| 706-7G-01190 706-7G-03160 PC210-10 PC210LC-10 PC240LC-10 PC240NLC-1 PC290LC-10 PC290NLC-10 |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
706-7G-01190
|
[1] |
Swing Motor Assembly Komatsu China
|
|
|
["SN: K60001-UP"] analogs:["R7067G01190"] |$0. |
|
|
706-7G-03160
|
[1] |
Motor Subassembly Komatsu China
|
|
|
["SN: K60001-UP"] |$1. |
| 1 |
706-7G-41250
|
[1] |
Case Komatsu China
|
|
|
["SN: K60001-UP", "SCC: C2"] |
| 2 |
706-7G-71180
|
[1] |
Housing Komatsu China
|
|
|
["SN: K60001-UP", "SCC: C2"] |
| 3 |
706-7G-40110
|
[1] |
Bushing Komatsu China
|
|
|
["SN: K60001-UP", "SCC: C2"] |
| 4 |
708-8K-15190
|
[1] |
Pin, Dowel Komatsu China
|
|
|
["SN: K60001-UP", "SCC: C2"] |
| 5 |
709-25-11650
|
[2] |
Valve, Check Komatsu
|
0.02 kg. |
|
["SN: K60001-UP"] |
| 6 |
709-25-11361
|
[2] |
Spring Komatsu
|
0.005 kg. |
|
["SN: K60001-UP"] |
| 7 |
709-25-11640
|
[2] |
Plug Komatsu
|
0.157 kg. |
|
["SN: K60001-UP"] |
| 8 |
07000-B2020
|
[2] |
O-Ring Komatsu China
|
|
|
["SN: K60001-UP"] |
| 11 |
706-7G-71710
|
[2] |
Valve Komatsu
|
0.1 kg. |
|
["SN: K60001-UP"] |
| 12 |
706-7G-71560
|
[2] |
Spring Komatsu
|
0.05 kg. |
|
["SN: K60001-UP"] |
| 13 |
706-7G-71630
|
[2] |
Plug Komatsu China
|
|
|
["SN: K60001-UP"] |
| 14 |
07002-63334
|
[2] |
O-Ring Komatsu
|
1.46 kg. |
|
["SN: K60001-UP"] |
| 15 |
706-7G-40210
|
[1] |
O-Ring Komatsu China
|
|
|
["SN: K60001-UP", "SCC: C2"] |
| 16 |
01010-61450
|
[6] |
Bolt Komatsu
|
0.085 kg. |
|
["SN: K60001-UP", "SCC: C2"] analogs:["0101031450", "0101051450", "0101081450"] |
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
706-7G-01190
|
[1] |
Swing Motor Assembly Komatsu China
|
|
|
["SN: K60001-UP"] analogs:["R7067G01190"] |$0. |
|
|
706-7G-03160
|
[1] |
Motor Subassembly Komatsu China
|
|
|
["SN: K60001-UP"] |$1. |
| 1 |
706-7G-41630
|
[1] |
Shaft Komatsu
|
3 kg. |
|
["SN: K60001-UP", "SCC: C2"] |
| 2 |
706-75-42880
|
[1] |
Bearing Komatsu
|
2.42 kg. |
|
["SN: K60001-UP", "SCC: C2"] |
| 3 |
706-7G-41660
|
[1] |
Spacer Komatsu China
|
|
|
["SN: K60001-UP", "SCC: C2"] |
| 4 |
706-76-40890
|
[1] |
Bearing Komatsu
|
0.524 kg. |
|
["SN: K60001-UP", "SCC: C2"] |
| 5 |
706-7G-41510
|
[1] |
Spacer Kit Komatsu China
|
|
|
["SN: K60001-UP", "SCC: C2"] |
| 6 |
04064-04518
|
[1] |
Ring, Snap Komatsu China
|
0.007 kg. |
|
["SN: K60001-UP", "SCC: C2"] analogs:["20Y3029190"] |
| 7 |
706-75-43410
|
[1] |
Seal, Oil Komatsu
|
0.15 kg. |
|
["SN: K60001-UP"] |
| 8 |
706-7G-41910
|
[1] |
Spacer Komatsu
|
0.042 kg. |
|
["SN: K60001-UP"] |
| 9 |
04065-06220
|
[1] |
Ring, Snap Komatsu
|
0.013 kg. |
|
["SN: K60001-UP"] |
| 10 |
706-7G-41310
|
[1] |
Block, Cylinder Komatsu
|
2.3 kg. |
|
["SN: K60001-UP", "SCC: C2"] |
| 11 |
706-7G-41720
|
[1] |
Plate, Valve Komatsu
|
0.38 kg. |
|
["SN: K60001-UP", "SCC: C2"] |
| 12 |
706-75-43750
|
[1] |
Pin, Dowel Komatsu China
|
|
|
["SN: K60001-UP", "SCC: C2"] |
| 13 |
706-7G-41320
|
[1] |
Shaft Komatsu China
|
|
|
["SN: K60001-UP", "SCC: C2"] |
| 14 |
706-7G-41130
|
[1] |
Ring Komatsu China
|
|
|
["SN: K60001-UP", "SCC: C2"] |
| 15 |
706-7G-41140
|
[1] |
Spring Komatsu
|
0.06 kg. |
|
["SN: K60001-UP", "SCC: C2"] |
| |
706-7G-05010
|
[1] |
Retainer Kit Komatsu
|
0.22 kg. |
|
["SN: K60001-UP", "SCC: C2"] |$20. |
| 18 |
706-7G-41410
|
[7] |
Piston Subassembly Komatsu
|
0.000 kg. |
|
["SN: K60001-UP", "SCC: C2"] |
| 19 |
706-7G-91441
|
[5] |
Plate Komatsu
|
0.11 kg. |
|
["SN: K60001-UP", "SCC: C2"] |
| 20 |
706-7G-91450
|
[4] |
Disc Komatsu
|
0.08 kg. |
|
["SN: K60001-UP", "SCC: C2"] |
| 21 |
706-7G-91120
|
[1] |
Piston, Brake Komatsu China
|
|
|
["SN: K60001-UP", "SCC: C2"] |
| 22 |
708-1W-49170
|
[1] |
O-Ring Komatsu China
|
|
|
["SN: K60001-UP", "SCC: C2"] |
| 23 |
706-7G-91520
|
[1] |
O-Ring Komatsu China
|
|
|
["SN: K60001-UP", "SCC: C2"] |
| 24 |
706-7G-91360
|
[6] |
Spring Komatsu China
|
|
|
["SN: K60001-UP", "SCC: C2"] |
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
706-7G-01190
|
[1] |
Swing Motor Assembly Komatsu China
|
|
|
["SN: 450001-UP"] analogs:["R7067G01190"] |$0. |
|
1. |
702-75-01330
|
[1] |
Valve, Relief Komatsu China
|
|
