Komatsu HPV95 hydraulic pump rotary group and spare parts for PC200-6 PC200-7 PC200-8 excavator

Name: Komatsu HPV95 hydraulic pump rotary group and spare parts for PC200-6 PC200-7 PC200-8 excavator
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

Komatsu HPV95 hydraulic pump rotary group and spare parts for PC200-6 PC200-7 PC200-8 excavator

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

HPV95 PC200-6 PC200-7 PC200-8 708-2L-00490 708-2L-01490 708-2L-00500 708-2L-01500 708-2L-01600 PC220-8 PC220LC-8 PC270-8 PC270LC-8 PC240-8K PC290-8K

Pos.	Part No	Qty	Parts name	Comments
	708-2L-00490	[1]	Pump Assembly Komatsu	145 kg.
			["SN: 350615-UP"] analogs:["7082L00500", "7082L00501", "7082L00400"] \|$0.
	708-2L-01490	[1]	Pump Subassembly Komatsu China
			["SN: 350615-UP"] \|$1.
1	708-2L-32160	[1]	Shaft,Front Komatsu	3.1 kg.
			["SN: 350615-UP", "SCC: C2"]
2	708-2L-32150	[1]	Bearing Komatsu	0.6 kg.
			["SN: 350615-UP", "SCC: C2"] analogs:["7082E12152", "7082L22150", "7082512731"]
3	708-2E-05040	[1]	Washer Kit Komatsu	0.101 kg.
			["SN: 350615-UP", "SCC: C2"] analogs:["7082E12190"]
4	708-25-12790	[1]	Ring, Snap Komatsu	0.006 kg.
			["SN: 350615-UP", "SCC: C2"]
5	708-2L-32460	[1]	Seal, Oil Komatsu	0.000 kg.
			["SN: 350615-UP"]
6	708-2L-22160	[1]	Spacer Komatsu	0.047 kg.
			["SN: 350615-UP"]
7	04065-06825	[1]	Ring, Snap Komatsu	0.018 kg.
			["SN: 350615-UP"]
	708-2L-06470	[1]	Block Assembly,Front Komatsu	5.26 kg.
			["SN: 350615-UP", "SCC: C2"] \|$13.
10	720-68-19610	[1]	Pin Komatsu	0.002 kg.
			["SN: 350615-UP", "SCC: C2"]
11	04065-04818	[1]	Ring, Snap Komatsu OEM	0.007 kg.
			["SN: 350615-UP", "SCC: C2"]
12	708-2L-23131	[1]	Seat Komatsu	0.073 kg.
			["SN: 350615-UP", "SCC: C2"]
13	708-2L-33160	[1]	Spring Komatsu	0.12 kg.
			["SN: 350615-UP", "SCC: C2"] analogs:["7082L23151"]
14	708-7L-13140	[1]	Seat Komatsu	0.02 kg.
			["SN: 350615-UP", "SCC: C2"]
15	708-2L-23351	[1]	Guide, Retainer, Retainer Komatsu OEM	0.14 kg.
			["SN: 350615-UP", "SCC: C2"]
16	708-2L-23360	[3]	Pin Komatsu	0.003 kg.
			["SN: 350615-UP", "SCC: C2"]
17	708-2L-33350	[1]	Retainer, Shoe, Shoe Komatsu	0.3 kg.
			["SN: 350615-UP", "SCC: C2"]
18	708-2L-33430	[9]	Piston Subassembly Komatsu	0.209 kg.
			["SN: 350615-UP", "SCC: C2"]
	708-2L-06630	[1]	Cradle Assembly Komatsu	4.3 kg.
			["SN: 350615-UP", "SCC: C2"] \|$25.
21	04020-01228	[1]	Pin, Dowel Komatsu	0.026 kg.
			["SN: 350615-UP", "SCC: C2"] analogs:["21T3016190"]
22	01252-61230	[4]	Bolt, Hexagon Socket Head Komatsu	0.044 kg.
			["SN: 350615-UP", "SCC: C2"]
Parts on group :

Pos.	Part No	Qty	Parts name	Comments
	708-2L-00490	[1]	Pump Assembly Komatsu	145 kg.
			["SN: 350615-UP"] analogs:["7082L00500", "7082L00501", "7082L00400"] \|$0.
	708-2L-01490	[1]	Pump Subassembly Komatsu China
			["SN: 350615-UP"] \|$1.
1	708-2L-32170	[1]	Shaft,Rear Komatsu	2.1 kg.
			["SN: 350615-UP", "SCC: C2"]
2	708-2L-32150	[1]	Bearing Komatsu	0.6 kg.
			["SN: 350615-UP", "SCC: C2"] analogs:["7082E12152", "7082L22150", "7082512731"]
3	708-2E-05040	[1]	Washer Kit Komatsu	0.101 kg.
			["SN: 350615-UP", "SCC: C2"] analogs:["7082E12190"]
4	708-25-12790	[1]	Ring, Snap Komatsu	0.006 kg.
			["SN: 350615-UP", "SCC: C2"]
	708-2L-06480	[1]	Block Assembly,Rear Komatsu	5.26 kg.
			["SN: 350615-UP", "SCC: C2"] \|$10.
7	720-68-19610	[1]	Pin Komatsu	0.002 kg.
			["SN: 350615-UP", "SCC: C2"]
8	04065-04818	[1]	Ring, Snap Komatsu OEM	0.007 kg.
			["SN: 350615-UP", "SCC: C2"]
9	708-2L-23131	[1]	Seat Komatsu	0.073 kg.
			["SN: 350615-UP", "SCC: C2"]
10	708-2L-33160	[1]	Spring Komatsu	0.12 kg.
			["SN: 350615-UP", "SCC: C2"] analogs:["7082L23151"]
11	708-7L-13140	[1]	Seat Komatsu	0.02 kg.
			["SN: 350615-UP", "SCC: C2"]
12	708-2L-23351	[1]	Guide, Retainer, Retainer Komatsu OEM	0.14 kg.
			["SN: 350615-UP", "SCC: C2"]
13	708-2L-23360	[3]	Pin Komatsu	0.003 kg.
			["SN: 350615-UP", "SCC: C2"]
14	708-2L-33350	[1]	Retainer, Shoe, Shoe Komatsu	0.3 kg.
			["SN: 350615-UP", "SCC: C2"]
15	708-2L-33430	[9]	Piston Subassembly Komatsu	0.209 kg.
			["SN: 350615-UP", "SCC: C2"]
	708-2L-06630	[1]	Cradle Assembly Komatsu	4.3 kg.
			["SN: 350615-UP", "SCC: C2"] \|$22.
18	04020-01228	[1]	Pin, Dowel Komatsu	0.026 kg.
			["SN: 350615-UP", "SCC: C2"] analogs:["21T3016190"]
19	01252-61230	[4]	Bolt, Hexagon Socket Head Komatsu	0.044 kg.
			["SN: 350615-UP", "SCC: C2"]
