KOMATSU PC210-8K PC210LC-8K PC210NLC-8K PC230NHD-8K EXCAVATOR 708-2L-00700 708-2L-00701 708-2L-01700 708-2L-01701 PUMP ASSEMBLY ROTARY GROUP AND SPARE PARTS

KOMATSU PC210-8K PC210LC-8K PC210NLC-8K PC230NHD-8K EXCAVATOR 708-2L-00700 708-2L-00701 708-2L-01700 708-2L-01701 PUMP ASSEMBLY ROTARY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
708-2L-00700 708-2L-00701 708-2L-01700 708-2L-01701
PC210-8K PC210LC-8K PC210NLC-8K PC230NHD-8K
Pos. Part No Qty Parts name Comments
     708-2L-00701   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K54697-UP"] analogs:["7082L00700"] |1.
     708-2L-00700   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K50001-K54696"] analogs:["7082L00701"] |1.
        708-2L-01701   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K54697-UP"] |1.
        708-2L-01700   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K50001-K54696"] |1.
     708-2L-06390   [1]   CASE ASSEMBLY, FRONT Komatsu 0.000 kg.
  ["SN: K50001-UP"] |1.
3   708-1L-29340   [1]   ORIFICE Komatsu 0.001 kg.
  ["SN: K50001-UP"]
4   708-2L-41170   [8]   O-RING Komatsu 0.001 kg.
  ["SN: K50001-UP"]
5   07000-B1009   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: K50001-UP"] analogs:["7082L23910"]
6   07044-12412   [1]   PLUG Komatsu 0.09 kg.
  ["SN: K50001-UP"] analogs:["0704402412", "R0704412412"]
7   07002-62434   [1]   O-RING Komatsu 0.001 kg.
  ["SN: K50001-UP"] analogs:["7081W28910"]
8   04530-11222   [1]   BOLT, EYE Komatsu 0.122 kg.
  ["SN: K50001-UP"]
9   708-8E-16150   [1]   PLUG Komatsu 0.02 kg.
  ["SN: K50001-UP"]
10   07002-61023   [1]   O-RING Komatsu 0.22 kg.
  ["SN: K50001-UP"] analogs:["7082L23920"]
11   07040-12414   [1]   PLUG Komatsu 0.092 kg.
  ["SN: K50001-UP"] analogs:["0704002412", "0704012412"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2L-00701   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K54697-UP"] analogs:["7082L00700"] |1.
     708-2L-00700   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K50001-K54696"] analogs:["7082L00701"] |1.
        708-2L-01701   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K54697-UP"] |1.
        708-2L-01700   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K50001-K54696"] |1.
     708-2L-06490   [1]   CAP ASSEMBLY, END Komatsu 0.000 kg.
  ["SN: K50001-UP"] |1.
3   708-1L-29340   [2]   ORIFICE Komatsu 0.001 kg.
  ["SN: K50001-UP"]
4   708-2L-42150   [2]   BEARING Komatsu 0.24 kg.
  ["SN: K50001-UP"]
5   07000-A5190   [2]   O-RING Komatsu 0.025 kg.
  ["SN: K50001-UP"]
6   04020-01228   [2]   PIN, DOWEL Komatsu 0.026 kg.
  ["SN: K50001-UP"] analogs:["21T3016190"]
7   07040-12414   [1]   PLUG Komatsu 0.092 kg.
  ["SN: K50001-UP"] analogs:["0704002412", "0704012412"]
8   07002-62434   [1]   O-RING Komatsu 0.001 kg.
  ["SN: K50001-UP"] analogs:["7081W28910"]
9   708-2L-25480   [4]   FILTER Komatsu OEM 0.5 kg.
  ["SN: K50001-UP"]
10   01010-61655   [12]   BOLT Komatsu 0.119 kg.
  ["SN: K50001-UP"] analogs:["801015613", "0101031655", "0101051655", "0101081655"]
11   01643-31645   [12]   WASHER Komatsu 0.072 kg.
  ["SN: K50001-UP"] analogs:["802170005", "0164301645"]
12   708-8E-16150   [6]   PLUG Komatsu 0.02 kg.
