41190	[1]	NUT, LOCK Komatsu	3 kg.
			["SN: K53707-UP"]
7.	20Y-27-41180	[1]	LOCK Komatsu	0.04 kg.
			["SN: K53707-UP"]
8.	01010-81020	[2]	BOLT Komatsu	0.161 kg.
			["SN: K53707-UP"] analogs:["801014093", "0101051020", "801015108"]
9.	20Y-27-42540	[1]	CARRIER Komatsu China
			["SN: K53707-UP"]
10.	20Y-27-22140	[4]	GEAR Komatsu China	3.72 kg.
			["SN: K53707-UP"]
11.	20Y-27-22220	[4]	BEARING Komatsu China	0.3 kg.
			["SN: K53707-UP"] analogs:["20Y2721270"]
12.	20Y-27-21250	[8]	THRUST WASHER Komatsu China	0.03 kg.
			["SN: K53707-UP"]
13.	20Y-27-21230	[4]	PIN Komatsu	1.54 kg.
			["SN: K53707-UP"]
14.	20Y-27-21290	[4]	PIN Komatsu OEM	0.03 kg.
			["SN: K53707-UP"]
15.	20Y-27-13310	[1]	THRUST WASHER Komatsu China	0.08 kg.
			["SN: K53707-UP"]
16.	20Y-27-22130	[1]	GEAR Komatsu China	1.75 kg.
			["SN: K53707-UP"]
17.	20Y-27-22240	[1]	THRUST WASHER Komatsu China	0.03 kg.
			["SN: K53707-UP"]
18.	20Y-27-22151	[1]	GEAR Komatsu	43.7 kg.
			["SN: K53707-UP"] analogs:["20Y2722150"]
19.	20Y-27-22160	[1]	CARRIER Komatsu OEM	6 kg.
			["SN: K53707-UP"]
20.	20Y-27-22120	[3]	GEAR Komatsu China	2.5 kg.
			["SN: K53707-UP"]
21.	20Y-27-22210	[3]	BEARING Komatsu China	0.12 kg.
			["SN: K53707-UP"] analogs:["20Y2721260"]
22.	20Y-27-21240	[6]	THRUST WASHER Komatsu China	0.02 kg.
			["SN: K53707-UP"]
23.	20Y-27-21220	[3]	PIN Komatsu China	0.411 kg.
			["SN: K53707-UP"]
24.	20Y-27-21280	[3]	PIN Komatsu China	0.01 kg.
			["SN: K53707-UP"]
25.	20Y-27-42510	[1]	SHAFT Komatsu OEM	0.000 kg.
			["SN: K53707-UP"]
26.	20Y-27-21310	[1]	THRUST WASHER Komatsu China	0.17 kg.
			["SN: K53707-UP"]
27.	20Y-27-42530	[1]	COVER Komatsu China
			["SN: K53707-UP"]
28.	04260-01587	[1]	BALL Komatsu	0.018 kg.
			["SN: K53707-UP"]
29.	20Y-27-13281	[18]	BOLT Komatsu	0.31 kg.
			["SN: K53707-UP"]
30.	01643-31645	[18]	WASHER Komatsu	0.072 kg.
			["SN: K53707-UP"] analogs:["802170005", "0164301645"]
31.	07049-01012	[2]	PLUG Komatsu	0.001 kg.
			["SN: K53707-UP"]
32.	07044-12412	[3]	PLUG Komatsu	0.09 kg.
			["SN: K53707-UP"] analogs:["0704402412", "R0704412412"]
33.	07002-12434	[3]	O-RING Komatsu China	0.01 kg.
			["SN: K53707-UP"] analogs:["0700202434", "0700213434"]
34.	20Y-27-11582	[1]	SPROCKET Komatsu China	36.2 kg.
			["SN: K53707-UP"] analogs:["20Y2711581", "20Y27K1110", "20Y2777110"]
35.	20Y-27-11561	[20]	BOLT Komatsu China	0.14 kg.
			["SN: K53707-UP"]
36	01010-B1660	[36]	BOLT Komatsu	0.127 kg.
			["SN: K53707-UP"] analogs:["0101061660", "0101031660", "0101081660"]
38	20Y-30-21191	[2]	COVER Komatsu	12.25 kg.
			["SN: K53707-UP"]
39	01010-81230	[8]	BOLT Komatsu	0.043 kg.
			["SN: K53707-UP"] analogs:["0101051230", "01010B1230"]
40	01643-31232	[8]	WASHER Komatsu	0.027 kg.
			["SN: K53707-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
41	708-8F-00250	[-1]	MOTOR ASSEMBLY Komatsu	93 kg.
			["SN: K53707-UP"]
