KOMATSU PC200-7 PC200-8 PC200LC-7 PC200LC-8 PC210-8K PC210LC-8K PC210NLC-8K PC220-7 PC220-8 PC220LC-7 PC220LC-8 PC230NHD-8K PC270-7 PC270-8PC270LC-8-W1 PC290LC-8K PC290NLC-8K EXCAVATOR 706-7G-01041 706-7G-03041 PUMP ASSEMBLY ROTARY GROUP AND SPARE PARTS

KOMATSU PC200-7 PC200-8 PC200LC-7 PC200LC-8 PC210-8K PC210LC-8K PC210NLC-8K PC220-7 PC220-8 PC220LC-7 PC220LC-8 PC230NHD-8K PC270-7 PC270-8PC270LC-8-W1 PC290LC-8K PC290NLC-8K EXCAVATOR 706-7G-01041 706-7G-03041 PUMP ASSEMBLY ROTARY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
706-7G-01041 706-7G-03041 PC200-7 PC200-8 PC200LC-7 PC200LC-8 PC210-8K PC210LC-8K PC210NLC-8K PC220-7 PC220-8 PC220LC-7 PC220LC-8 PC230NHD-8K PC270-7 PC270-8PC270LC-8-W1 PC290LC-8K PC290NLC-8K
Pos. Part No Qty Parts name Comments
     706-7G-01041   [1]   MOTOR ASSEMBLY Komatsu 57.5 kg.
  ["SN: K50011-K51120"] analogs:["7067G03040", "7067G01040", "7067G01130", "7067G03041"] |1.
        706-7G-03041   [1]   MOTOR SUB ASSEMBLY Komatsu 57.5 kg.
  ["SN: K50011-K51120"] analogs:["7067G03040", "7067G01040", "7067G01130", "7067G01041"] |1.
1   706-7G-41111   [1]   CASE Komatsu China
  ["SN: K50011-K51120"] analogs:["7067G41110"]
2   706-7G-71130   [1]   HOUSING Komatsu China
  ["SN: K50011-K51120"]
3   706-7G-40010   [1]   BEARING Komatsu 0.032 kg.
  ["SN: K50011-K51120"]
4   706-75-42820   [1]   PIN, DOWEL Komatsu China
  ["SN: K50011-K51120"]
5   709-25-11650   [2]   VALVE, CHECK Komatsu 0.02 kg.
  ["SN: K50011-K51120"]
6   709-25-11361   [2]   SPRING Komatsu 0.005 kg.
  ["SN: K50011-K51120"]
7   709-25-11640   [2]   PLUG Komatsu 0.157 kg.
  ["SN: K50011-K51120"]
8   07000-12020   [2]   O-RING Komatsu 0.001 kg.
  ["SN: K50011-K51120"]
9   706-75-74540   [2]   VALVE Komatsu 0.134 kg.
  ["SN: K50011-K51120"]
10   706-7G-71550   [2]   SPRING Komatsu 0.02 kg.
  ["SN: K50011-K51120"]
11   706-75-74850   [2]   PLUG Komatsu China
  ["SN: K50011-K51120"]
12   07002-13334   [2]   O-RING Komatsu China 0.025 kg.
  ["SN: K50011-K51120"] analogs:["0700203334"]
13   706-75-42370   [1]   O-RING Komatsu 0.012 kg.
  ["SN: K50011-K51120"]
14   01252-61245   [10]   BOLT Komatsu 0.057 kg.
  ["SN: K50011-K51120"] analogs:["0125241245"]
Parts on group :
Pos. Part No Qty Parts name Comments
     706-7G-01041   [1]   MOTOR ASSEMBLY Komatsu 57.5 kg.
  ["SN: K50011-K51120"] analogs:["7067G03040", "7067G01040", "7067G01130", "7067G03041"] |1.
        706-7G-03041   [1]   MOTOR SUB ASSEMBLY Komatsu 57.5 kg.
  ["SN: K50011-K51120"] analogs:["7067G03040", "7067G01040", "7067G01130", "7067G01041"] |1.
1   706-7G-41610   [1]   SHAFT, DRIVE Komatsu 3.9 kg.
  ["SN: K50011-K51120"]
2   706-75-42880   [1]   BEARING Komatsu 2.42 kg.
  ["SN: K50011-K51120"]
3   706-75-43810   [1]   SPACER Komatsu 0.635 kg.
  ["SN: K50011-K51120"]
4   706-7E-11260   [2]   SPRING Komatsu 0.03 kg.
  ["SN: K50011-K51120"]
5   706-7E-11270   [1]   SEAT Komatsu 0.05 kg.