  ["SN: K50001-UP"]
13   07002-61023   [6]   O-RING Komatsu 0.22 kg.
  ["SN: K50001-UP"] analogs:["7082L23920"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2L-00701   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K54697-UP"] analogs:["7082L00700"] |1.
     708-2L-00700   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K50001-K54696"] analogs:["7082L00701"] |1.
        708-2L-01701   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K54697-UP"] |1.
        708-2L-01700   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K50001-K54696"] |1.
1   708-2L-42210   [1]   SHAFT, FRONT Komatsu 0.000 kg.
  ["SN: K50001-UP"]
2   708-2L-42250   [1]   BEARING Komatsu 0.42 kg.
  ["SN: K50001-UP"]
3   708-2E-05040   [1]   WASHER KIT Komatsu 0.101 kg.
  ["SN: K50001-UP"] analogs:["7082E12190"]
4   708-25-12790   [1]   RING, SNAP Komatsu 0.006 kg.
  ["SN: K50001-UP"]
5   708-25-52861   [1]   SEAL, OIL Komatsu China 0.078 kg.
  ["SN: K50001-UP"] analogs:["7082552860", "7067340920"]
6   708-2L-22160   [1]   SPACER Komatsu 0.047 kg.
  ["SN: K50001-UP"]
7   04065-06825   [1]   RING, SNAP Komatsu 0.018 kg.
  ["SN: K50001-UP"]
   708-2L-06590 [1]   BLOCK ASSEMBLY, FRONT Komatsu 5.84 kg.
  ["SN: K50001-UP"] |8.
10   708-18-13230   [1]   PIN Komatsu 0.01 kg.
  ["SN: K50001-UP"]
11   04065-05820   [1]   RING, SNAP Komatsu 0.01 kg.
  ["SN: K50001-UP"]
12   708-2L-43130   [1]   SEAT Komatsu 0.03 kg.
  ["SN: K50001-UP"]
13   708-2L-43150   [1]   SPRING Komatsu 0.21 kg.
  ["SN: K50001-UP"]
14   708-2H-23141   [1]   SEAT Komatsu 0.03 kg.
  ["SN: K50001-UP"]
15   708-2L-43510   [1]   GUIDE, RETAINER Komatsu 0.22 kg.
  ["SN: K50001-UP"]
16   708-2L-43360   [3]   PIN Komatsu 0.000 kg.
  ["SN: K50001-UP"]
17   708-2L-43340   [1]   RETAINER, SHOE Komatsu 0.39 kg.
  ["SN: K50001-UP"]
18 708-2L-43311 [9]   PISTON SUB ASSEMBLY Komatsu 0.28 kg.
  ["SN: K50001-UP"]
     708-2L-06262   [1]   CRADLE ASSEMBLY Komatsu 6.1 kg.
  ["SN: K50001-UP"] analogs:["7082L06261"] |19.
21   04020-01228   [1]   PIN, DOWEL Komatsu 0.026 kg.
  ["SN: K50001-UP"] analogs:["21T3016190"]
22   01252-61025   [6]   BOLT Komatsu 0.028 kg.
  ["SN: K50001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2L-00701   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K54697-UP"] analogs:["7082L00700"] |1.
     708-2L-00700   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K50001-K54696"] analogs:["7082L00701"] |1.
        708-2L-01701   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K54697-UP"] |1.
        708-2L-01700   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K50001-K54696"] |1.
1   708-2L-44120   [1]   SLIDER Komatsu 0.32 kg.
  ["SN: K50001-UP"]
     708-2L-00643   [1]   VALVE ASSEMBLY, PC Komatsu China
  ["SN: K54697-UP"] |2.
     708-2L-06640   [1]   VALVE ASSEMBLY, PC Komatsu 0.000 kg.
  ["SN: K50001-K54696"] analogs:["7082L06643"] |2.
     708-2L-06690   [1]   PISTON ASSEMBLY, SERVO Komatsu 0.000 kg.
  ["SN: K50001-UP"] |2.
4   708-2G-15320   [1]   SEAL Komatsu 0.002 kg.
  ["SN: K50001-UP"]
5   708-2L-45210   [1]   PLUG Komatsu 0.000 kg.
  ["SN: K50001-UP"]
6   708-2L-35760   [1]   BALL Komatsu 0.001 kg.
  ["SN: K50001-UP"]
