21P-60-K1183
PC150-6K PC150LC-6K PC160-6K PC180LC-6K PC180NLC-6K PC200EL-6K PC200EN-6K PW150ES-6K PW170ES-6K PW170ES-6K-KA
|
|
|
|
|
|
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
21P-60-K1183
|
[1] |
MOTOR ASS'Y,SWING Komatsu
|
28.4 kg. |
|
["SN: K30135-UP"] analogs:["21P60K5190", "21P60K1182"] |1. |
|
1. |
21P-60-K4760
|
[1] |
HOUSING Komatsu China
|
|
|
["SN: K30135-UP"] |
|
2. |
21P-60-K1250
|
[1] |
PLATE,VALVE Komatsu
|
0.17 kg. |
|
["SN: K30001-UP"] |
|
3. |
21P-60-K2710
|
[1] |
PLUG Komatsu
|
0.000 kg. |
|
["SN: K30001-UP"] |
|
4. |
21P-60-K4770
|
[1] |
HOUSING Komatsu China
|
|
|
["SN: K30135-UP"] |
|
5. |
21P-60-K1260
|
[1] |
O-RING Komatsu
|
0.01 kg. |
|
["SN: K30001-UP"] |
|
6. |
21P-60-K1270
|
[1] |
O-RING Komatsu
|
0.002 kg. |
|
["SN: K30135-UP"] |
|
7. |
21P-60-K1280
|
[1] |
O-RING Komatsu
|
4 kg. |
|
["SN: K30001-UP"] |
|
8. |
21P-60-K4780
|
[1] |
SEAL Komatsu
|
0.24 kg. |
|
["SN: K30135-UP"] |
|
9. |
21P-60-K4790
|
[1] |
SEAL Komatsu China
|
|
|
["SN: K30135-UP"] |
|
10. |
21P-60-K4810
|
[1] |
SPACER,(NOT SHOWN) Komatsu China
|
|
|
["SN: K30135-UP"] |
|
11. |
21P-60-K2740
|
[1] |
RING Komatsu China
|
|
|
["SN: K30001-UP"] |
|
12. |
21P-60-K4820
|
[1] |
RING Komatsu China
|
|
|
["SN: K30135-UP"] |
|
13. |
21P-60-K2750
|
[1] |
SEAL Komatsu China
|
|
|
["SN: K30001-UP"] |
|
14. |
21P-60-K4830
|
[1] |
SHAFT Komatsu
|
2.5 kg. |
|
["SN: K30135-UP"] |
|
15. |
21P-60-K2770
|
[1] |
PIN Komatsu China
|
|
|
["SN: K30135-UP"] |
|
16. |
21P-60-K4840
|
[1] |
BARREL Komatsu
|
0.000 kg. |
|
["SN: K30135-UP"] |
|
17. |
21P-60-K4850
|
[1] |
SUPPORT Komatsu
|
0.000 kg. |
|
["SN: K30135-UP"] |
|
18. |
21P-60-K2820
|
[7] |
PISTON ASS'Y Komatsu
|
0.05 kg. |
|
["SN: K30135-UP"] |
|
19. |
21P-60-K1310
|
[21] |
RING,PISTON Komatsu
|
0.001 kg. |
|
["SN: K30135-UP"] |
|
20. |
21P-60-K4860
|
[1] |
RING,NEEDLE Komatsu China
|
|
|
["SN: K30135-UP"] |
|
21. |
21P-60-K1360
|
[1] |
BEARING,BALL Komatsu
|
0.000 kg. |
|
["SN: K30001-UP"] |
|
22. |
21P-60-K4870
|
[1] |
BEARING Komatsu
|
0.5 kg. |
|
["SN: K30135-UP"] |
|
23. |
21P-60-K4880
|
[1] |
SPACER¤ 2.35MM Komatsu China
|
|
|
["SN: K30135-UP"] |
|
|
21P-60-K4890
|
[1] |
SPACER¤ 2.4MM Komatsu China