  ["SN: K50011-K51120"]
6   706-76-40890   [1]   BEARING Komatsu 0.524 kg.
  ["SN: K50011-K51120"]
7   706-75-05040   [1]   SPACER KIT Komatsu 0.091 kg.
  ["SN: K50011-K51120"]
8   04064-04518   [1]   RING, SNAP Komatsu China 0.007 kg.
  ["SN: K50011-K51120"] analogs:["20Y3029190"]
9   706-7E-11280   [1]   SEAL, OIL Komatsu 0.15 kg.
  ["SN: K50011-K51120"]
10   706-75-43720   [1]   SPACER Komatsu 0.042 kg.
  ["SN: K50011-K51120"] analogs:["7067G41910"]
11   04065-06220   [1]   RING, SNAP Komatsu 0.013 kg.
  ["SN: K50011-K51120"]
12 706-7G-41210 [1]   BLOCK, CYLINDER Komatsu 2.402 kg.
  ["SN: K50011-K51120"]
13   706-7G-41710   [1]   PLATE, VALVE Komatsu 0.38 kg.
  ["SN: K50011-K51120"]
14   706-75-43750   [1]   PIN, DOWEL Komatsu China
  ["SN: K50011-K51120"]
15   706-7G-41120   [1]   SHAFT, CENTER Komatsu 0.37 kg.
  ["SN: K50011-K51120"]
16   706-7G-41130   [1]   RING, CENTER Komatsu China
  ["SN: K50011-K51120"]
17   706-7G-41140   [1]   SPRING Komatsu 0.06 kg.
  ["SN: K50011-K51120"]
     706-7G-05010   [1]   RETAINER KIT Komatsu 0.22 kg.
  ["SN: K50011-K51120"] |18.
20   706-7G-41160   [7]   PISTON SUB ASSEMBLY Komatsu 0.22 kg.
  ["SN: K50011-K51120"]
21   706-7G-91340   [5]   PLATE Komatsu 0.12 kg.
  ["SN: K50011-K51120"]
22   706-7G-91350   [4]   DISC Komatsu 0.083 kg.
  ["SN: K50011-K51120"]
23   706-7G-91111   [1]   PISTON, BRAKE Komatsu OEM 2.7 kg.
  ["SN: K50011-K51120"] analogs:["7067G91110"]
24   706-77-40370   [1]   O-RING Komatsu OEM 0.01 kg.
  ["SN: K50011-K51120"]
25   708-8F-31610   [1]   O-RING Komatsu OEM 0.006 kg.
  ["SN: K50011-K51120"]
26   706-7G-91360   [6]   SPRING Komatsu China
  ["SN: K50011-K51120"]
Parts on group :
Pos. Part No Qty Parts name Comments
     706-7G-01041   [1]   MOTOR ASSEMBLY Komatsu 57.5 kg.
  ["SN: K50011-K51120"] analogs:["7067G03040", "7067G01040", "7067G01130", "7067G03041"] |1.
   1.   702-75-01270   [1]   VALVE ASSEMBLY, RELIEF Komatsu OEM 0.64 kg.
  ["SN: K50011-K51120"] analogs:["7027501250"]
2   07000-F2020   [1]   O-RING Komatsu China 0.001 kg.
  ["SN: K50011-K51120"] analogs:["0700022020"]
3   07001-02020   [1]   RING, BACK-UP Komatsu 0.001 kg.
  ["SN: K50011-K51120"]
4   07002-13034   [1]   O-RING Komatsu China 0.005 kg.
  ["SN: K50011-K51120"] analogs:["0700203034"]
        702-15-77000   [1]   VALVE ASSEMBLY Komatsu 1.17 kg.
  ["SN: K50011-K51120"] |5.
7   709-70-71610   [2]   SEAL Komatsu China
  ["SN: K50011-K51120"]
8   702-15-71130   [2]   SPRING Komatsu 0.005 kg.
  ["SN: K50011-K51120"]
9   702-15-71140   [2]   PLUG Komatsu China
  ["SN: K50011-K51120"]
10   07002-01423   [2]   O-RING Komatsu China 0.001 kg.
  ["SN: K50011-K51120"] analogs:["0700211423"]
   11.   07000-13042   [1]   O-RING Komatsu China 0.01 kg.
  ["SN: K50011-K51120"] analogs:["0700003042"]
   12.   07000-11009   [2]   O-RING Komatsu 0.001 kg.
  ["SN: K50011-K51120"] analogs:["0700001009"]
   13.   01252-60825   [2]   BOLT Komatsu 0.017 kg.
  ["SN: K50011-K51120"] analogs:["0125240825", "0125230825"]