7   708-2L-35770   [1]   PLUG Komatsu 0.005 kg.
  ["SN: K50001-UP"]
8   708-2L-35690   [3]   SEAL Komatsu 0.003 kg.
  ["SN: K50001-UP"]
9   708-2L-35280   [1]   PIN Komatsu 0.01 kg.
  ["SN: K50001-UP"]
10   708-2L-35860   [1]   SPOOL Komatsu 0.03 kg.
  ["SN: K50001-UP"]
11   708-2G-15290   [1]   RETAINER Komatsu 0.05 kg.
  ["SN: K50001-UP"]
12   708-2L-35641   [1]   SEAT Komatsu 0.01 kg.
  ["SN: K50001-UP"]
13   708-2L-45220   [1]   SPRING Komatsu 0.21 kg.
  ["SN: K50001-UP"]
14   708-2L-44190   [1]   SPRING Komatsu 0.14 kg.
  ["SN: K50001-UP"]
15   708-2L-35650   [1]   SEAT Komatsu 0.01 kg.
  ["SN: K50001-UP"]
16   708-2L-45230   [1]   SPRING Komatsu 0.005 kg.
  ["SN: K50001-UP"]
17   708-2L-44320   [1]   SCREW Komatsu 0.000 kg.
  ["SN: K50001-UP"]
18   07000-B3038   [1]   O-RING Komatsu 0.002 kg.
  ["SN: K50001-UP"]
19   708-2G-15230   [1]   RING Komatsu 0.001 kg.
  ["SN: K50001-UP"]
20   708-2G-15260   [1]   SEAL Komatsu 0.003 kg.
  ["SN: K50001-UP"]
21   708-2L-35270   [1]   PLUG Komatsu 0.04 kg.
  ["SN: K50001-UP"]
22   07000-B2011   [1]   O-RING Komatsu 0.001 kg.
  ["SN: K50001-UP"]
23   07000-B2050   [1]   O-RING Komatsu 0.002 kg.
  ["SN: K50001-UP"]
24   708-2G-15310   [1]   RING Komatsu 0.001 kg.
  ["SN: K50001-UP"]
25   708-2L-44161   [1]   COVER Komatsu 1.502 kg.
  ["SN: K50001-UP"]
26   01580-10806   [1]   NUT Komatsu 0.005 kg.
  ["SN: K50001-UP"] analogs:["801920104"]
27   708-2L-35290   [1]   NUT Komatsu 0.12 kg.
  ["SN: K50001-UP"]
28   708-2G-15330   [1]   RING, WIRE Komatsu 0.005 kg.
  ["SN: K50001-UP"]
29   708-2L-45240   [2]   RING, SEAL Komatsu 0.001 kg.
  ["SN: K50001-UP"]
30   01252-61645   [4]   BOLT Komatsu 0.119 kg.
  ["SN: K50001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2L-00701   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K54697-UP"] analogs:["7082L00700"] |1.
     708-2L-00700   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K50001-K54696"] analogs:["7082L00701"] |1.
        708-2L-01701   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K54697-UP"] |1.
        708-2L-01700   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K50001-K54696"] |1.
     708-2L-06860   [1]   COVER ASSEMBLY Komatsu China
  ["SN: K50001-UP"] |1.
1   708-2L-44171   [1]   SCREW Komatsu China
  ["SN: K50001-UP"]
2   07000-B3038   [1]   O-RING Komatsu 0.002 kg.
  ["SN: K50001-UP"]
3   708-2G-15230   [1]   RING Komatsu 0.001 kg.
  ["SN: K50001-UP"]
4   708-2L-35290   [1]   NUT Komatsu 0.12 kg.
  ["SN: K50001-UP"]
5   708-2L-44130   [1]   COVER Komatsu 1.47 kg.
  ["SN: K50001-UP"]
6   07000-B2050   [1]   O-RING Komatsu 0.002 kg.
  ["SN: K50001-UP"]
7   708-2G-15310   [1]   RING Komatsu 0.001 kg.
  ["SN: K50001-UP"]
8   01252-61645   [4]   BOLT Komatsu 0.119 kg.
  ["SN: K50001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2L-00701   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K54697-UP"] analogs:["7082L00700"] |1.
     708-2L-00700   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K50001-K54696"] analogs:["7082L00701"] |1.
        708-2L-01701   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K54697-UP"] |1.
        708-2L-01700   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K50001-K54696"] |1.
