Komatsu HMV160 hydraulic final drive travel motor rotary group and spare parts for Komatsu PC300-6 PC300-7 PC300-8 excavator

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

HMV160 PC300-8 PC350-8 207-27-00560 708-8H-00420 PC270-8 PC270LC-8 PC300-8 PC270LC-8N1-W1 PC308USLC-3E0 PC300-7 PC300-7E0 PC300HD-7E0 PC300LC-7-BA PC360-7 708-8H-00320 TRAVEL MOTOR PC270-7 PC300-7 PC350-7 PC360-7 PC290-7K PC340-7K PC380-7K PC270-8 PC300-8 PC350-8 PC300-8MO PC350-8MO PC290-8K PC290-10

Pos.	Part No	Qty	Parts name	Comments
	207-27-00560	[1]	Final Drive Assembly Komatsu China
			["SN: 63595-UP"] \|$0.
	708-8H-00420	[1]	Motor Assembly Komatsu China
			["SN: 63595-UP"] \|$1.
1	708-8H-32120	[1]	Shaft Komatsu	2.66 kg.
			["SN: 63595-UP", "SCC: C2"]
2	708-8H-32150	[1]	Bearing Komatsu	0.57 kg.
			["SN: 63595-UP", "SCC: C2"]
3	708-8H-32170	[1]	Bearing Komatsu	0.34 kg.
			["SN: 63595-UP", "SCC: C2"]
4	708-8H-05050	[1]	Spacer Kit Komatsu	0.105 kg.
			["SN: 63595-UP", "SCC: C2"]
5	708-1F-12281	[1]	Seal, Oil Komatsu	0.1 kg.
			["SN: 63595-UP"] analogs:["7081F12280"]
6	708-8H-32160	[1]	Spacer Komatsu	0.05 kg.
			["SN: 63595-UP"]
7	04065-07825	[1]	Ring, Snap Komatsu	0.022 kg.
			["SN: 63595-UP"]
	708-8H-04810	[1]	Cylinder Block Assembly Komatsu	7.44 kg.
			["SN: 63595-UP", "SCC: C2"] \|$16.
10	708-18-13230	[1]	Pin Komatsu	0.01 kg.
			["SN: 63595-UP", "SCC: C2"]
11	708-8H-33360	[3]	Pin Komatsu	0.01 kg.
			["SN: 63595-UP", "SCC: C2"]
12	708-8H-33141	[2]	Spacer Komatsu	0.06 kg.
			["SN: 63595-UP", "SCC: C2"]
13	708-8H-33750	[1]	Spring Komatsu China
			["SN: 63595-UP", "SCC: C2"]
14	04065-06020	[1]	Ring, Snap Komatsu	0.011 kg.
			["SN: 63595-UP", "SCC: C2"]
15	708-8H-33512	[1]	Guide, Retainer Komatsu	0.23 kg.
			["SN: 63595-UP", "SCC: C2"]
16	708-8H-33340	[1]	Retainer, Shoe Komatsu	0.44 kg.
			["SN: 63595-UP", "SCC: C2"]
17	708-8H-33650	[9]	Piston Subassembly Komatsu	0.302 kg.
			["SN: 63595-UP", "SCC: C2"]
18	708-8H-33471	[1]	Cam, Rocker Komatsu	3.262 kg.
			["SN: 63595-UP", "SCC: C2"]
19	04260-02857	[2]	Ball, Retainer Komatsu	0.1 kg.
			["SN: 63595-UP", "SCC: C2"]
20	708-8H-34190	[1]	Piston Komatsu China
			["SN: 63595-UP"] analogs:["7088H34143"]
21	708-8H-34151	[1]	Spring Komatsu China
			["SN: 63595-UP"]
22	X17-8320160	[1]	Plug Komatsu China
			["SN: 63595-UP"]
23	07002-13334	[1]	O-ring Komatsu China	0.025 kg.
			["SN: 63595-UP"] analogs:["0700203334"]
24	708-8H-35130	[4]	Plate Komatsu	0.16 kg.
			["SN: 63595-UP", "SCC: C2"]
25	708-8H-35180	[3]	Disc Komatsu	0.36 kg.
			["SN: 63595-UP", "SCC: C2"]
26	708-8H-35141	[1]	Piston, Brake, Brake Komatsu China
			["SN: 63595-UP", "SCC: C2"]
27	07000-15175	[1]	O-ring Komatsu China	0.03 kg.
			["SN: 63595-UP", "SCC: C2"] analogs:["0700005175"]