|
|
|
["SN: K30135-UP"] |23. |
|
|
21P-60-K4910
|
[1] |
SPACER¤ 2.45MM Komatsu China
|
|
|
["SN: K30135-UP"] |23. |
|
|
21P-60-K4920
|
[1] |
SPACER¤ 2.5MM Komatsu China
|
|
|
["SN: K30135-UP"] |23. |
|
|
21P-60-K4930
|
[1] |
SPACER¤ 2.55MM Komatsu China
|
|
|
["SN: K30135-UP"] |23. |
|
|
21P-60-K4940
|
[1] |
SPACER¤ 2.6MM Komatsu China
|
|
|
["SN: K30135-UP"] |23. |
|
|
21P-60-K4950
|
[1] |
SPACER¤ 2.65MM Komatsu China
|
|
|
["SN: K30135-UP"] |23. |
|
|
21P-60-K4960
|
[1] |
SPACER¤ 2.7MM Komatsu China
|
|
|
["SN: K30135-UP"] |23. |
|
|
21P-60-K4970
|
[1] |
SPACER¤ 2.75MM Komatsu China
|
|
|
["SN: K30135-UP"] |23. |
|
|
21P-60-K4980
|
[1] |
SPACER¤ 2.8MM Komatsu China
|
|
|
["SN: K30135-UP"] |23. |
|
|
21P-60-K4990
|
[1] |
SPACER¤ 2.85MM Komatsu China
|
|
|
["SN: K30135-UP"] |23. |
|
|
21P-60-K5110
|
[1] |
SPACER¤ 2.9MM Komatsu China
|
|
|
["SN: K30135-UP"] |23. |
|
|
21P-60-K5120
|
[1] |
SPACER¤ 2.95MM Komatsu China
|
|
|
["SN: K30135-UP"] |23. |
|
24. |
21P-60-K2670
|
[1] |
RING,RETAINER Komatsu
|
0.000 kg. |
|
["SN: K30001-UP"] |
|
25. |
21P-60-K1410
|
[1] |
SHIM¤ 0.2MM Komatsu
|
0.000 kg. |
|
["SN: K30001-UP"] |
|
|
21P-60-K2880
|
[1] |
SHIM¤ 0.4MM Komatsu China
|
|
|
["SN: K30001-UP"] |25. |
|
|
21P-60-K2890
|
[1] |
SHIM¤ 0.6MM Komatsu China
|
|
|
["SN: K30001-UP"] |25. |
|
|
21P-60-K2910
|
[1] |
SHIM¤ 0.8MM Komatsu China
|
|
|
["SN: K30001-UP"] |25. |
|
|
21P-60-K2920
|
[1] |
SHIM¤ 1.0MM Komatsu China
|
|
|
["SN: K30001-UP"] |25. |
|
|
21P-60-K2930
|
[1] |
SHIM¤ 1.0MM Komatsu China
|
|
|
["SN: K30135-UP"] |25. |
|
26. |
21P-60-K2940
|
[4] |
SCREW Komatsu China
|
|
|
["SN: K30001-UP"] |
|
27. |
21P-60-K4360
|
[1] |
HOUSING Komatsu China
|
|
|
["SN: K30135-UP"] |
|
28. |
21P-60-K1330
|
[2] |
O-RING Komatsu
|
0.01 kg. |
|
["SN: K30001-UP"] |
|
29. |
21P-60-K4370
|
[2] |
PLUG Komatsu China
|
|
|
["SN: K30001-UP"] |
|
30. |
21P-60-K5150
|
[2] |
CARTRIDGE,VALVE Komatsu China
|
|
|
["SN: K30147-UP"] |
|
|
21P-60-K1340
|
[2] |
CARTRIDGE,VALVE Komatsu
|
0.2 kg. |
|
["SN: K30001-K30146"] |30. |
|
31. |
21P-60-K4380
|
[1] |
PLUG Komatsu China
|
|
|
["SN: K30001-UP"] |
|
32. |
21P-60-K1350
|
[2] |
VALVE,CHECK Komatsu China
|
|
|
["SN: K30001-UP"] |