     708-2L-06790   [1]   CASE ASSEMBLY, REAR Komatsu 0.000 kg.
  ["SN: K50001-UP"] |1.
3   07000-B1009   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: K50001-UP"] analogs:["7082L23910"]
4   708-1L-29340   [1]   ORIFICE Komatsu 0.001 kg.
  ["SN: K50001-UP"]
5   708-2L-41170   [8]   O-RING Komatsu 0.001 kg.
  ["SN: K50001-UP"]
6   07044-12412   [1]   PLUG Komatsu 0.09 kg.
  ["SN: K50001-UP"] analogs:["0704402412", "R0704412412"]
7   07002-62434   [1]   O-RING Komatsu 0.001 kg.
  ["SN: K50001-UP"] analogs:["7081W28910"]
8   04530-11222   [1]   BOLT, EYE Komatsu 0.122 kg.
  ["SN: K50001-UP"]
9   20B-27-11210   [1]   BLEEDER Komatsu 0.02 kg.
  ["SN: K50001-UP"]
10   708-8E-16150   [3]   PLUG Komatsu 0.02 kg.
  ["SN: K50001-UP"]
11   07002-61023   [3]   O-RING Komatsu 0.22 kg.
  ["SN: K50001-UP"] analogs:["7082L23920"]
12   07040-12414   [1]   PLUG Komatsu 0.092 kg.
  ["SN: K50001-UP"] analogs:["0704002412", "0704012412"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2L-00701   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K54697-UP"] analogs:["7082L00700"] |1.
     708-2L-00700   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K50001-K54696"] analogs:["7082L00701"] |1.
        708-2L-01701   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K54697-UP"] |1.
        708-2L-01700   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K50001-K54696"] |1.
1   708-2L-42220   [1]   SHAFT, REAR Komatsu 0.000 kg.
  ["SN: K50001-UP"]
2   708-2L-42250   [1]   BEARING Komatsu 0.42 kg.
  ["SN: K50001-UP"]
3   708-2E-05040   [1]   WASHER KIT Komatsu 0.101 kg.
  ["SN: K50001-UP"] analogs:["7082E12190"]
4   708-25-12790   [1]   RING, SNAP Komatsu 0.006 kg.
  ["SN: K50001-UP"]
     708-2L-06890   [1]   BLOCK ASSEMBLY, REAR Komatsu 5.26 kg.
  ["SN: K50001-UP"] |5.
7   708-18-13230   [1]   PIN Komatsu 0.01 kg.
  ["SN: K50001-UP"]
8   04065-05820   [1]   RING, SNAP Komatsu 0.01 kg.
  ["SN: K50001-UP"]
9   708-2L-43130   [1]   SEAT Komatsu 0.03 kg.
  ["SN: K50001-UP"]
10   708-2L-43150   [1]   SPRING Komatsu 0.21 kg.
  ["SN: K50001-UP"]
11   708-2H-23141   [1]   SEAT Komatsu 0.03 kg.
  ["SN: K50001-UP"]
12   708-2L-43510   [1]   GUIDE, RETAINER Komatsu 0.22 kg.
  ["SN: K50001-UP"]
13   708-2L-43360   [3]   PIN Komatsu 0.000 kg.
  ["SN: K50001-UP"]
14   708-2L-43340   [1]   RETAINER, SHOE Komatsu 0.39 kg.
  ["SN: K50001-UP"]
15   708-2L-43311   [9]   PISTON SUB ASSEMBLY Komatsu 0.28 kg.
  ["SN: K50001-UP"]
     708-2L-06262   [1]   CRADLE ASSEMBLY Komatsu 6.1 kg.
  ["SN: K50001-UP"] analogs:["7082L06261"] |16.
     708-2L-06261   [1]   CRADLE ASSEMBLY Komatsu 6.1 kg.
  ["SN: K50001-UP"] analogs:["7082L06262"] |16.
18   04020-01228   [1]   PIN, DOWEL Komatsu 0.026 kg.
  ["SN: K50001-UP"] analogs:["21T3016190"]
19   01252-61025   [6]   BOLT Komatsu 0.028 kg.
  ["SN: K50001-UP"]
20   708-2L-42230   [1]   COUPLING Komatsu 0.000 kg.
  ["SN: K50001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2L-00701   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K54697-UP"] analogs:["7082L00700"] |1.
     708-2L-00700   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K50001-K54696"] analogs:["7082L00701"] |1.