28	07001-05175	[1]	Ring, Back-up Komatsu China
			["SN: 63595-UP", "SCC: C2"]
29	07000-15195	[1]	O-ring Komatsu China	0.038 kg.
			["SN: 63595-UP", "SCC: C2"] analogs:["0700005195"]
30	07001-05195	[1]	Ring, Back-up Komatsu	0.016 kg.
			["SN: 63595-UP", "SCC: C2"]
31	708-8H-35150	[1]	Spring Komatsu China
			["SN: 63595-UP", "SCC: C2"]
Pos.	Part No	Qty	Parts name	Comments
	708-8H-00320	[1]	MOTOR ASS'Y Komatsu	177.001 kg.
			["SN: 20001-UP"] \|$1.
1.	708-8H-32120	[1]	SHAFT Komatsu	2.66 kg.
			["SN: 20001-UP"]
2.	708-8H-32150	[1]	BEARING Komatsu	0.57 kg.
			["SN: 20001-UP"]
3.	708-8H-32170	[1]	BEARING Komatsu	0.34 kg.
			["SN: 20001-UP"]
4.	708-8H-05050	[1]	SPACER KIT Komatsu	0.105 kg.
			["SN: 20001-UP"]
5.	708-1F-12281	[1]	SEAL,OIL Komatsu	0.1 kg.
			["SN: 20001-UP"] analogs:["7081F12280"]
6.	708-8H-32160	[1]	SPACER Komatsu	0.05 kg.
			["SN: 20001-UP"]
7.	04065-07825	[1]	RING,SNAP Komatsu	0.022 kg.
			["SN: 20001-UP"]
	708-8H-04810	[1]	CYLINDER BLOCK ASS'Y Komatsu	7.44 kg.
			["SN: 20001-UP"] \|$17.
8	708-8H-33710	[1]	BLOCK,CYLINDER Komatsu	6.7 kg.
			["SN: 20001-UP"]
9	708-8H-33810	[1]	PLATE,VALVE Komatsu	0.74 kg.
			["SN: 20001-UP"]
10.	708-18-13230	[1]	PIN Komatsu	0.01 kg.
			["SN: 20001-UP"]
11.	708-8H-33360	[3]	PIN Komatsu	0.01 kg.
			["SN: 20001-UP"]
12.	708-8H-33141	[2]	SPACER Komatsu	0.06 kg.
			["SN: 20001-UP"]
13.	708-8H-33750	[1]	SPRING Komatsu China
			["SN: 20001-UP"]
14.	04065-06020	[1]	RING,SNAP Komatsu	0.011 kg.
			["SN: 20001-UP"]
15.	708-8H-33512	[1]	RETAINER Komatsu	0.23 kg.
			["SN: 20001-UP"]
16.	708-8H-33340	[1]	RETAINER,SHOE Komatsu	0.44 kg.
			["SN: 20001-UP"]
17.	708-8H-33650	[9]	PISTON SUB ASS'Y Komatsu	0.302 kg.
			["SN: 20001-UP"]
18.	708-8H-33471	[1]	CAM,ROCKER Komatsu	3.262 kg.
			["SN: 20001-UP"]
19.	04260-02857	[2]	BALL Komatsu	0.1 kg.
			["SN: 20001-UP"]
20.	708-8H-34143	[1]	PISTON Komatsu China
			["SN: 20001-UP"] analogs:["7088H34190"]
21.	708-8H-34151	[1]	SPRING Komatsu China
			["SN: 20001-UP"]
22.	708-8K-14210	[1]	PLUG Komatsu China
			["SN: 20001-UP"]
23.	07002-13334	[1]	O-RING Komatsu China	0.025 kg.
			["SN: 20001-UP"] analogs:["0700203334"]
24.	708-8H-35130	[4]	PLATE Komatsu	0.16 kg.
			["SN: 20001-UP"]
25.	708-8H-35180	[3]	DISC Komatsu	0.36 kg.
			["SN: 20001-UP"]
26.	708-8H-35141	[1]	PISTON,BRAKE Komatsu China
			["SN: 20001-UP"]
27.	07000-15175	[1]	O-RING Komatsu China	0.03 kg.
			["SN: 20001-UP"] analogs:["0700005175"]
28.	07001-05175	[1]	RING,BACK-UP Komatsu China
			["SN: 20001-UP"]
29.	07000-15195	[1]	O-RING Komatsu China	0.038 kg.
			["SN: 20001-UP"] analogs:["0700005195"]
30.	07001-05195	[1]	RING,BACK-UP Komatsu	0.016 kg.
			["SN: 20001-UP"]
31.	708-8H-35150	[1]	SPRING Komatsu China
			["SN: 20001-UP"]