        708-2L-01701   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K54697-UP"] |1.
        708-2L-01700   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K50001-K54696"] |1.
1   708-2L-44120   [1]   SLIDER Komatsu 0.32 kg.
  ["SN: K50001-UP"]
     708-2L-06643   [1]   VALVE ASSEMBLY, PC Komatsu 0.000 kg.
  ["SN: K54697-UP"] analogs:["7082L06640"] |2.
     708-2L-06640   [1]   VALVE ASSEMBLY, PC Komatsu 0.000 kg.
  ["SN: K50001-K54696"] analogs:["7082L06643"] |2.
     708-2L-06690   [1]   PISTON ASSEMBLY, SERVO Komatsu 0.000 kg.
  ["SN: K50001-UP"] |2.
4   708-2G-15320   [1]   SEAL Komatsu 0.002 kg.
  ["SN: K50001-UP"]
5   708-2L-45210   [1]   PLUG Komatsu 0.000 kg.
  ["SN: K50001-UP"]
6   708-2L-35760   [1]   BALL Komatsu 0.001 kg.
  ["SN: K50001-UP"]
7   708-2L-35770   [1]   PLUG Komatsu 0.005 kg.
  ["SN: K50001-UP"]
8   708-2L-35690   [3]   SEAL Komatsu 0.003 kg.
  ["SN: K50001-UP"]
9   708-2L-35280   [1]   PIN Komatsu 0.01 kg.
  ["SN: K50001-UP"]
10   708-2L-35860   [1]   SPOOL Komatsu 0.03 kg.
  ["SN: K50001-UP"]
11   708-2G-15290   [1]   RETAINER Komatsu 0.05 kg.
  ["SN: K50001-UP"]
12   708-2L-35641   [1]   SEAT Komatsu 0.01 kg.
  ["SN: K50001-UP"]
13   708-2L-45220   [1]   SPRING Komatsu 0.21 kg.
  ["SN: K50001-UP"]
14   708-2L-44190   [1]   SPRING Komatsu 0.14 kg.
  ["SN: K50001-UP"]
15   708-2L-35650   [1]   SEAT Komatsu 0.01 kg.
  ["SN: K50001-UP"]
16   708-2L-45230   [1]   SPRING Komatsu 0.005 kg.
  ["SN: K50001-UP"]
17   708-2L-44320   [1]   SCREW Komatsu 0.000 kg.
  ["SN: K50001-UP"]
18   07000-B3038   [1]   O-RING Komatsu 0.002 kg.
  ["SN: K50001-UP"]
19   708-2G-15230   [1]   RING Komatsu 0.001 kg.
  ["SN: K50001-UP"]
20   708-2G-15260   [1]   SEAL Komatsu 0.003 kg.
  ["SN: K50001-UP"]
21   708-2L-35270   [1]   PLUG Komatsu 0.04 kg.
  ["SN: K50001-UP"]
22   07000-B2011   [1]   O-RING Komatsu 0.001 kg.
  ["SN: K50001-UP"]
23   07000-B2050   [1]   O-RING Komatsu 0.002 kg.
  ["SN: K50001-UP"]
24   708-2G-15310   [1]   RING Komatsu 0.001 kg.
  ["SN: K50001-UP"]
25   708-2L-44161   [1]   COVER Komatsu 1.502 kg.
  ["SN: K50001-UP"]
26   01580-10806   [1]   NUT Komatsu 0.005 kg.
  ["SN: K50001-UP"] analogs:["801920104"]
27   708-2L-35290   [1]   NUT Komatsu 0.12 kg.
  ["SN: K50001-UP"]
28   708-2G-15330   [1]   RING, WIRE Komatsu 0.005 kg.
  ["SN: K50001-UP"]
29   708-2L-45240   [2]   RING, SEAL Komatsu 0.001 kg.
  ["SN: K50001-UP"]
30   01252-61645   [4]   BOLT Komatsu 0.119 kg.
  ["SN: K50001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2L-00701   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K54697-UP"] analogs:["7082L00700"] |1.
     708-2L-00700   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K50001-K54696"] analogs:["7082L00701"] |1.
        708-2L-01701   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K54697-UP"] |1.
        708-2L-01700   [1]   PUMP SUB ASSEMBLY Komatsu China
  ["SN: K50001-K54696"] |1.
     708-2L-06860   [1]   COVER ASSEMBLY Komatsu China
  ["SN: K50001-UP"] |1.
1   708-2L-44171   [1]   SCREW Komatsu China
  ["SN: K50001-UP"]
2   07000-B3038   [1]   O-RING Komatsu 0.002 kg.
  ["SN: K50001-UP"]
3   708-2G-15230   [1]   RING Komatsu 0.001 kg.
  ["SN: K50001-UP"]
4   708-2L-35290   [1]   NUT Komatsu 0.12 kg.
  ["SN: K50001-UP"]
5   708-2L-44130   [1]   COVER Komatsu 1.47 kg.
  ["SN: K50001-UP"]
6   07000-B2050   [1]   O-RING Komatsu 0.002 kg.
  ["SN: K50001-UP"]
7   708-2G-15310   [1]   RING Komatsu 0.001 kg.
  ["SN: K50001-UP"]
8   01252-61645   [4]   BOLT Komatsu 0.119 kg.
  ["SN: K50001-UP"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2L-00701   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K54697-UP"] analogs:["7082L00700"] |1.
     708-2L-00700   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K50001-K54696"] analogs:["7082L00701"] |1.
        708-2L-07710   [2]   VALVE ASSEMBLY, LS Komatsu 0.000 kg.
  ["SN: K54697-UP"] |1.
        708-2L-06780   [2]   VALVE ASSEMBLY, LS Komatsu China
  ["SN: K50001-K54696"] |1.
1   708-2L-35311   [1]   SLEEVE Komatsu 0.36 kg.
  ["SN: K50001-UP"]
2   708-2L-24680   [4]   SEAL Komatsu 0.003 kg.
  ["SN: K50001-UP"]
3   708-2L-35430   [1]   SPOOL Komatsu China
  ["SN: K50001-UP"]
4   708-2L-28540   [1]   PISTON Komatsu 0.01 kg.
  ["SN: K50001-UP"]
5   708-2L-35360   [1]   SLEEVE Komatsu 0.04 kg.
  ["SN: K50001-UP"]
6   708-2L-35331   [1]   SEAT Komatsu 0.01 kg.
  ["SN: K50001-UP"]
7   708-2L-35880   [1]   SPRING Komatsu China
  ["SN: K54697-UP"]
     708-2L-35560   [1]   SPRING Komatsu China
  ["SN: K50001-K54696"] |7.
8   708-2L-35341   [1]   SEAT Komatsu 0.001 kg.
  ["SN: K50001-UP"]
9   708-2L-35351   [1]   PLUG Komatsu 0.04 kg.
  ["SN: K50001-UP"]
10   07000-B1009   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: K50001-UP"] analogs:["7082L23910"]
11   07001-01009   [1]   RING, BACK-UP Komatsu 0.001 kg.
  ["SN: K50001-UP"]
12   01583-11408   [1]   NUT Komatsu 0.4 kg.
  ["SN: K50001-UP"] analogs:["801713411"]
13   07002-62434   [1]   O-RING Komatsu 0.001 kg.
  ["SN: K50001-UP"] analogs:["7081W28910"]
Parts on group :
Pos. Part No Qty Parts name Comments
     708-2L-00701   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K54697-UP"] analogs:["7082L00700"] |1.
     708-2L-00700   [1]   PUMP ASSEMBLY Komatsu 187 kg.
  ["SN: K50001-K54696"] analogs:["7082L00701"] |1.
   1.   702-21-57400   [1]   PILOT VALVE Komatsu OEM 0.442 kg.
  ["SN: K50001-UP"] analogs:["7022155901"]
   2.   01252-60635   [2]   BOLT Komatsu 0.011 kg.
  ["SN: K50001-UP"]
   3.   20Y-62-22790   [1]   BAND, RED Komatsu 0.001 kg.
  ["SN: K50001-UP"]
   6.   20Y-62-22830   [1]   BAND, WHITE Komatsu 0.001 kg.
  ["SN: K50001-UP"]
   9.   20Y-62-22810   [1]   BAND, YELLOW Komatsu 0.001 kg.
  ["SN: K50001-UP"]
   10.   708-1G-15910   [2]   PLUG Komatsu China
  ["SN: K50001-UP"] analogs:["7082L44220"]
   11.   07000-B1008   [2]   O-RING Komatsu 0.001 kg.
  ["SN: K50001-UP"]
   12.   07001-01008   [4]   RING, BACK-UP Komatsu 0.001 kg.
  ["SN: K50001-UP"]
   13.   07002-61423   [2]   O-RING Komatsu 0.001 kg.
  ["SN: K50001-UP"] analogs:["7082L23950"]

Materials

Shipping & Returns

Dimensions

Care Instructions

查看完整資訊

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Kawasaki Best Selling Series

檢視全部

Komatsu Best Selling Series

檢視全部

Caterpillar Best Selling Series

檢視全部
